Remote Control Syntax V4
Co mmand format: VSET<X>:<NR2>
1. VSET: Command header
2. X: output channel
3. Separator
4. NR2: parameter
Command Details:
1. ISET<X>:<NR2>
Description: Sets the output current.
Example: ISET1:2.225
Sets the CH1 output current to 2.225A
2. ISET<X>?
Description: Returns the output current setting.
Example: ISET1?
Returns the CH1 output current setting
3. VSET<X>:<NR2>
Description: Sets the output voltage.
Example: VSET1:20.50
Sets the CH1 voltage to 20.50V
4. VSET<X>?
Description: Returns the output voltage setting.
Example: VSET1?
Returns the CH1 voltage setting.
5. lOUT<xX>?
Description: Returns the actual output current.
Example: lOUT1?
Returns the CH1 output current
6. VOUT<X>?
Description: Returns the actual output voltage.
Example: VOUT1?
Returns the CH1 output voltage
7. BEEP<Boolean>
Description: Turns on or off the beep. Boolean: boolean logic.
Example: BEEP1 Turns on the beep.
8. OUT<Boolean>
Description: Turns on off the output.
Boolean: 0 OFF, 1 ON
Example: OUT1 Turns on the output
9. STATUS?
Description: reading the status of the power supply returning
Contents: 8 bits follow the below formats
Bit Content Description
0 CH! 0=CC mode, 1=CV mode
1 CH2 0=CC mode, 1=CV mode
2,3 Tracking 01=independent, 11=serial connection, 10=parallel connection
4 Beep 0=OFF, 1=ON
5 OCP 0=OCP OFF, 1=OCP ON
