Using the Engine Start Function
IMPORTANT: Engine Start is only to be used with lead acid batteries.
1. Set up the battery charger and connect to the battery following steps 1
through 2 in the "Charging A Lead Acid Battery" section.
2. Press the Engine Start Button. The LCD Screen will display the
following*:
The Pump Engine Icon flashes. The Digital Display shows the
countdown from "60" to "00" to indicate the unit is in Engine Start
Mode. The bars on the Battery Icon will change from empty to solid
(bottom to top) repeatedly. The Clamp Icons and the Battery Icon will
light solid.
3. When "00" is reached, a beep will sound, Engine Start Icon (
light solid. The vehicle is ready to start.
4. Crank the engine using manufacturer's guidelines, typically in 3 to
5 second bursts. The Digital Display shows "5 SEC." indicating a
5-second countdown.
5. After cranking, the unit will automatically adjust the charging current
to about 2A for 5 minutes and then revert to charging mode. To stop
charging, press the charge button.
Important: The function requires a resting/cooling period between
attempts. Wait 4 to 5 minutes before a second attempt at starting the
engine, if needed.
When disconnecting charger, disconnect AC cord, remove clamp from
vehicle chassis, and then remove clamp from battery terminal.

TROUBLESHOOTING

Unit Not Charging
• Make sure all connections are secure.
• Check that the charger is properly connected to a live 120 volt AC outlet.
• If the battery to be charged has fallen below 2 volts, the battery cannot be
recharged with charger.
CARE AND MAINTENANCE
To reduce the risk of electric shock, unplug the battery charger from the
outlet before attempting any maintenance or cleaning. Turning off the
controls will not reduce this risk.
Storage
• Store the unit in a clean, dry, cool place when not in use.
• Clean the unit casing and cords (as necessary) with a dry cloth. Ensure
that unit is completely disconnected from battery and power source
before cleaning. Do not immerse the appliance in water.
• To maintain the operating condition and maximize the life of the charger
cords, always coil them loosely for storage. Do not wrap them around the
unit or crimp them with a tight band.
ACCESSORIES
Recommended accessories for use with this unit may be available from the
manufacturer. If you need assistance regarding accessories, please contact
the manufacturer at 1-877-571-2391.
WARNING:
The use of any accessory not recommended for use with
this appliance could be hazardous.
TECHNICAL ASSISTANCE
For Customer Service or Technical Assistance, contact the manufacturer at
1-877-571-2391.
ONE-YEAR LIMITED MANUFACTURER'S
WARRANTY
The manufacturer, Baccus Global LLC, warrants this product against
defects in materials and workmanship for a period of ONE (1) YEAR
commencing from the date of retail purchase by the original end-user
purchaser or from the date of delivery of the good, whichever occurs later
("Warranty Period").
If there is a defect and a valid claim is received by the manufacturer within
the Warranty Period, the defective product can be replaced in the following
ways: (1) Return the product to the manufacturer for replacement. Proof of
purchase may be required by manufacturer. (2) Return the product to the
retailer where product was purchased for an exchange (provided that the
store is a participating retailer). Returns to retailer should be made within
the time period of the retailer's return policy for exchanges only. Proof of
purchase may be required. Please check with the retailer for their specific
return policy regarding returns that are beyond the time set for exchanges.
This manufacturer's warranty does not apply to accessories, bulbs, fuses
and batteries; defects resulting from normal wear and tear, accidents;
damages sustained during shipping; alterations; unauthorized use; neglect,
misuse, abuse; and failure to follow instructions for care and maintenance
for the product.
) will
This manufacturer's warranty gives you, the original retail purchaser, specific
legal rights and you may have other rights which vary from state to state
or province to province. This product is not intended for commercial
use. To register your product with the manufacturer, please visit www.
BaccusGlobal.com.
The photos in this manual may differ from the actual unit.

SPECIFICATIONS

Input:
Output:
225 NE Mizner Blvd., Suite 301, Boca Raton, FL 33432
120V AC, 60Hz, 245W
12V DC, 15A
50 Amp Engine Start (5 Seconds on, 5
Minutes off) (for lead acid battery only)
Imported by Baccus Global LLC,
www.Baccusglobal.com 1-877-571-2391
RD050824
