Front Panel Overview

The upper computer sends instructions
Slave Function Set an
Address Code address
01H 01H 0000H
01H 05H 0001H
01H 03H 0000H
Newark.com/multicomp-pro
Farnell.com/multicomp-pro
sg.element14.com/b/multicomp-pro
Data length/setting
CRCL CRCH
content
N-16bit
FF00H
N-16bit
Page <4>
Function: read machine status
Address:000H-CC/CV
0001H-ON/OFF indicates the output
0004H- beep
0005H-LOCK indicates the lock
0006H-OVP
0007H-OCP
QO0AH-SENSE external compensation
O00CH-ON/OFF external switch
Function: set machine status
Address: 0001H-ON/OFF indicates the output
0004H-beep
0005H-indicates the lock
Q006H-OVP ON/OFF
XXH XXH
0007H-OCP ON/OFF
0008H- indicates the AUTO mode
QO0AH-SENSE external compensation
O00CH-ON/OFF external switch
Setting content: FFOOH-turning ON
0000H-tuming OFF
Functionn: read the voltage and current
values of the device
Address: 0000H-0001H output voltage
0002H-0003H output current
0004H-0005H set voltage
0006H-0007H set current
0008H-0008H set OVP
OQ0AH-000BH set OCP
Instructions
