Page 1 F400/FS400 User guide ENABLING BRIGHT OUTCOMES...
Page 2 Product revision Firmware: Pulse 2.4.x...
Page 3 Barco. If the purchaser or a third party carries out modifications or repairs on goods delivered by Barco, or if the goods are handled incorrectly, in particular if the systems are operated incorrectly or if, after the transfer of risks, the goods are subject to influences not agreed upon in the contract, all guarantee claims of the purchaser will be rendered invalid.
Page 4 Furthermore, strengthen your network security to protect the projector against unauthorized access by third parties. To the maximum extent permitted by law, Barco disclaims any liability for the use of the projector in an open network environment.
Page 5: Table Of Contents
Pulse RCU, silicone protection sleeve (optional)......................31 3 Input & Communication ...................................33 Introduction......................................34 Mains power requirement................................34 Input & communication panel..............................34 Making connections..................................35 Control interface ....................................35 LED and Button indication chart .............................36 Pulse Quad DP 1.2 input ................................37 4 Getting started......................................39 Projector orientation ..................................40 R5915525 /01 F400/FS400...
Page 6 8 GUI – Installation ....................................85 Position.........................................86 8.1.1 Orientation ..................................86 8.1.2 Projector tilt indication ..............................87 Lens........................................88 8.2.1 Configuring the lens, optical zoom and focus .....................88 8.2.2 Configuring the lens, shift............................88 8.2.3 Configuring the lens, Shift to center .........................89 8.2.4 Iris ......................................90 R5915525 /01 F400/FS400...
Page 7 Projector address.......................... 134 10.1.1.3 IR sensors ............................135 10.1.2 Host name - custom projector name setup....................136 10.1.3 LAN Communication .............................. 137 10.1.3.1 Introduction to a Network connection ................137 10.1.3.2 Wired IP address set up ......................138 R5915525 /01 F400/FS400...
Page 8 How infrared is displayed ................................ 184 Default setup ....................................184 Cloned image with full RGB input ............................185 Cloned inputs with only green content for IR........................ 186 C Advanced blend ....................................187 Advanced blend, file creation..............................188 R5915525 /01 F400/FS400...
Page 9 User interface....................................191 D Specifications ......................................195 Specifications of F400–4K..............................196 Specifications of FS400–4K..............................197 Specifications of F400–N4K ..............................199 Specifications of FS400–N4K ............................... 200 Dimensions of a F400................................202 E Regulatory information................................. 203 Product compliance..................................204 Disposal information................................... 205 China RoHS compliance................................
Page 10 R5915525 /01 F400/FS400...
Page 11: Safety
Ensure that you understand and follow all safety guidelines, safety instructions and warnings mentioned in this chapter before installing the F400 projector. Clarification of the term “F400” used in this document When referring in this document to the term “F400” means that the content is applicable for following Barco products: •...
Page 12: General Considerations
• All warnings on the projector and in the documentation manuals must be adhered to. • Installation and preliminary adjustments must be performed by qualified Barco personnel or by authorized Barco service dealers. • This product contains no user serviceable parts. Attempts to modify/replace mechanics or electronics inside the housing or compartments will violate any warranties and may be hazardous.
Page 13: Important Safety Instructions
Should any liquid or solid object fall into the cabinet, unplug the set and have it checked by qualified service personnel before resuming operations. • Do not disassemble this projector, always take it to an authorized trained service person when service or repair work is required. R5915525 /01 F400/FS400...
Page 14 (See chapter “Available lenses” in the installation manual), refer to chapter “High Brightness Precautions”, for information regarding precautions. • FOR PROFESSIONAL USE ONLY means installation can only be carried out by Barco AUTHORIZED PERSONNEL familiar with potential hazards associated with high intensity light beams. •...
Page 15 Never use water on an electrical fire. • Always have service performed on this projector by qualified service personnel. Always insist on genuine Barco replacement parts. Never use non-Barco replacement parts as they may degrade the safety of this projector. •...
Page 16 Safety dropped inside the projector. If this does happen, switch off and unplug the mains supply immediately. Do not operate the projector again until it has been checked by Barco authorized service personnel. • Do not block the projector cooling fans or free air movement around the projector. Minimum safety distance to the exhaust area of the unit must not be less than 25 cm (10”) and to the intake area, not less than 25...
Page 17: Product Safety Labels
Safety Safety Data Sheets for Hazardous Chemicals For safe handling information on chemical products, consult the Safety Data Sheet (SDS). SDSs are available upon request via safetydatasheets@barco.com. 1.3 Product safety labels Light beam related safety labels Safety labels explanation and location: Hazard RG3: Not for household use symbol.
Page 18: High Brightness Precautions: Hazard Distance
3.0 meter to prevent potential exposure, for example by an individual sitting on another individual's shoulders, within the HD. Sufficiently large separation height may be achieved by mounting the image projector on the ceiling or through the use of physical barriers. R5915525 /01 F400/FS400...
Page 19 0 meter if the height of the hazard zone is minimum 2.5 meter. • 0.1 meter if the height of the hazard zone is minimum 2.4 meter. • 0.6 meter if the height of the hazard zone is minimum 2.2 meter. R5915525 /01 F400/FS400...
Page 20: Hd For Fully Enclosed Projection Systems
The LIP shall be installed by Barco or by a trained and Barco-authorized installer or shall only be transferred to laser light show variance holders. This is applicable for dealers and distributors since they may need to install the LIP (demo install) and/or they transfer (sell, rent, lease) the LIP.
Page 21: Hd In Function Of Modifying Optics
10 cm. The HD can be neglected if the measured light at the screen surface is below 5000 diffuse cd/m² or 15000 LUX. 1.6 HD in function of modifying optics Hazard Distance Image 1–4 Hazard Distance Throw Ratio R5915525 /01 F400/FS400...
Page 22: Hd Calculation Of Multi-Projector Stacks
Bracknell RG12 8PE, Berkshire, United Kingdom 1.9 Download Product Manual Download Product Manual Product manuals and documentation are available online at www.barco.com/td. Registration may be required; follow the instructions given on the website. IMPORTANT! Read Installation Instructions before connecting equipment to the mains power supply.
Page 23: Remote Control Unit
Pulse RCU, function of the “RGB filter” button .................30 Pulse RCU, functions of the “Projector OSD on/off” button ...............30 2.10 Displaying and Programming addresses into the RCU..............30 2.11 Using the mini-jack connector of the RCU..................31 2.12 Pulse RCU, silicone protection sleeve (optional) ................31 R5915525 /01 F400/FS400...
Page 24: Basic Remote Control Unit
About the basic remote In order to make sure you can control your projector remotely, Barco has provided a basic remote control unit in case the Pulse RCU is not available to you. While this remote control has a more limited amount of available features, it will be able to help you out with basic controls.
Page 25: Pulse Rcu, Battery Installation
Push the battery cover tab with the fingernail a little backwards (1) and pull, at the same time, the cover upwards (2). Image 2–2 Insert the two AA size batteries, making sure the polarities match the + and - marks inside the battery compartment. R5915525 /01 F400/FS400...
Page 26: Pulse Rcu, Protocol Setup
Depending on the projector, the remote control can be switched between these protocols. Which protocol to use • The NEC protocol must be used for Barco projectors based on the Pulse platform: F70, F80, F90, HDX 4K, UDX, UDM, XDL, F40, F400, etc. •...
Page 27: Pulse Rcu, Function Of The On/Off Button
Remarks when using the RC5 protocol Due to new or updated functionality not all buttons of the Pulse RCU are one-to-one compatible with the legacy Barco RCU and projectors. Take the following limitations into account: • Buttons Shutter open and Shutter close emit the same code when in RC5 mode. This because the legacy RCU’s only had 1 button for Shutter functionality.
Page 28: Using The Rcu
The RCU will not function properly if strong light strikes the IR sensor window or if there are obstacles between the RCU and the IR receiver. Image 2–7 The RCU can also hard-wired been used. See chapter “Using the mini-jack connector of the RCU”, page R5915525 /01 F400/FS400...
Page 29: Pulse Rcu, Functionality Overview
Continuously lit (up to 5 seconds) when address digits are expected after pressing the ADDR button. • Slowly flashes (2 times a second) when the battery level is becoming low; typically when more than 85% of the useful life is past. R5915525 /01 F400/FS400...
Page 30: Pulse Rcu, Function Of The "Rgb Filter" Button
Press the Address button until the Button pressed indicator lights up continuously (proximately 5 seconds). Enter the address with the digit buttons within the time the indicator lights up (also proximately 5 seconds). Note: That address can be any value between 0 and 31. R5915525 /01 F400/FS400...
Page 31: Using The Mini-Jack Connector Of The Rcu
(optional) Introduction Barco offers a silicone form fitting protection sleeve for the Pulse RCU. The silicone material keeps it comfortably, non slip and soft touch. All buttons and openings remain accessible. The sleeve is quick and easy installed. For ordering information see Barco website.
Page 32 Remote Control Unit Image 2–11 R5915525 /01 F400/FS400...
Page 33: Input & Communication
Input & Communication Introduction ..........................34 Mains power requirement ......................34 Input & communication panel......................34 Making connections ........................35 Control interface ...........................35 LED and Button indication chart.....................36 Pulse Quad DP 1.2 input .......................37 R5915525 /01 F400/FS400...
Page 34: Introduction
The AC supply must be installed by a qualified electrician in conformance to local codes. Hardware, wire sizes and conduit types must comply with local codes. 3.3 Input & communication panel Overview WIRED REMOTE OUT1 OUT2 SYNC SYNC (1A) 12V DC TRIGGER HDMI SYNC I O Image 3–2 R5915525 /01 F400/FS400...
Page 35: Making Connections
Capability of a connector to accept HDCP content (revision v1.X or v2.X) can vary and depends of the FPGA resource mapping that manage connectors. Please refer to the Home/Source menu to obtain this information. 3.5 Control interface Parameter Value Ethernet connector 1x RJ45 connector for projector control Protocols DHCP, TCP/IP, UDP/P Speed 10/100/1000 Mbit R5915525 /01 F400/FS400...
Page 36: Led And Button Indication Chart
Standby mode. Solid WHITE Projector is ON, shutter is open Solid RED Projector is ON, shutter is closed LED Status WIRED REMOTE OUT1 OUT2 SYNC SYNC (1A) 12V DC TRIGGER HDMI SYNC I O Image 3–3 LED status R5915525 /01 F400/FS400...
Page 37: Pulse Quad Dp 1.2 Input
The SYNC LED lit up ORANGE when valid input sync is detected. • The SEL LED lit up GREEN when the input is selected. For specifications about the supported inputs for DisplayPort 1.2 see chapter “Video timing tables”, page 209. R5915525 /01 F400/FS400...
Page 38 Input & Communication R5915525 /01 F400/FS400...
Page 39: Getting Started
Local Keypad and LCD panel ......................41 Power modes ..........................42 Power mode transitions.........................42 Status overview ..........................44 Power off projector........................45 Increasing the projector lifetime .....................45 Operation in 24/7 Mode.........................46 4.10 Projector Address .........................46 4.11 Quick setup via Direct access ......................46 R5915525 /01 F400/FS400...
Page 40: Projector Orientation
The projector orientation in this manual refers to the left and right side corresponding with the left and right hand when standing behind the projector and look forward in the projection direction. Image 4–1 Rear side Left side Right side Front Bottom 4.2 Projector overview Components Image 4–2 R5915525 /01 F400/FS400...
Page 41: Local Keypad And Lcd Panel
The keypad has a backlight that can be switched on and off manually. By default the light turns off after 5 minutes. The Power and Shutter buttons are equipped with white, blue and red backlit LEDs. The other keys are only equipped with white and blue backlit LEDs. The LEDs are controlled according to the features available. R5915525 /01 F400/FS400...
Page 42: Power Modes
In standby ECO mode, remote power up (Wake-on-LAN) and local power up (button) are supported. 4.5 Power mode transitions 4.5.1 General Transition Diagram This diagram shows all modes available on the projector (unplug, ON, READY, ECO), and the actions necessary to change mode. R5915525 /01 F400/FS400...
Page 43: Power On Projector
Press and hold the Power on/off button on the projector for 3 seconds, or press the Power Off button on the remote control. The projector will power down through a cool down phase. The Power on/off button will BLINK R5915525 /01 F400/FS400...
Page 44: Going From Ready To Standby Eco
Device serial number and article number • Current firmware version and model name • Current illumination (in percentage) • Lamp runtime in hours • Chosen communication method and IP address (if connected) • Warp status • Environmental temperature R5915525 /01 F400/FS400...
Page 45: Power Off Projector
CAUTION: Never switch off the projector by means of unplugging mains cord or by cut down of mains power. Barco advises to keep the projector always powered and use the ECO mode for low power consumption. How to unplug the projector Follow the procedure above to Switch Off the projector.
Page 46: Operation In 24/7 Mode
Placing new batteries in the remote control or plugging the remote to a projector via a cable will automatically reset the address back to its default value '0'. 4.11 Quick setup via Direct access Quick source selection Press the Input button on the remote control or local keypad. R5915525 /01 F400/FS400...
Page 47 Getting started Image 4–7 The Source selection menu opens on the LCD display. Image 4–8 Example of the input selection menu Image 4–9 Use the arrow keys to select the desired source. R5915525 /01 F400/FS400...
Page 48 Quick test pattern selection Press the Test pattern button on the remote control or local keypad. Image 4–10 The Test pattern menu opens on the LCD display. Use the arrow keys to select the desired test pattern. R5915525 /01 F400/FS400...
Page 49: Gui - Introduction
GUI — Introduction Overview .............................50 Navigation............................52 Test Patterns ..........................54 About this chapter This chapter gives a general overview of the Graphic User Interface. R5915525 /01 F400/FS400...
Page 50: Overview
Notifications: The error and/or warning messages that are currently active. If no messages are active, this list will be empty. • Preview: A preview pane of the projected image. If no image is being projected, a test image is displayed instead. R5915525 /01 F400/FS400...
Page 51 The projector software platform uses access levels what each user can do. A standard user has access to the standard projector functionality. A certified service technician has also access to the advanced settings menu. This menu is password protected. This password can only be obtained by following the service partner training. R5915525 /01 F400/FS400...
Page 52: Navigation
Not visible on F80 Only visible when logged in Only available on “stealth” variant projectors 5.2 Navigation Navigation via the RCU or local keypad Navigating the OSD can be done using the remote control or the local keypad. R5915525 /01 F400/FS400...
Page 53 OK 79 OK. Within an input field, use the * button as backspace button to remove an entered digit. Use the # button to enter a dot (.). Changes to values are implemented dynamically. R5915525 /01 F400/FS400...
Page 54: Test Patterns
• Color gradients • Checkerboard • Cross hatch • Geometry • Horizontal gray bars • Vertical gray bars • 3D Stereo About the test pattern types There are three types of test patterns possible in the projector: R5915525 /01 F400/FS400...
Page 55 Push the Test Patterns button on the RC. Image 5–7 Main menu, Test patterns In the Test pattern menu, select the desired test pattern from the list. To turn the test pattern off, select off instead. Image 5–8 Test patterns menu, test pattern off R5915525 /01 F400/FS400...
Page 56 GUI — Introduction R5915525 /01 F400/FS400...
Page 57: Gui - Source
GUI – Source Displaying a single source ......................58 Displaying multiple sources: Stitched layouts ..................58 Connector Settings ........................60 No source image ..........................62 About the Source menu This menu is used to select, review and configure sources into the projector. R5915525 /01 F400/FS400...
Page 58: Displaying A Single Source
The first time you use a selected single source, the source will be displayed in the projector's native resolution. If the resolution of the source is different to the projector's resolution, the image is stretched or shrunk. R5915525 /01 F400/FS400...
Page 59 Active Stereo. Advanced image processing will make sure a passive stereo image is properly converted to active stereo. How to select a stitched layout Press Menu to activate the menus and select Source. Image 6–3 Main menu, Source Press OK. R5915525 /01 F400/FS400...
Page 60: Connector Settings
How to configure a connector Press Menu to activate the menus and select Source. Image 6–5 Main menu, Source Press OK. The Select Source menu is displayed with the actual available sources filled out. Select Connector Settings and click OK. R5915525 /01 F400/FS400...
Page 61 To set a video timing other than the one native for the connector, select one of the options under EDID. • Image adjustment override configuration. Image adjustment override To override the Image adjustments with the configured settings, enable the Image adjustments override slider. Once enabled, the override values will be used when the source is selected. R5915525 /01 F400/FS400...
Page 62: No Source Image
“Power saving settings”, page 147. How to change Press Menu to activate the menus and select Source. Image 6–10 Main menu, Source Press OK. The Select Source menu is displayed with the actual available sources filled out. R5915525 /01 F400/FS400...
Page 63 Select the desired image to project when no source image is available. When custom background images have been uploaded using an external tool, they will be listed after the predefined images. Image 6–13 Example of the No source image menu with two custom background images. R5915525 /01 F400/FS400...
Page 64 GUI – Source R5915525 /01 F400/FS400...
Page 65: Gui - Image
Adjusting the gamma correction.....................69 Setting the desired Gamma type ....................70 Tilted brightness uniformity correction ....................72 Digital shift & zoom ........................74 RealColor P7..........................77 7.10 BrilliantColor ..........................79 7.11 Smear reduction ...........................80 7.12 Displaying HDR content ........................81 7.13 Night vision ..........................83 R5915525 /01 F400/FS400...
Page 66: Adjusting The Contrast
The brightness function is used to adjust the black level of the projected image. It adds or subtracts an offset to the red, green and blue signals. Available range: -1.00 to +1.00 Default value: 0.00 How to set up Brightness Level In the main menu, select Image → Brightness. R5915525 /01 F400/FS400...
Page 67: Adjusting The Saturation
How to set up Saturation Level In the main menu, select Image → Saturation. Image 7–5 Image menu — Saturation Use the ◄ or ► key to change the saturation until the desired value is reached (adjustable between 0 and R5915525 /01 F400/FS400...
Page 68: Adjusting The Sharpness
Image 7–7 Effect of sharpness adjust How to adjust In the main menu, select Image → Sharpness. Image 7–8 Image menu – Sharpness Use the ◄ or ► key to change the sharpness until the desired value is reached. R5915525 /01 F400/FS400...
Page 69: Adjusting The Gamma Correction
Use the ▼ key to select the slider. Use the ◄ or ► key to change the gamma value between 1.0 and 2.8 . The default value is 2,2. Tip: The slider can be adjusted with a precision of 0.1. R5915525 /01 F400/FS400...
Page 70: Setting The Desired Gamma Type
HDR is dependant on extra factors such as screen luminance, a separate menu has been made available for this (PQ). If the source signal is HDR encoded an HDR icon will be visible next to the source signal. This is visible both in the Source selection menu, as well as the status menu. R5915525 /01 F400/FS400...
Page 71 The Gamma type menu is displayed. If source content is available, the detected gamma of the source will be displayed at the bottom of the menu. Image 7–14 Example of the gamma menu Use the ◄ or ► key to select the desired gamma type and confirm. R5915525 /01 F400/FS400...
Page 72: Tilted Brightness Uniformity Correction
A positive vertical correction will result in the bottom side of the screen becoming less bright than the top side. • A negative vertical correction will result in the top side of the screen becoming less bright than the bottom side. R5915525 /01 F400/FS400...
Page 73 How to adjust brightness across the screen While the projector is ON mode: In the main menu, select Image → Tilted brightness uniformity. Image 7–19 Image menu, Tilted brightness uniformity The Tilted brightness uniformity menu is displayed. R5915525 /01 F400/FS400...
Page 74: Digital Shift & Zoom
The area outside the rendered picture will then be black. For an example, see the following photos. The red lines in the figures represent the DMD outline. R5915525 /01 F400/FS400...
Page 75 This function will shift the picture digitally, meaning that the picture will be moved in any direction. As a result, some parts of the picture might be shifted outside the DMD range. For an example, see the following pictures. The red lines in the figures represent the DMD outline Image 7–24 Original Picture, not digitally shifted R5915525 /01 F400/FS400...
Page 76 Use the enter key to activate this mini-keypad. If digital shift is enabled, the keypad will transform into the keypad for digital shift. If only digital zoom is active, it will automatically transform in the keypad for digital zoom. R5915525 /01 F400/FS400...
Page 77: Realcolor P7
Alternatively, if you are unfamiliar with how to adjust the colors to a specific setting, there are also a certain number of presets available, which forces the color output to specific color standards. How to set custom P7 values In the main menu, select Image → Advanced → RealColor P7. R5915525 /01 F400/FS400...
Page 78 Note: You can only pick coordinates within the measured color triangle. You can reset all coordinates to the default values (to native) by clicking the Reset icon. How to choose one of the P7 presets In the main menu, select Image → Advanced → P7 RealColor. R5915525 /01 F400/FS400...
Page 79: Brilliantcolor Tm
Video mode, a secondary color is added (C1). This has the effect of increasing the color intensity, and by that also the perceived light intensity. How to select the BrilliantColor mode In the main menu, select Image → Advanced → BrilliantColor Image 7–35 Advanced settings menu, BrilliantColor R5915525 /01 F400/FS400...
Page 80: Smear Reduction
The amount of Smear reduction that can be achieved depends on the chosen projector type. How to activate smear reduction In the main menu, select Image → Advanced settings → Smear reduction. Image 7–37 Advanced settings, Smear reduction The Smear reduction menu will be displayed. R5915525 /01 F400/FS400...
Page 81: Displaying Hdr Content
How do I know if my content is HDR encoded? If the source signal is HDR encoded, an HDR icon will be visible next to the source signal. This is visible both in the Source selection menu, as well as the status menu. R5915525 /01 F400/FS400...
Page 82 Select the desired Screen luminance unit (nits or foot-Lambert). Enter the Screen luminance (which is measured in nits or foot-Lambert). Alter the HDR boost if necessary. You can modify this value to somewhere between 0.8 and 1.2. R5915525 /01 F400/FS400...
Page 83: Night Vision
This function is only available for the FS variants of the projector. How to swap channels Select the Menu/ Image / Advanced / Night Vision. menu Toggle the Swap channel function on / off by pressing the OK button on the remote control or the keypad. Image 7–42 R5915525 /01 F400/FS400...
Page 84 GUI – Image R5915525 /01 F400/FS400...
Page 85: Gui - Installation
GUI – Installation Position ............................86 Lens ............................88 Scaling modes..........................91 Warping ............................92 Blending & masking ........................104 CLO feature ..........................114 Illumination ..........................118 3D projection..........................119 R5915525 /01 F400/FS400...
Page 86: Position
Image 8–1 How to set the correct orientation In the main menu, select Installation → Position → Orientation. Image 8–2 Installation menu, orientation The Orientation menu is displayed. Image 8–3 Example of the orientation menu R5915525 /01 F400/FS400...
Page 87: Projector Tilt Indication
Image 8–5 Tilt sensor indication If you notice the tilt sensor isn’t working correctly (e.g. when compared to a level), you can calibrate the sensor in the settings menu. For more info, see “Advanced settings – Tilt sensor calibration”, page 164. R5915525 /01 F400/FS400...
Page 88: Lens
For the digital zoom and shift, navigate to Home → Image → Digital Zoom Shift. For more info, see “Digital shift & zoom”, page Optical lens shift is only possible when the used lens has been fully calibrated. To calibrate the lens, navigate to Settings → Maintenance → Lens Calibration. R5915525 /01 F400/FS400...
Page 89: Configuring The Lens, Shift To Center
The lens can be forced back to the center position by selecting Shift to center. How force lens in Mid position To force lens in Mid position, select Installation → Lens → Shift to center. Image 8–10 Lens menu, Shift to center Confirm by pressing the CONFIRM button. R5915525 /01 F400/FS400...
Page 90: Iris
Use the arrow keys to adjust Iris until preferred rendering is obtained. The numeric value in the menu indicates the degree of opening of the iris. Value = 0, full opening. (No iris activated). Increased numeric value indicates decreasing in the iris opening. (Iris activated). R5915525 /01 F400/FS400...
Page 91: Scaling Modes
For more info on adjusting the Screen Size menu, see “Warping – Screen size”, page Example using a screen of 2,35:1, an input signal of 4:3 and a projector with a native resolution of 3840 x 2400 R5915525 /01 F400/FS400...
Page 92: Warping
About warping on/off By toggling between on and off the warping functionality can be enabled or disabled. How to toggle In the main menu, select Installation → Warp. Image 8–15 Installation menu, warp The Warp menu is displayed. R5915525 /01 F400/FS400...
Page 93: Warping - Screen Size
Image 8–19 Warp outline example Using the Screen aspect ration presets In the main menu, select Installation → Warp → Screen Size. R5915525 /01 F400/FS400...
Page 94 The selected ratio is filled out next to Screen width and Screen height. Click Apply. How to adjust the image with pixels? In the main menu, select Installation → Warp → Screen Size. Image 8–23 Warp menu, screen size R5915525 /01 F400/FS400...
Page 95: Warping - 4 Corners Adjustment
4 corner adjustment is typically used when the mechanical installation of the projector prevents it from pointing perpendicularly at the screen. For example, you can overshoot the screen and use 4 corner adjustment to pull your projected image corners back into the screen. Some examples: R5915525 /01 F400/FS400...
Page 96 The 4 corners menu is displayed. Image 8–28 Example of the 4 corners menu To enable 4 Corners warping, enable the 4 corner slider. To have a visual representation of what your warp will look like, enable the Helper lines slider. R5915525 /01 F400/FS400...
Page 97: Warping - Bow
To reset the 4 corner adjustments, select Reset and press the OK button. 8.4.4 Warping – Bow About bow adjustment A bow distortion can be adjusted so that a normal image is displayed. Positive adjustments introduce more outside bow distortion. Negative adjustments introduce more inside bow distortion. R5915525 /01 F400/FS400...
Page 98 The bow menu is displayed. To enable bow correction, make sure the Bow slider is enabled (visible by the blue highlight). To perform a symmetric adjustment , make sure the Symmetric slider is set to On (visible by the blue highlight). R5915525 /01 F400/FS400...
Page 99 Use the arrow keys to adjust the angle and linearity (length) of the vectors. Press enter to confirm and switch between angle and length. Tip: The angle is adjusted by using the up and down arrow keys. The linearity is adjusted by using the left and right arrow keys. R5915525 /01 F400/FS400...
Page 100 There are now two vectors on each side of the picture that can be adjusted individually. Use the arrow keys to select the helping lines that represent the picture and confirm. The helping lines that represent the projected picture are now colored blue, while the others are colored white. Image 8–39 R5915525 /01 F400/FS400...
Page 101: Warping - Warp Files
XML file. Alternatively, you can contact the “file endpoint” directly via the curl program or some other tool that supports http upload. For more information on uploading/downloading Warp files using the Projector Toolset, refer to the Projector Toolset user manual. R5915525 /01 F400/FS400...
Page 102 In the Warp menu, select Warp files. Image 8–43 Warp menu, Warp files The Warp Files menu is displayed. Image 8–44 Example of the Warp files menu Make sure the Enable slider is set to right. Select the desired warp file. R5915525 /01 F400/FS400...
Page 103: Warping - Latency Control In A Multi Projector Setup
Transport delay in the status menu for each projector. Image 8–46 Example of the Transport delay in the status menu Identify the projector with the longest delay. For each projector in the setup, select Installation → Warp in the main menu. R5915525 /01 F400/FS400...
Page 104: Blending & Masking
The principle is that the light intensity in the blend zone from each projector will be adjusted individually, so that the rendering on the screen is perceived as from one projector. R5915525 /01 F400/FS400...
Page 105: Basic Blend
8.5.1 Basic blend How to set up a basic blend zone? In the main menu, select Installation → Blend and Mask → Basic blend. Image 8–51 Blend menu, Basic blend The Basic blend menu is displayed. R5915525 /01 F400/FS400...
Page 106 Use the arrow keys or remote digits to change the value of the blend zone and confirm. Repeat this process for all other desired sides. Continue by creating the blend mask. For more info, see “Blend & Blend mask”, page 107. R5915525 /01 F400/FS400...
Page 107: Blend & Blend Mask
Determine the start position of the mask (1) for the masking height and width, together with the desired size of the mask (2) to determine the width of the masked area. When the helping lines are activated, you will get a visual indication of the screen of the installed blending area. R5915525 /01 F400/FS400...
Page 108 First set the mask width for the right edge of the first projector. Enter a width value equal to the overlap area (width1). Repeat for the left edge of the second projector. Adjust the offset to cut the image on each side (masking). R5915525 /01 F400/FS400...
Page 109: Blend Files
– alpha]. For more info on the introspection tool, consult the Pulse API reference guide. How to activate an uploaded Blend configuration file? In the main menu, select Installation → Blend and Mask → Blend files. R5915525 /01 F400/FS400...
Page 110: Basic Black Level Adjustment
The size of the black level area is calculated automatically from the blend zones. This is done by using the start position and size of each edge of the blend and adding an additional size of 8 pixels to reduce the effect known as "sea of mirrors". R5915525 /01 F400/FS400...
Page 111 Move the cursor to the side where the overlapped area occurs (Top, Left, Right or Bottom) and press enter. Adjust the level with the arrow keys and press enter when the desired black level zone is reached. enter the black level value with the numeric keys in the remote control. R5915525 /01 F400/FS400...
Page 112: Rgb Gain Adjustment
RGB Adjustment page, you can specify the multiplication factors (gains) for the Red, Green and Blue colors separately. How to perform an RGB adjustment In the main menu, select Installation → Blend and Mask → Black Level. Image 8–66 Blend and Mask menu, Black level The Basic black level menu is displayed. R5915525 /01 F400/FS400...
Page 113: Black Level Files
How to activate an uploaded Black Level adjustment file? In the main menu, select Installation → Blend and mask → Black level → Black level files. Image 8–68 Blend and mask menu, Black level files The Black level files menu is displayed. R5915525 /01 F400/FS400...
Page 114: Clo Feature
8.6.1 Introduction Introduction The CLO (Constant Light Output) is a Barco Pulse software feature for maintaining a stable light output from the projector over time, by automatically adjusting the light source. The CLO feature utilizes a light sensor placed internally in the projectors light path.
Page 115: Using The Clo Features
Explanation: The light source power is at its maximum and can no longer maintain the desired light output • L8000d Illumination cli light measuring failed Explanation: The CLO failed while trying to measure the light on the light sensor, either when enabling the CLO or during CLO operation R5915525 /01 F400/FS400...
Page 116: Example For Using The Clo Feature For Maintaining Brightness Over Time
The same prerequisites apply for this feature regarding the degradation of the light source and the initial set- point chosen for the light source power. The CLO scale can be set and / or monitored using the property: • illumination.clo.scale R5915525 /01 F400/FS400...
Page 117: Example: Clo Scale With One Projector
10 seconds shall not differ more than 0.75% from the set-point". This to maintain the desired light output. From a user perspective no interaction has been made with the projector, so a change to the hasstabilized signal in this case would not make sense. The functionality presented in a Given-When-Then format. R5915525 /01 F400/FS400...
Page 118: Ewma
8.6.7 Setpoint Setpoint This feature enables the user to set the desired value directly. As no max value is given Barco recommends using the CLO scale if different output power settings are needed when using the CLO. The setpoint can be set and/or monitored using the property: •...
Page 119: Projection
In a 3D setup it is crucial that the projected images are perfectly synchronized through the whole signal path, from the signal source to the picture viewed through the 3D goggles. R5915525 /01 F400/FS400...
Page 120: Active Stereo & Passive Stereo
Select the correct stitched source Input in the Source menu. See “Setup process 3D projection”, page 120. Depending on the chosen 3D emitter and chosen source, correct the 3D setup. For more info, see “3D Setup”, page 121. R5915525 /01 F400/FS400...
Page 121: Connection Possibilities
Why change the 3D setup? While Barco can provide a 3D emitter and active shutter glasses as options to this projector, you are also free to use a 3D emitter and active shutter glasses of your own choice. Since glasses and emitter can have various specifications compared to the ones Barco can provide, the 3D setup menu allows you to configure the output image to the specifications of your glasses and emitter.
Page 122 Image 8–76 Installation menu, 3D setup The 3D setup menu is displayed. Image 8–77 Example of the 3D setup menu on a UDX If it is necessary to invert the stereo sync output, enable the Swap eyes option. R5915525 /01 F400/FS400...
Page 123 If the projected moving 3D content doesn’t look smooth enough, enable the Swap frame pair option to help improve this. Select the desired the stereo Dark Time. Select the desired Display mode. Use the slider to set the desired stereo Sync delay. R5915525 /01 F400/FS400...
Page 124 GUI – Installation R5915525 /01 F400/FS400...
Page 125: Gui - Projector Profiles
GUI – Projector profiles Profiles introduction ........................126 Saving the current projector settings in a profile ................127 Assigning a created projector profile to a preset ................128 Deleting a projector profile......................130 R5915525 /01 F400/FS400...
Page 126: Profiles Introduction
3D Display mode used settings) • Swap eyes on / off • Swap frame pair on / off • Dark time and sync delay values Realcolor • Brilliant Color mode (if available) • P7 desired values • P7 measured values R5915525 /01 F400/FS400...
Page 127: Saving The Current Projector Settings In A Profile
How to save the current projector settings? In the main menu, select Profiles → Edit. Image 9–2 Profiles menu, edit The Profile edit menu is displayed. only valid if recalled with same lens Only if external cooler is installed Only for applicable models R5915525 /01 F400/FS400...
Page 128: Assigning A Created Projector Profile To A Preset
9.3 Assigning a created projector profile to a preset This procedure assumes you have created at least one projector profile. . How to assign a projector profile to a preset In the main menu, select Profiles → Edit. R5915525 /01 F400/FS400...
Page 129 Image 9–7 Example of a projector profile with available preset slots Use the arrow keys to select a preset slot and confirm with the OK key. The selected preset slot is now shown next to the profile name. R5915525 /01 F400/FS400...
Page 130: Deleting A Projector Profile
How to delete a profile In the main menu, select Profiles → Edit. Image 9–9 Profiles menu, edit The edit menu is displayed. Image 9–10 Profile edit menu Select the undesired projector profile and confirm to expand it. R5915525 /01 F400/FS400...
Page 131 GUI – Projector profiles Image 9–11 Example of a projector profile with available preset slots Use the arrow keys to select Delete and confirm. confirm the delete action. R5915525 /01 F400/FS400...
Page 132 GUI – Projector profiles R5915525 /01 F400/FS400...
Page 133: Gui - System Settings
10.4 Power saving settings ......................... 147 10.5 Lens features ..........................150 10.6 Factory reset ..........................150 10.7 Lens Calibration ......................... 154 10.8 Login to advanced settings ......................155 10.9 List of open source licenses......................156 10.10 End-User license agreement (EULA).................... 157 R5915525 /01 F400/FS400...
Page 134: Communication
The following choices are possible: • Generic IR (address 0) • Barco broadcast IR (address 1) Select APPLY and click OK to apply the changes. 10.1.1.2 Projector address About individual projector address As more than one projector can be installed in a room, each projector should be separately addressable with an RCU or with a computer using serial communication.
Page 135: Ir Sensors
When all sensors are turned off, the projector will no longer respond to signals from the remote control. To re- enable the sensors, use the menu keypad on the projector. How to disable In the main menu, select Settings → Communication → Remote Control. Image 10–5 Communication menu, IR control The Remote control menu is displayed. R5915525 /01 F400/FS400...
Page 136: Host Name - Custom Projector Name Setup
How to set a different Host name In the main menu, select Settings → Communication → Host name. Image 10–7 Communication menu, Host name The Host name menu is displayed. Image 10–8 Example of the host name menu R5915525 /01 F400/FS400...
Page 137: Lan Communication
This must not be 0.0.0.0. If there is no router on the projector's local subnet then just set this field to any IP-Address on the subnet. R5915525 /01 F400/FS400...
Page 138: Wired Ip Address Set Up
On network side, Barco thus recommends the maximum amount of security for your network, in order to avoid this form of tampering. Some network devices may not be properly set for security when installed out of the box.
Page 139 Repeat steps 4 and 5 for the Subnet mask and Default Gateway. Select APPLY and click OK to confirm all changes. When the connection is established, it is indicated with the connection symbol and the indication Connected. R5915525 /01 F400/FS400...
Page 140: Lan Over Hdbaset Tm Ip Address Set Up
When connected, it is indicated with the connection symbol and the indication Connected. Select APPLY and confirm. How to manually set up the IP address In the main menu, select Settings → Communication → HDBaseT Image 10–16 Communication menu, HDBaseT R5915525 /01 F400/FS400...
Page 141: User Interface
When the connection is established, it is indicated with the connection symbol and the indication Connected. 10.2 User interface 10.2.1 Changing the User Interface language How to change the language of the user interface In the main menu, select Settings → User interface → Language. R5915525 /01 F400/FS400...
Page 142: Themes
How to select a different interface theme In the main menu, select Settings → User interface →Themes. Image 10–21 Settings menu, themes In the themes menu, select the desired Theme. You can choose one of the following: Light, or Dark. R5915525 /01 F400/FS400...
Page 143: Units (Measurement) System Setup
LEDs for the LAN and HDbaseT inputs will be disabled. Stealth Mode is enabled and disabled by pressing the OSD button on the remote control for 3 seconds. How to set the backlight In the main menu, Settings → User interface → Backlight. R5915525 /01 F400/FS400...
Page 144: Date And Time
Date is displayed by default as: day / month / year. Time is displayed by default as: hour : minutes : seconds, in the 24–hour clock. How to set manually In the main menu, select Settings → Date and time. Image 10–26 Settings menu, Date and time R5915525 /01 F400/FS400...
Page 145: Date And Time Setup - Automatically
Time is displayed by default as: hour : minutes : seconds, in the 24–hour clock. To set date and time automatically In the main menu, select Settings → Date and time. Image 10–28 The Date and time menu is displayed. R5915525 /01 F400/FS400...
Page 146 Contact your IT system administrator. In case the connection is successful, a green icon appears at the right side of the server line. Select Region and select with the arrow keys the region where the projector is installed. R5915525 /01 F400/FS400...
Page 147: Power Saving Settings
10.4 Power saving settings About the power saving features In the aspect of continuous improvement, Barco has added several power saving features to the projector, which will extend the lifetime of your projector and light source in particular. From Pulse software 2.3.x onward, the following power saving features are available:...
Page 148 To enable or disable the Auto light source off feature, proceed as follows: In the Power menu, click Auto light source off. Image 10–35 Power menu, Auto light source off The Auto light source off menu is displayed. R5915525 /01 F400/FS400...
Page 149 Enable or disable the Auto standby slider to respectively enable or disable this power saving feature. When enabled, select the timeout period after which the projector will go into standby or standby ECO mode. When enabled, choose which version of the Standby mode: regular standby mode, or standby ECO mode. R5915525 /01 F400/FS400...
Page 150: Lens Features
10.6 Factory reset What can be done? All settings and values on the projector can be reset to its default values. This can be done for one or more settings separately, or all settings together (factory reset). R5915525 /01 F400/FS400...
Page 151 Contrast mid value Brightness mid value Saturation mid value Sharpness mid value Gamma mid value, auto Digital Shift and Zoom Disabled, set to mid values Cropping Aspect Ratio 16:9 Scaling Fill Aspect ratio Orientation Orientation Table, Front R5915525 /01 F400/FS400...
Page 152 All profiles will be deleted, presets will be cleared Scheduler Weekly schedule Disabled, Schedule is fully cleared. Screen Screen luminance unit nits Screen Luminance HDR Boost System Auto dim Enabled Auto light source off Disabled, timer set to 10 minutes. R5915525 /01 F400/FS400...
Page 153 Images uploaded by external tools (e.g. Projector Toolset) are removed. Images uploaded using the OEM partner tool provided by Barco are not removed. How to reset all projector settings In the main menu, select Settings → Maintenance → Reset. Image 10–41 Settings menu, factory reset The Reset menu is displayed.
Page 154: Lens Calibration
Navigate to the checkbox next to the settings that need to be reset and press OK. Multiple selections are possible. Select RESET SELECTED and confirm with OK to reset all selected settings. 10.7 Lens Calibration How to calibrate In the main menu, Settings → Maintenance → Lens Calibration. R5915525 /01 F400/FS400...
Page 155: Login To Advanced Settings
The text Calibrating will be displayed in the icon of the selected function until the calibration is completed. Image 10–47 When an error is detected, the message Calibration Error is displayed next to function. 10.8 Login to advanced settings How to login In the main menu, Settings → Maintenance → Login. R5915525 /01 F400/FS400...
Page 156: List Of Open Source Licenses
How to find the open source licenses For the complete and most up-to-date list of the used open source software and the version used, go to the main menu and select Settings → General → Open source licenses. R5915525 /01 F400/FS400...
Page 157: End-User License Agreement (Eula)
There is no option to re-accept or reject the EULA. It is only available for consulting purposes. How to find the EULA after accepting it Go to the main menu and select Settings → General → EULA. Image 10–51 General menu – EULA R5915525 /01 F400/FS400...
Page 158 GUI – System Settings R5915525 /01 F400/FS400...
Page 159: Gui - Advanced Settings
“Login to advanced settings”, page 155 for more info. Image 11–1 Maintanance menu with the Advanced menu and Remote access menu unlocked The Security, Advanced and Diagnostics menus will remain visible until you leave the Maintenance menu. R5915525 /01 F400/FS400...
Page 160: Security - Enable Source Preview
Image 11–3 Example of the Security menu Drag the slider of the Source preview icon to the right to enable the source preview feature. Image 11–4 Remote access menu, Source preview is Image 11–5 Remote access menu, Source preview is disabled enabled R5915525 /01 F400/FS400...
Page 161: Security - Enable Custom Test Pattern Upload
Image 11–7 Example of the Security menu Drag the slider of the Camera icon to the right to enable the camera preview feature. Image 11–8 Security menu, Custom test pattern disabled Image 11–9 Security menu, Custom test pattern enabled R5915525 /01 F400/FS400...
Page 162: Advanced Settings - Realcolor Calibration
Blue slider: calibration mode enabled. How to adjust the P7 native settings Once the calibration mode is activated, select the desired value, click OK to activate, change with the up and down keys and confirm by clicking OK. R5915525 /01 F400/FS400...
Page 163: Advanced Settings - Statistics
In the main menu, navigate to Settings → Maintenance → Advanced, while you are logged in.. Image 11–13 Maintenance menu, Advanced In the Advanced Settings menu, select Statistics. Image 11–14 Advanced settings, Statistics The Statistics menu will be displayed. R5915525 /01 F400/FS400...
Page 164: Advanced Settings - Tilt Sensor Calibration
In the main menu, navigate to Settings → Maintenance → Advanced, while you are logged in. Image 11–16 Maintenance menu, Advanced Enter the service code. In the Service menu, select Tilt sensor calibration. Image 11–17 Advanced menu, Tilt sensor calibration Confirm your action. R5915525 /01 F400/FS400...
Page 165: Tim Curing
In the main menu, navigate to Settings → Maintenance → Advanced, while you are logged in. Image 11–19 Maintenance menu, Advanced In the Advanced Settings menu, select TIM curing. Image 11–20 The TIM curing menu is displayed. R5915525 /01 F400/FS400...
Page 166 To activate DMD curing, select DMD curing and click OK to confirm. Gray slider: DMD curing disabled Blue slider: DMD curing enabled. To activate Laser curing, select Laser curing and click OK to confirm. Gray slider: Laser curing disabled Blue slider: Laser curing enabled. R5915525 /01 F400/FS400...
Page 167: Gui - Status Menu
GUI – Status menu 12.1 Status menu overview......................... 168 No settings can be modified in the status menu. Its only for consulting. R5915525 /01 F400/FS400...
Page 168: Status Menu Overview
Projector power and environmental details (e.g. power, temperature, pressure, etc) • Network status (e.g. host name, IP address, software version) • Active function icons (e.g. warp, blend, files, etc). Active functions are highlighted, while inactive functions are muted. R5915525 /01 F400/FS400...
Page 169 • Mounted lens: Lens type and Lens description (if available). • Installation information: Altitude, pitch angle, roll angle, distance (only if applicable for your device) • Basic statistics, Light source run time, light source strikes, projector runtime. R5915525 /01 F400/FS400...
Page 170 GUI – Status menu R5915525 /01 F400/FS400...
Page 171: Gui - Projector Scheduler
GUI – Projector scheduler 13.1 About the projector scheduler ...................... 172 13.2 Adding a new command in the scheduler..................172 13.3 Edit or Delete a command ......................174 13.4 Clearing the scheduler ........................ 175 R5915525 /01 F400/FS400...
Page 172: About The Projector Scheduler
Make sure the Enabled slider is set to the right and lit blue. If not, the Scheduler will not be active. 13.2 Adding a new command in the scheduler How to add a new command In the Scheduler menu, select Add Command. The Add Command page is displayed. R5915525 /01 F400/FS400...
Page 173 For more info on creating Projector Profiles, see “GUI – Projector profiles”, page 125. If Profile is selected, the currently available projector Profiles will be listed in the menu. Image 13–5 Example of the Add Command window with the available profiles listed R5915525 /01 F400/FS400...
Page 174: Edit Or Delete A Command
Image 13–7 Example of the Scheduler menu, with Power On being added. 13.3 Edit or Delete a command How to edit or delete a command In the Scheduler menu, select and confirm an existing command. The Edit Command window will be prompted. R5915525 /01 F400/FS400...
Page 175: Clearing The Scheduler
Image 13–9 Example of the warning dialog Confirm the action by clicking Confirm. Note: If you clicked the Clear All button by accident, click Cancel instead to cancel and return to the Scheduler menu. All actions in the Scheduler will be deleted. R5915525 /01 F400/FS400...
Page 176 GUI – Projector scheduler Image 13–10 Example of a cleared Scheduler menu R5915525 /01 F400/FS400...
Page 177: Maintenance
Maintenance 14.1 Cleaning the lens........................178 14.2 Cleaning the exterior of the projector .................... 178 14.3 Filters ............................178 About this chapter This chapter contains general maintenance procedures. R5915525 /01 F400/FS400...
Page 178: Cleaning The Lens
The F400 is shipped without any filters. The air intake is just protected by a mesh. This mesh has to be vacuum cleaned occasionally when needed. There is no specific interval for this operation. Pressurized air cans are not efficient if there is too much dust on the surface, the pressure is too low R5915525 /01 F400/FS400...
Page 179: A Image Settings And Adjustments For Optimal Latency
Image settings and adjustments for optimal latency Introduction ..........................180 Latency............................180 DMD display device ........................180 Image display ..........................180 Image positioning ........................182 R5915525 /01 F400/FS400...
Page 180: Introduction
DMD display device Barco projectors uses a DMD device from Texas Instruments to display the image. A DMD device displays the intensity of a pixel by time multiplexing the time it is on over the frame time. If one pixel is 50% grey, it is on for 50% of the time for that frame.
Page 181 Therefore, the black pixels at the bottom of the image directly adds to latency since the image cannot be display until all the extra black pixels have been transmitted to the DMD. R5915525 /01 F400/FS400...
Page 182: Image Positioning
DMD with black lines before the actual content. Note that for a 60Hz system, latency will never go below 16.66667ms because the DMD is displaying the image synchronously with the refresh of the incoming image. R5915525 /01 F400/FS400...
Page 183: B Color Component Mapping
Color component mapping Introduction ..........................184 How infrared is displayed ......................184 Default setup..........................184 Cloned image with full RGB input ....................185 Cloned inputs with only green content for IR ................. 186 R5915525 /01 F400/FS400...
Page 184: Introduction
IR channel has full black/white content if displayed on a regular monitor. This is not a clone or spitted image even if the content in the example below indicates the same image on both inputs. Display port 1 (VL) Color mapping Image B–1 R5915525 /01 F400/FS400...
Page 185: Cloned Image With Full Rgb Input
IR channel and fully saturate the DMD with this component. Display port 1 (VL) Color mapping Image B–3 Displayport 2 (IR) Image B–4 To achieve this result, use the following settings: R5915525 /01 F400/FS400...
Page 186: Cloned Inputs With Only Green Content For Ir
Display port 1 (VL) Color mapping Image B–5 Display port 2 (IR) Image B–6 Property Value image.connector.displayport1.colorcomponent.red GREEN_IN image.connector.displayport1.colorcomponent.green image.connector.displayport1.colorcomponent.blue image.connector.displayport2.colorcomponent.red GREEN_IN image.connector.displayport2.colorcomponent.green GREEN_IN image.connector.displayport2.colorcomponent.blue GREEN_IN R5915525 /01 F400/FS400...
Page 187: C Advanced Blend
Advanced blend Advanced blend, file creation....................... 188 Example files..........................189 User interface..........................191 R5915525 /01 F400/FS400...
Page 188: Advanced Blend, File Creation
About The file format is JSON based and consists of a top-level object that has a surfaces member, containing an array of surfaces objects. Files containing this format are marked with the extension .babl (for Barco Advanced BLend). File parameters...
Page 189: Example Files
[0.25, 0.2], [0.4, 0.2], [0.6, 0.2], [0.8, 0.2], [0.30, 0.4], [0.8, 0.3], [0.30, 0.6], [0.8, 0.6], [0.20, 0.8], [0.4, 0.8], [0.6, 0.8], [0.8, 0.8] "colors": [ [1.0, 1.0, 1.0], [0.50, 0.50, 0.50], [0.0, 0.0, 0.0], [0.98, 0.98, 0.98] "type":"babl", "version":"1.0" R5915525 /01 F400/FS400...
Page 190 [0.98, 0.21], [0.78, 0.27], [0.73, 0.28], [0.53, 0.21], [0.94, 0.37], [0.53, 0.38], [0.94, 0.55], [0.53, 0.54], [0.99, 0.71], [0.79, 0.67], [0.73, 0.67], [0.53, 0.71] "colors": [ [0.0, 0.0 ,0.0], [0.95, 0.95, 0.95], [1.0, 1.0, 1.0], [0.05, 0.05, 0.05] } ], "type":"babl", "version":"1.0" R5915525 /01 F400/FS400...
Page 191: User Interface
New: Creates a new project • Load: Switch between active projects. Note: Make sure to save changes before switching to a new project • Load from disk: Load saved project • Invert: Inverts the current project • Save: Saves current project R5915525 /01 F400/FS400...
Page 192 Snap to point: Snap to a point on another surface • Grid: Enable the grid in the Advanced blend tool • Snap to grid: Snap a point to the intersections of the grid in the Advanced blend tool • Grid size: Choose the grid size R5915525 /01 F400/FS400...
Page 193 Image C–8 • Shape outline color:Change the color of the shape • Zoom:Zoom the grid in and out • X,Y: Position of the selected corner point • A: Change the grey level of the selected point R5915525 /01 F400/FS400...
Page 194 Advanced blend R5915525 /01 F400/FS400...
Page 195: D Specifications
Specifications Specifications of F400–4K......................196 Specifications of FS400–4K......................197 Specifications of F400–N4K ......................199 Specifications of FS400–N4K ...................... 200 Dimensions of a F400 ......................... 202 R5915525 /01 F400/FS400...
Page 196: Specifications Of F400-4K
4096 x 2160 @ 60Hz 2560 x 1600 @ 120Hz Input color depth Up to 12Bits depending on set-up`s Software tools Projector Toolset + Android app + iOS app Control IR RJ45 Network connection 10/100 base-T RJ-45 connection R5915525 /01 F400/FS400...
Page 197: Specifications Of Fs400-4K
Complies with FCC rules & regulations, part 15 Class A and CE EN55032 CISPR 32(emmision)/EN55035 CISPR 35(immunity) Class A, Rhos Warranty Limited 5 years on parts and labor Extentable D.2 Specifications of FS400–4K Overview Notes PRELIMINARY SPECIFICATION Brightness 5,400 typical ANSI Lumens...
Page 198 -20 to 60 °C 24/7 operation Operating humidity 20 - 80% RH (no condense) Storage humidity 10 - 90% RH (no condense) Dimensions (WxLxH) 562 x 472 x 286 mm / 22 x 18,5 x 11,2 In R5915525 /01 F400/FS400...
Page 199: Specifications Of F400-N4K
1 x DP 1.4 (HDCP 2.2) 1 x HDMI 2.1 (HDCP 2.2) 4 x DP 1.2 Input resolutions Including and up to: 4,096 x 2,176 @ 60Hz 4,096 x 2,176 @ 120Hz 4,096 x 2,176 @ 240Hz 6,144 x 3,264 @ 60Hz R5915525 /01 F400/FS400...
Page 200: Specifications Of Fs400-N4K
Power cord, wireless remote control Certifications CE, FCC Class A and cNus Warranty Limited 5 years parts and labor, extendable. * Typical ANSI lumens ** Mode dependant D.4 Specifications of FS400–N4K Notes PRELIMINARY Brightness 5,300 Center Lumens 5,000 ANSI Lumens* Contrast ratio 2,000 –...
Page 201 472 x 562(542) x 286 mm / 18,6 x 22,1(21,3) x 11,3 in (front cover removed) Weight 31,0 kg / 68 lbs Standard accessories Power cord, wireless remote control Certifications CE, FCC Class A and cNus Warranty Limited 5 years parts and labor, extendable * Typical ANSI lumens ** Mode dependant R5915525 /01 F400/FS400...
Page 202: Dimensions Of A F400
Specifications D.5 Dimensions of a F400 Overview UNDER CONSTRUCTION R5915525 /01 F400/FS400...
Page 203: E Regulatory Information
Regulatory information Product compliance ........................204 Disposal information ........................205 China RoHS compliance ......................205 Taiwan RoHS compliance......................207 Turkey RoHS compliance......................208 Production address........................208 Contact information........................208 Product Info (Taiwan) ........................208 R5915525 /01 F400/FS400...
Page 204: Product Compliance
Regulatory information E.1 Product compliance UK Compliance This product is fit for use in the UK. Authorised Representative: Barco UK Ltd Address: Building 329, Doncastle Road Bracknell RG12 8PE, Berkshire, United Kingdom EurAsian Conformity (EAC) This product complies with the Safety of Low-Voltage Equipment (LVE Technical Regulation 004/...
Page 205: Disposal Information
Electronic Products” (Also called RoHS of Chinese Mainland), the table below lists the names and contents of toxic and/or hazardous substances that Barco’s product may contain. The RoHS of Chinese Mainland is included in the MCV standard of the Ministry of Information Industry of China, in the section “Limit Requirements of toxic substances in Electronic Information Products”.
Page 206 Chinese Mainland, marked with the Environmental Friendly Use Period (EFUP) logo. The number inside the EFUP logo that Barco uses (please refer to the photo) is based on the “General guidelines of environment-friendly use period of electronic information products”...
Page 207: Taiwan Rohs Compliance
Note 2：“〇” indicates that the percentage content of the restricted substance does not exceed the percentage of reference value of presence. 備考3.〝—〞係指該項限用物質為排除項目。 Note 3：The “—” indicates that the restricted substance corresponds to the exemption. 備註: 此RoHS表格適用於以下產品型號: F400 Hint: This RoHS table is suitable for following models: F400 R5915525 /01 F400/FS400...
Page 208: Turkey Rohs Compliance
Barco Fredrikstad AS Mosseveien 63, 1610 Fredrikstad, Norway Importers contact information To find your local importer, contact Barco directly or one of Barco's regional offices via the contact information given on Barco's web site, www.barco.com. E.8 Product Info (Taiwan) Product info product name 產品名稱:...
Page 209: F Video Timing Tables
Video timing tables Overview video timings ....................... 210 Overview video timings HDMI 2.0 inputs..................211 Overview video timings DisplayPort 1.4 input................213 Overview video timings DisplayPort 1.2 inputs ................213 REVISION OF THE TABLES IS NECESSARY. R5915525 /01 F400/FS400...
Page 210: Overview Video Timings
F.1 Overview video timings List of compatible signals The following table specifies the video signals that the projector can project. Barco Events projectors supports the signal with “X” in the Compatible signals column. Note: Support for refresh rates 24.00, 30.00, 60.00 Hz automatically includes support of 1/1.001 x those refresh rates.
Page 211: Overview Video Timings Hdmi 2.0 Inputs
Note: support for refresh rates 24.00, 30.00, 60.00 Hz automatically includes support of 1/1.001 x those refresh rates Video timing Vertical refresh rate (Hz) 3D support? (active pixels x active lines) 640 x 480 720 x 480 720 x576 800 x 600 1024x 768 1280 x720 Frame packing Top – bottom R5915525 /01 F400/FS400...
Page 212 3840 x 2160 3840 x 2160 3840 x 2160 3840 x 2160 3840 x 2160 3840 x 2400 3840 x 2400 4096 x 2160 4096 x 2160 4096 x 2160 4096 x 2160 4096 x 2160 4096 x 2176 R5915525 /01 F400/FS400...
Page 213: Overview Video Timings Displayport 1.4 Input
1280 x 1600 2 Column mode (2 x 1 layout) 1280 x 1600 2 Column mode (2 x 1 Active 3D layout) 1400 x 1050 1600 x 1200 1600 x 1200 Active 3D 1920 x 1080 1920 x 1080 R5915525 /01 F400/FS400...
Page 214 Active 3D 2560 x 1600 2560 x 1600 3840 x 2160 3840 x 2160 3840 x 2160 3840 x 2160 3840 x 2160 3840 x 2400 3840 x 2400 4096 x 2160 4096 x 2160 4096 x 2160 R5915525 /01 F400/FS400...
Page 215 Video timing tables Video timing Available layout modes, Vertical refresh rate other than standard Support for 3D? (active pixels x active (Hz) layout (1 x 1 layout) lines) 4096 x 2160 4096 x 2160 R5915525 /01 F400/FS400...
Page 216 Video timing tables R5915525 /01 F400/FS400...
Page 217: Glossary
This includes the transport delay. The value is normally given in milliseconds. MAC address Media Access Control address. Unique hardware number, used in combination with the IP-address to connect to the network (LAN or WAN). R5915525 /01 F400/FS400...
Page 218 A number that is used to identify a subnetwork so that IP addresses can be shared on a local area network. Transport latency The added delay in the image processing chain. The value is the number of lines relative to the output resolution. R5915525 /01 F400/FS400...
Page 219: Index
Basic remote control unit 24 Prospector 115 Battery CLO scale Disposal 205 3 projectors 117 Blending 104 One projector 117 Basic blend 105, 107 Cloned image with full RGB input Black level adjustment 110 Color component mapping 185 R5915525 /01 F400/FS400...
Page 220 Tilted brightness 72 IP address, wired connection 138 Image display EULA 157 Image settings and adjustments for optimal EurAsian Conformity (EAC) 204 latency 180 EWMA Image positioning CLO 118 Image settings and adjustments for optimal Example files latency 182 R5915525 /01 F400/FS400...
Page 221 Functionality overview 41 Power off Location Switching off 45 Light sensor 114 Product Info (Taiwan) 208 Production 208 Profile Delete 130 New 127 Macro 125 Profiles 125 Delete 130 Edit 128 Edit 128 Introduction 126 New 127 Preset 128 R5915525 /01 F400/FS400...
Page 222 Broadcast address 134 Single source 58 Projector address 134 Specifications 195 Reset F400–4K 196 3D settings 150 F400–N4K 199 All 150 FS400–4K 197 Blending 150 FS400–N4K 200 DMX 150 Status Light 36 Features 150 Status menu 167 Illumination 150 Overview 168...
Page 223 CLO 116 User definition 13 User interface Advanced blend 191 System settings 141 Video timings DisplayPort 1.4 input 213 DisplayPort Inputs 213 HDMI Inputs 211 Overview 210 Tables 209 Warping 92 WEEE 205, 208 Weekly schedule 171 R5915525 /01 F400/FS400...
Page 224 Index R5915525 /01 F400/FS400...
Page 226 R5915525 /01 | 2023-12-20 www.barco.com...

This manual is also suitable for:

F400 F400-4k F400-n4k Fs400-4k Fs400-n4k

Barco FS400 User Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Barco FS400

Summary of Contents for Barco FS400
