Citrocasa REVOLUTION ADVANCE User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
Manual version:
June 2020
REVOLUTION ADVANCE
Version 04 and newer
Citrus America, Inc.
2781 Wrights Rd, Ste 1233, Oviedo, FL 32765
Phone: (407) 790-7862 / Fax: (407) 790-7863
Website:
www.citrusamerica.com
Training:
www.citrusamerica/training.com
0
NOTICE: ALL USERS OF THIS JUICER MUST UNDERSTAND THE IMPORTANT SAFEGUARDS SECTION AND THE CONTENTS OF THIS
MANUAL. THIS INSTRUCTION MANUAL SHOULD BE LOCATED IN AN ACCESSIBLE LOCATION FOR ALL USERS OF THE JUICER.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the REVOLUTION ADVANCE and is the answer not in the manual?

Questions and answers

Related Manuals for Citrocasa REVOLUTION ADVANCE

Summary of Contents for Citrocasa REVOLUTION ADVANCE

  • Page 1 User Manual Manual version: June 2020 REVOLUTION ADVANCE Version 04 and newer Citrus America, Inc. 2781 Wrights Rd, Ste 1233, Oviedo, FL 32765 Phone: (407) 790-7862 / Fax: (407) 790-7863 Website: www.citrusamerica.com Training: www.citrusamerica/training.com NOTICE: ALL USERS OF THIS JUICER MUST UNDERSTAND THE IMPORTANT SAFEGUARDS SECTION AND THE CONTENTS OF THIS...

  • Page 2: Table Of Contents

    CONTENTS IMPORTANT GENERAL INFORMATION AND SAFEGUARDS CITROCASA LIMITED WARRANTY TECHNICAL SPECIFICATIONS and MACHINE PART OVERVIEW SETTING UP YOUR CITROCASA REVOLUTION OPERATING YOUR CITROCASA REVOLUTION CLEANING YOUR CITROCASA REVOLUTION COMMON SPARE PARTS ACCESSORIES CERTIFICATIONS...

  • Page 3: Important General Information And Safeguards

    • Citrocasa juicers are certified and in accordance with the NSF, UL, CE, GS and TUV safety standards. • The technical data of the Citrocasa juicer is located on the ID plate on the rear of the machine. When ordering spare parts, be sure to mention the model and serial number.
  • Page 4 IMPORTANT SAFEGUARDS (CONTINUED) • Please read the section on cleaning and hygiene and be sure that all personnel are adequately trained on machine usage prior to their using the equipment. • Before cleaning the machine, making any repairs or maintenance, FOR YOUR SAFETY please ensure that the machine is unplugged from its power supply.
  • Page 5 Citrocasa may make changes to this instruction manual without prior notice. The most current version of this manual may be obtained by contacting Citrus America, Inc. directly. If you have any suggestions to improve this manual or our products, or any questions regarding the training of users or machine operation and maintenance, or any other comments, please contact your dealer/supplier or Citrus America, Inc.

  • Page 6: Citrocasa Limited Warranty

    Citrus America, Inc. be liable for any loss, damage, whether direct, indirect, incidental, special, consequential, or punitive, or for any costs or expenses incurred, arising out of or in connection with the use of the Citrocasa juicer. Manufacturer’s and Citrus America, Inc.’s liability shall not exceed the purchase price paid.

  • Page 7: Technical Specifications And Machine Part Overview

    3. TECHNICAL SPECIFICATIONS and MACHINE PART OVERVIEW Main Switch (not visible) Model Revolution Advance Fruit Supply Tunnel Display Pressing Capacity Approx. 20 fruit per minute Fruit Specifications Citrus fruit Front Cover Optimal fruit diameter (standard pressing kit): 2.5 - 3 in (...

  • Page 8: Setting Up Your Citrocasa Revolution

    4. SETTING UP YOUR CITROCASA REVOLUTION Unpack the juicer and position it on a stable and level surface that can bear the weight (net weight approx. 95 lb/43 kg). We recommend cleaning all parts that come into contact with the juice before using the juicer for the first time. See page 13 for step-by- step instructions on how to disassemble and clean your juicer.
  • Page 9 3. Fruit sizing tool and peel bucket guides: • Pull out the peel bucket. (3a) • Remove the fruit sizing tool from inside the peel bucket. Make sure to use the fruit sizing tool when choosing the right fruit (see page 9). •...
  • Page 10 CHOOSING A LANGUAGE: 1. On the display, push the FUNCTION button (1) until you see FUNCTION “Choose language”. button 2. Go through the language options (English, German, Spanish, French, Italian) by pressing the ON (2) and OFF (3) button AT THE SAME TIME.

  • Page 11: Operating Your Citrocasa Revolution

    5. OPERATING YOUR CITROCASA REVOLUTION 1. Make sure that the juicer is switched on. The control lamp will light up. 2. Place a container under the tap and fill the fruit supply tunnel with fruit. The tunnel can hold 5-6 oranges at a time. You have to continue to feed fruit into the fruit supply tunnel in order to keep juicing.
  • Page 12 5. INTELLIGENT STOP: The Intelligent Stop function allows you to set the amount of fruit to be juiced before the peel bucket should be emptied. An acoustic signal indicates when the pre-set amount has been reached. The juicer will stop automatically. This will avoid peel jams and peel backup.
  • Page 13 7. TOTAL AMOUNT OF “SQUEEZED FRUITS”: Press the FUNCTION button to see the total number of fruit pressed. This number cannot be reset. 8. TOTAL “OPERATING HOURS”: Press the FUNCTION button to see the total hours of operation. This number cannot be reset. 9.

  • Page 14: Cleaning Your Citrocasa Revolution

    6. CLEANING CITROCASA REVOLUTION: STEP-BY-STEP CLEANING ü Clean your juicer AT LEAST ONCE PER DAY, or more frequently, depending on usage! ü For proper cleaning, the juicer must be disassembled as described on the following pages. ü Do not hose or spray down the juicer! ü...
  • Page 15 Caution: Removing the upper pressing elements will expose the knife. The blade is very sharp and can cause injury. Do not touch the sharp edge of the blade (top). Always hold the knife from the front! 9. Remove the upper pressing 10.
  • Page 16 CLEANING THE SB TAP: Follow steps 15-18: 15. Remove the tap 16. Pull the tap out. 17. Turn the upper tap part to the left and separate the two tap 18. Thoroughly housing by pulling it up. parts. clean all tap parts REASSEMBLING YOUR JUICER: 1.

  • Page 17: Common Spare Parts

    7. COMMON SPARE PARTS Front Cover Revolution Fruit Sieve Support Revolution Peel Container Fine Sieve Part no. 300.104.010 Part no. 300.114.030 Part no. 300.117.032 Part no. 300.106.012 Lower Pressing Element Upper Pressing Element (mounted inside sieve support) Double Cover (stainless) Part no.
  • Page 18 Fruit Supply Tunnel Peel Ejector (Rake) Knife Guide Fruit Sieve Part no. 300.246.023 Part no. 300.109.020 Part no. 300.239.043 Part no. 300.203.033 Electronic Box Display complete SB Tap complete Motor Part no. 300.006.U21 Part no. 300.009.060 Part no. 300.112.030 Part no. 300.003.021 For parts not listed contact SB Tap Citrus America:...

  • Page 19: Accessories

    ACCESSORIES Fruit Supply Basket Revolution Part no. 300.248.003 Counter Installation Kit with large 130-fruit-capacity waste bucket Call for part no. CERTIFICATIONS If you have any suggestions to improve this manual or our products, or any questions or other comments, please contact either the manufacturer, TMP GmbH, or the manufacturer’s North American distributor, Citrus America, Inc.: Citrus America, Inc.
