- Page 1 Assembly Instructions ADV5401, ADV5301, ADV5001 Adventus adaptor bar Etac Cross / Cross5 2023-11 Revision 3...
-
Page 2: General Instructions
INFO Particularly important or explanatory information General instructions These instructions shall always be followed when placing the adaptor bar ADV5401, ADV5301, ADV5001 on a wheelchair. Adjustment of the Adventus wheel is described in the user manual of the Adventus wheel. - Page 3 Assembly Instructions ADV5401, ADV5301. ADV5001 __________________________________________________________________________________ 2. Overview A Adapterbar B Fork adapterbar C Adapterkit Pic1 D QR Pin INFO Picture above (Pic1) show a Cross 5 wheelchair. __________________________________________________________________________________ Sida 3/10...
- Page 4 Assembly Instructions ADV5401, ADV5301. ADV5001 __________________________________________________________________________________ 3. Assembly adapterkit First mount the Adapterkit (C) on both sides of the frame. Do not tighten the screws completely. Pictures bellow (Pic2, Pic3) show one side only. Pic3 Pic2 Mount the adapterbar (A) using the QR Pin (D) (Pic4).
- Page 5 Assembly Instructions ADV5401, ADV5301. ADV5001 __________________________________________________________________________________ Tighten the clamp screws crosswise (Pic5) on one side first and then the other side. Pic5 INFO After the screws are tightened check that the adapter bar still can be removed from its holders without excessive force. If the adapter bar is stuck in its holders loosen the screws on one side and adjust the position.
- Page 6 Assembly Instructions ADV5401, ADV5301. ADV5001 __________________________________________________________________________________ 4. Adjustment of the adapter bar Mount the fork adapter bar (B) onto the adapter bar (A). Mount the level tool onto the adapter bar fork (B). Remove the rear screws (E) in the fork that locks the rotation and make sure that the front screws (F) are a little bit loose so that the fork can be rotated.
- Page 7 Assembly Instructions ADV5401, ADV5301. ADV5001 __________________________________________________________________________________ Now rotate both the adapter bar and the fork to a position where the level tool shows the correct angle and the fork doesn’t collide with the footrests. The fork can be positioned both under and over the footrest depending on wheelchair model and footrest position.
- Page 8 Assembly Instructions ADV5401, ADV5301. ADV5001 __________________________________________________________________________________ Reassemble the rear screws (E) in the hole that is fits the best. Tighten the screws. VARNING! The screws (E&F) shall be tightened to 7-9Nm of torque. Loctite 243 or eq. must be applied if locking washers are not used.
- Page 9 Assembly Instructions ADV5401, ADV5301. ADV5001 __________________________________________________________________________________ Now, tighten the screws that sits in the clamps on the adapter bar (A) and on fork adapter bar (B). On both clamps, slightly tighten all screws. It is important to not completely tighten each screw, but to slowly tighten them a little at a time.
- Page 10 Decon Wheel AB Södra Ekeryd 119, SE-314 93 Hyltebruk, Sweden Tel: +46 (0)345 40880 Fax: +46 (0)345 40895 E-mail: info@decon.se...
