hager 2930 Installation Instructions

2930 CYL for cylindrical
locksets and Hager
mortise exit device
with 1/2" to 3/4" latch.
Hager 2930 heavy duty electric strikes
are designed for use with cylindrical and
mortise locksets and mortise exit
devices. Several faceplate configurations
eliminate the need for centerline
relocation, making them perfect for new
or retrofit construction.
Warnock Hersey Tested according to: Warnock Hersey Tested according to:
UL 10C, 3 Hr Fire Rated (Fail-Secure only). UL 10C, 3 Hr Fire Rated (Fail-Secure only).
UL Tested according to: UL Tested according to:
UL 1034 Burglary-Resistant UL 1034 Burglary-Resistant
OPERATION: OPERATION:
Fail-Secure (Power-to-Unlock): Unlocked when Fail-Secure (Power-to-Unlock): Unlocked when
energized. energized.
Locked when de-energized and during power failure. Locked when de-energized and during power failure.
Application: For non fire rated and fire rated doors Application: For non fire rated and fire rated doors
(exception, may not be used on stairwell doors). May (exception, may not be used on stairwell doors). May
not be maintained in the unlocked (energized) state not be maintained in the unlocked (energized) state
when used with fire rated doors. when used with fire rated doors.
Rev 3, Rev Date: 3/14/22
INSTALLATION INSTRUCTIONS
2930 ELECTRIC STRIKE
2930 MOR For mortise
locksets with up to a 3/4"
Strike Input - Minimum Wire Gauge Requirements Strike Input - Minimum Wire Gauge Requirements Strike Input - Minimum Wire Gauge Requirements
Voltage Voltage 100 ft 100 ft
12VDC 12VDC 18 Ga 18 Ga
24VDC 24VDC 18 Ga 18 Ga
Always visit www.hagerco.com for the latest Installation Instructions
HAGER COMPANIES 139 Victor Street, St. Louis, MO 63104 • (800) 325-9995
latch
OPTIONAL MONITORING OUTPUTS:
DSM (Door Secure Monitor)
Signals keeper is closed and deadlocked and/or
unlocked.
LBM (Latch Bolt Monitor)
Signals latch is extended into strike and/or retracted.
DBM (Deadbolt Monitor)
Signals deadbolt is extended into strike and /or
retracted.
150 ft 150 ft 200 ft 200 ft 250 ft 250 ft
16 Ga 16 Ga 14 Ga 14 Ga 14 Ga 14 Ga
18 Ga 18 Ga 18 Ga 18 Ga 16 Ga 16 Ga
Monitoring outputs: Minimum 22 Gage wire
recommended
Use Voltage Regulator EPA300 for all Fail Safe
applications.
Fail-Safe (Power-to-Lock): Locked when energized. Fail-Safe (Power-to-Lock): Locked when energized.
Unlocked when de-energized and during power failure. Unlocked when de-energized and during power failure.
Application: Non-fire rated doors only. Application: Non-fire rated doors only.
CAUTION: Fail-safe is not permitted with the UL Fire CAUTION: Fail-safe is not permitted with the UL Fire
Door Accessory label. Door Accessory label.
2930 Electric Strike
Installation Instructions
I-EA00076
2930 MDB for mortise
locksets with latch and
deadbolt
300 ft 300 ft
--- ---
16 Ga 16 Ga
