OIP-D50E/D50D
Important
P
e l
a
s
e
a
t c
v i
a
e t
y
o
To download the updated software, multilingual manuals, and Quick Start Guide, please visit Lumens
website at:
https://www.
1. Product Introduction
1.1 OIP-D50E Encoder Overview
Front panel
Power Indicator
Link Indicator
RS-232 Port
ISP SEL On/Off
Rear panel
Power Port
USB Port
OIP Network Port
2. Installation and Connections
Use an HDMI cable to connect the video source device to the HDMI
input port on the D50E encoder.
Use an HDMI cable to connect the video display device to the HDMI
output port on the D50D decoder.
Use a network cable to connect the OIP network port of the D50E
encoder, D50D decoder, and D50C controller to the network switch
of the same domain, so that all OIP devices are in the same local
area network.
Plug the power adapter into the power ports of D50E encoder, D50D
decoder, and D50C controller and connect to the power source.
(If the network switch supports PoE (IEEE802.3af) for power supply,
power can be obtained directly through the network switch.)
※
Steps
-
can complete the signal extension. You can use the
WebGUI operation interface to control the video display device
connected to the D50C controller. You can also connect a computer
and an IR emitter/receiver. Please follow the steps below:
Connect the computer to the D50E encoder, and the controlled
device to the RS-232 port of the D50D decoder. The computer can
issue RS-232 commands to the controlled device, and the controlled
device will execute those commands.
Connect the IR emitter/receiver to the D50E encoder and D50D
decoder to receive infrared signals from the remote control, and use
the remote control to control the controlled device.
VGA display connect to D50D decoder to output analog image and
audio.
3. Control Methods
1. The WebGUI interface will be displayed on the video display device connected to the D50C controller. You can connect a keyboard and mouse to the
D50C controller to perform control and setting on the WebGUI interface.
2. Open the web browser and enter the IP address corresponding to the CTRL network port of the D50C controller to control it on the web page.
4. Suggestions for the Switch Setting
VoIP transmission will consume a lot of bandwidth (especially at higher resolutions), and it needs to be paired with a Gigabit network switch that supports
Jumbo Frame and IGMP (Internet Group Management Protocol) Snooping. It is strongly recommended to be equipped with a switch which includes
VLAN(Virtual Local Area Network) professional network management.
1. Please set Port Frame Size (Jumbo Frame) to 8000.
2. Please set IGMP Snooping and relevant settings (Port, VLAN, Fast Leave, Querier) to "Enable".
5100482-50 NOV. 2022
Quick Start Guide
r u
w
r a
a r
t n
: y
www.MyLumens.com/reg
MyLumens.com
/support
IR Input/Output
ISP Button
IR Receive Window
Reset Button
11
VGA Loopback Output Port
Loopback and Link Button
Mode and Anti-dither Button
HDMI Input
LINE Input
LINE Output
.
.
1.2 OIP-D50D Decoder Overview
Front panel
11
Rear panel
IR Output
IR Input
OIP-D50E
Monitor
VGA
Input
Digital Stereo
Output
Video/Audio
Amplifier
MIC Input
Analog Stereo
Output
Speaker
Power indicator
Reset Button
Link Indicator
Switch and Mode Button
USB 2.0 Port
Channel and Link Button
USB 1.1 Port
Channel and USB Button
MIC Input
HDMI Output
LINE Output
VGA Output
Optical Output
ISP Button
Monitor
Computer
HDMI
Input
VGA Loopback
Output
RS-232
Connection
USB
Connection
Network Switch
(Supported for PoE)
OIP-D50D
LAN
IR Input
HDMI
Output
USB Peripheral Devices
Copyright © Lumens Digital Optics Inc. All rights reserved.
www.MyLumens.com
®
11
12
IR Receive Window
IR Input/Output
11
ISP SEL On/Off
12
RS-232 Port
OIP Network Port
Power Port
Media Player
Analog Stereo
Input
Speaker
Analog Stereo
Output
LAN
-
OIP D50C
Video Display Device
RS-232
Controlled Device
Connection
IR Output
Smart TV
