- Page 1 Manual V1.0 2024.05 www.toolkitrc.com ToolkitRC Technology (Shenzhen) Co., Ltd @ToolkitRC 2024...
-
Page 2: Introduction
Introduction Thank you for purchasing the M8D balance charger, please read this manual carefully before use. Key Points Tips Important Information Further information To ensure you have the best experience with this product please scan the QR code below to stay up to date with news, information and firmware updates for your charger. -
Page 3: Safety
Safety M8D allows an input voltage of DC 10.0V-49.0V. To ensure that the power supply voltage is consistent, pay attention to the positive and negative polarity of the power supply before use. Do not use this product in hot or humid environments, Keep away from flammable liquids and gases. -
Page 4: Table Of Contents
Introduction ............... 2 Key Points ................2 Further information ............2 Safety.................. 3 Contents ................4 M8D Layout ............... 6 Quick start ................7 Charging settings .............. 9 1，Battery type ..............9 2，Number of cells ............12 3，Mode ................13 4，End voltage setting（TVC）... - Page 5 Product description M8D is a touch screen balanced charger product, the total charging power can reach 1600W, using IPS bright display, capacitive touch screen plus roller encoder coexist, more convenient operation. Charge, discharge and balance management of LiPo, LiHV, LiFe, Lion LTO 1-8S, NiMh 1-20S, PB 1-15S batteries.
-
Page 6: M8D Layout
M8D Layout Display/Touch panel CH/ Exit Main port*2 Balance port*2 Scroll wheel Front DC input XT90 USB A/C output Cooling fan Back @ToolkitRC 2024... -
Page 7: Quick Start
[Info] button to display the voltage and internal resistance in the corresponding channel. 7. Touch [Status], short press [Scroll Wheel] to select [Status], or touch [Status] to select the charging task when the channel is idle. You can adjust and end the @ToolkitRC 2024... - Page 8 1. Short press [Scroll Wheel] once to confirm the function. 2. Long press [Scroll Wheel] for 2 seconds, it is the delete key function. 3. If any key is successfully operated, there will be a didi sound. =================================== @ToolkitRC 2024...
-
Page 9: Charging Settings
Otherwise, it will default to the first battery record, skip this step. 1，Battery type Select the battery that has been set, or press [New Battery], select the battery number to enter the new battery setting interface, which is displayed as follows. @ToolkitRC 2024... - Page 10 [Modify] to modify the battery type, which is displayed as follows. The charger supports charging 7 kinds of batteries: LiPo, LiHV, LiFe, Lion, LTO, NiMH, and PB. after selecting the battery that matches the actual battery. Press [Confirm] takes effect and rewinds to the previous page. @ToolkitRC 2024...
- Page 11 5, LTO: often referred to as a lithium-ion battery with a nominal voltage of 2.40V and a fully charged battery of 2.70V. 6, NiMh: often referred to as nickel-hydrogen battery, nominal voltage 1.20V. 7, PB：often called lead-acid battery, nominal voltage 2.00V. ================================================== @ToolkitRC 2024...
-
Page 12: 2，Number Of Cells
2, incorrectly set the number of strings, you may not be able to charge the batteries, or overcharging damage to the batteries, please be @ToolkitRC 2024... -
Page 13: 3，Mode
± 50mV of the full voltage. When the working mode is discharging, it is discharging cut-off voltage. Select the voltage adjustment value, step increment of 0.01V. @ToolkitRC 2024... - Page 14 2, Do not modify the cut-off voltage when you are not familiar with the battery characteristics. 3, The charging cut-off voltage can be set to a range of ±50mV of full voltage. 4, TVC: Abbreviation for Terminal Voltage Control ================================================== @ToolkitRC 2024...
-
Page 15: 5，Charging Current
Please set the charging rate of 1-2C according to the battery capacity. For example, if the battery capacity is 2000mAh, please set the charging current to 2.0-4.0A. Check the guidelines of your battery’s manufacturer for correct charging instructions. ================================================== @ToolkitRC 2024... -
Page 16: 6，Nimh Setting (Peakv)
3mV-15mV, as shown below: ================================= Tips 1, Only NiMh battery can set the battery negative pressure value. 2, Vocabulary explanation: PeakV: When the NiMH battery is fully charged, the voltage drop peak value of each cell. ================================= @ToolkitRC 2024... -
Page 17: Charging
Select [Status Bar] to dynamically set the working current or stop working. As shown in the figure below @ToolkitRC 2024... - Page 18 10:59: First channel working hours. 2000mAh: the cumulative capacity of the first channel. 1 4.200V: The first battery voltage ..4.200V: The fourth battery voltage (Red mark means this battery is under balance management) -.--V: No battery connected. @ToolkitRC 2024...
- Page 19 When setting to automatically detect the battery string number, please pay attention to whether the detected cell number matches the actual number. ================================= @ToolkitRC 2024...
-
Page 20: System Settings
Only when the input was set to battery. Power Selection: When this setting is turned on, each time charger power on it prompts you to select a power unmber. Max power: the maximum power absorbed from the @ToolkitRC 2024... - Page 21 Synchronous mode: After turning on this function, the two channels can be combined with the main port to charge the same battery, and the maximum current can reach 50A. Continuous Operation: After turning on the function, remove the full charged battery, and after connecting @ToolkitRC 2024...
- Page 22 Manual Calibration: When the voltage display deviates from the actual voltage of the battery, this function can be selected to calibrate the voltage values of the two channels. Default: restore all settings to factory values. ID: the unique ID of the device factory settings. @ToolkitRC 2024...
-
Page 23: Other Functions
Make it less noisy when operating at low temperatures or low power. 4, USB fast charging M8D built-in USB fast charging protocol, up to C port up to 65W charging power, supported protocols are PD, QC, AFC, FCP , SCP , PE, SFCP , VOC. - Page 24 Prevents the risk of combustion due to residual voltage after discarding. ================================================= Warning: 1, The battery in normal use cannot use this function, and the battery can be emptied by using the destroy function, causing irreversible damage. =================================== @ToolkitRC 2024...
-
Page 25: Specification
0.1-30.0A@800W*2 Recycle Charging Power 0.1-10A@40W*2 Normal USB-C 20V@65W or upgrade PD,QC,AFC,FCP,SCP,PE,SFCP,VOC Battery 1.0V-5.0V @1-8S Voltage Battery Internal 1-100mR @1-8S Resistance Display IPS 3.5 inch 480*320 Pixel Touch Capaticive Size 130mm*97mm*42mm Product Weight 450g Size 140mm*110mm*500mm Individual Packing Weight 700g @ToolkitRC 2024...
