2. Device Installation

This section describes the 2N
Here is what you can find in this section:
•

2.1 Before You Start

• 2.2 Mechanical Installation:
• 2.3 Electric Installation
• 2.4 Overview of Connectors
• 2.5 Overview of LED Indicators
• 2.6 RESET Button Function
• 2.7 Connection of Extending Modules
2.1 Before You Start

Product Completeness Check

Before starting the installation, check whether the 2N
items listed below:
1x
1x
2x
1x
1x
1x
1x
1x
4x
1x
1x
®
EasyGate IP product and its installation.
®
2N EasyGate IP product
1x wall / DIN rail bracket
Dowel (6 mm) with screws (4.5 x 40 mm)
Screw for fitting the device in the holder
Antenna
FXS cable
Power supply
Brief Manual
NiMH type AA, 1.2 V / min. 2000 mAh battery
2-pin terminal
3-pin terminal
