9458 Series Privacy Barn Door Lock Set Parts List:
(With Face Fixing Trim Plate)
7
8
10
9
11
Wall Conditions and Tools Suggestion
Most of the drywall will have corner bead in steel or vinyl; it's strongly recommended to use Hole Saw to cut the holes for installing locks and
trim plates. Hole Saw for steel will also help cutting through any screws inside drywall or wood stud to make the installation job run faster.
DO NOT USE:
Spade Bit
94582D-BLK, 945835-BLK, 94582D-32D, 945835-32D, 94582D-10B, 945835-10B
5
3
4
6
1
Recommend to Use:
INSTALLATION INSTRUCTIONS
Installation based on barn door application where doors are hung on the
OUTSIDE of the room.
Install Lock Inside the Jamb Wall behind the barn door
-
Install Trim Plate on the Jamb Wall facing the opening
-
Install Strike with an emergency release on the barn door
-
Adjustable Strike for door thickness from 1-3/8" to 2-1/4".
-
Works with 9400 stainless steel round track, Conestoga, and eConestoga
-
barn door series.
Wall Thickness:
LOCK BOLT NO.
BACKSET
9458-2D
2-1/4"
9458-35
3-1/2"
Items
Trim Parts
Strike
Others
2
Stud Finder
Level
9458 Privacy Barn Door Lock
WALL THICKNESS
TYPICAL WALL STUDS
4-1/2"+
2 x 4
6-1/2"+
2 x 6
No.
Parts Description
1
Face Fixing Trim with spindle
2
M4 x 50 Slotted Head Screws
3
Barn Door Lock
4
M4 x 40 Wood Screws
5
Lock Bracket
6
Dust Proof Strike
7
Washer
8
Sleeve
9
Hollow Screw
10
Decorative Cap
11
Emergency Key
-
Door Prep Template
-
Installation Instruction
Hole Saw
2-1/8"
1-1/4"
1"
T-Square
I-SD00383
Function
Privacy
1 EA
2 EA
1 EA
2 EA
1 EA
1 EA
2 EA
1 EA
1 EA
1 EA
1 EA
1 EA
1 EA
1/8" Drill Bit
1/4" Drill Bit
