First Aid - Vector VECBC50 Instruction Manual

• Vehicles that have on-board computerized systems may be damaged if
vehicle battery is jump-started. Before jump-starting, read the vehicle's
owner's manual to confirm that external-starting assistance is suitable.
• When working with lead acid batteries, always make sure someone is
close enough to provide immediate assistance in case of accident or
emergency.
• Always have protective eyewear when using this product: contact with
battery acid may cause blindness and/or severe burns. Be aware of first
aid procedures in case of accidental contact with battery acid.
• Have plenty of fresh water and soap nearby in case battery acid contacts
skin.
• If battery acid contacts skin or clothing, wash immediately with soap and
water for at least 10 minutes and get medical attention immediately.
• Never smoke or allow a spark or flame in vicinity of vehicle battery, engine
or battery charger.
• Remove personal metal items such as rings, bracelets, necklaces and
watches when working with a lead acid battery. A lead acid battery can
produce a short circuit current high enough to weld a ring, or similar metal
object, to skin causing a severe burn.
• Be extra cautious to avoid dropping a metal tool onto the battery. It might
spark or short-circuit the battery or another electrical part, and that may
cause an explosion.
• Never allow battery acid to come in contact with this unit.
• Do not operate this unit in a closed area or restrict ventilation in any way.
• Always turn the battery charger off by unplugging it when not in use.
• Do not open the BATTERY CHARGER — there are no user-serviceable
parts inside. Opening the battery charger will void the manufacturer's
warranty.
• Operate battery charger only as described in this Instruction Manual.
• Check battery charger and components periodically for wear and tear. Do
not disassemble the unit.
SPECIFIC SAFETY INSTRUCTIONS FOR
LITHIUM LIFEPO4 BATTERIES
Lithium charge mode is designed for lithium LiFePO4 batteries only.
WARNING: Use this mode with extreme care. This mode should only
be used with 12V lithium LiFePO4 batteries that have a built-in battery
management system (BMS). Lithium LiFePO4 batteries are made and
constructed in different ways and some may or may not contain a battery
management system (BMS).
• Consult the lithium LiFePO4 battery manufacturer before charging and
ask for recommended charging rates and voltages. Some lithium LiFePO4
batteries may be unstable and unsuitable for charging.
WARNING: – To reduce the risk of fire, electric shock, burst hazard, or
injury to persons or property:
• Lithium LiFePO4 batteries must be used and charged properly. Improper
use can result in serious injury, fire, or death.
• Lithium LiFePO4 batteries can explode in the presence of a source of
ignition. Do not use lithium LiFePO4 battery in the presence of an open
flame.
• Do not place this lithium LiFePO4 battery unit in fire or apply heat to it.
• Do not subject lithium LiFePO4 battery to strong impacts or shocks. Or it
may cause the battery to generate heat, rupture or ignite.
• Do not expose lithium LiFePO4 battery to water or salt water, or allow the
battery to get wet.
• Avoid storing lithium LiFePO4 battery in the basement, bathroom or
other areas of the house that are or may become wet or humid or where
moisture may concentrate.
• Do not leave lithium LiFePO4 battery in direct sunlight, or use or store it
inside cars in hot weather. Doing so may cause the battery to generate
heat, rupture, or ignite.
• Never charge lithium LiFePO4 battery near heat or flammable objects.
WARNING: NEVER THROW WATER ON A BURNING LITHIUM LiFePO4
BATTERY! If a lithium LiFePO4 battery does catch on fire, it will burn even
more violently if it comes in contact with water or even moisture in the air. A
fire extinguisher must be used.

FIRST AID

• Skin: If battery acid comes in contact with skin, rinse immediately with
water, then wash thoroughly with soap and water. If redness, pain, or
irritation occurs, seek immediate medical attention.
• Eyes: If battery acid comes in contact with eyes, flush eyes immediately,
for a minimum of 15 minutes and seek immediate medical attention.
• LCD liquid crystal display: If liquid crystal comes in contact with your
skin: Wash area off completely with plenty of water. Remove contaminated
clothing. If liquid crystal gets into your eye: Flush the affected eye with
clean water and then seek medical attention. If liquid crystal is swallowed:
Flush your mouth thoroughly with water. Drink large quantities of water
and induce vomiting. Then seek medical attention.
WARNING –
To reduce the risk of injury: Follow these instructions
and those published by the battery manufacturer and manufacturer of any
equipment you intend to use with this unit. Review cautionary markings on
this product and on engine.
SAVE THESE
INSTRUCTIONS
INTRODUCTION
Congratulations on purchasing your Vector
Instruction Manual and follow the instructions carefully before using
your new battery charger.
PREPARING TO CHARGE A LEAD-ACID
BATTERY
1. Be sure area around battery is well ventilated while battery is being
charged.
2. Remove battery completely from boat/airplane or any confined area
before charging.
3. If it is necessary to remove battery from vehicle to charge, or to clean
terminals, always remove grounded terminal from battery first. Make
sure all accessories in the vehicle are off, so as not to cause an arc.
4. Clean battery terminals, taking care to avoid getting corrosive material
in eyes.
5. Add distilled water in each cell until battery acid reaches level specified
by battery manufacturer. This helps purge excessive gas from cells. Do
not overfill. For a battery without cell caps (maintenance free), carefully
follow manufacturer's charging instructions.
6. Study all battery manufacturer's specific precautions, such as removing
or not removing cell caps while charging, and recommended rates of
charge.
7. Determine voltage of battery to be charged by referring to the vehicle
manual. The unit is for charging a 12 volt battery only.
Charger Location
• Locate charger as far away from battery as cables permit.
• Never place charger directly above battery being charged; gases from
battery will corrode and damage charger.
• Never allow battery acid to drip on charger when reading gravity or filling
battery.
• Never operate charger in a closed-in area or restrict ventilation in any way.
• A marine (boat) battery must be removed and charged on shore. To
charge it on board requires equipment specifically designed for marine
use. This unit is NOT designed for such use.
• Do not set a battery on top of charger.
Connection Precautions
• Never allow clamps to touch each other.
• Attach clamps to battery and chassis as indicated in "Charging a battery
installed in a vehicle" steps 5 and 6, or in "Charging a battery that has
been removed from a vehicle" steps 2 to 5.
Charging a battery installed in a vehicle
WARNING –
A spark near the battery may cause an explosion.
To reduce risk of a spark near the battery:
1. Position AC and clamp cords to reduce risk of damage by hood, door,
or moving engine part.
2. Stay clear of fan blades, belts, pulleys, and other parts that can cause
injury to persons.
Battery Charger. Read this
®
5
