Citrocasa Advance 8000 User Manual

Hide thumbs Also See for Advance 8000:
Table of Contents

Advertisement

Quick Links

User Manual
Manual version:
October 2020
8000SB-ATS Advance Version 08 and newer
8000XB Advance Version 08 and newer
Citrus America, Inc.
2781 Wrights Rd, Ste 1233, Oviedo, FL 32765
Phone: (407) 790-7862 / Fax: (407) 790-7863
Website:
www.citrusamerica.com
Training:
www.citrusamerica.com/training
NOTICE: ALL USERS OF THIS JUICER MUST UNDERSTAND THE IMPORTANT SAFEGUARDS SECTION AND THE CONTENTS OF THIS MANUAL. THIS INSTRUCTION MANUAL SHOULD
BE LOCATED IN AN ACCESSIBLE LOCATION FOR ALL USERS OF THE JUICER.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Advance 8000 and is the answer not in the manual?

Questions and answers

Related Manuals for Citrocasa Advance 8000

Summary of Contents for Citrocasa Advance 8000

  • Page 1 User Manual Manual version: October 2020 8000SB-ATS Advance Version 08 and newer 8000XB Advance Version 08 and newer Citrus America, Inc. 2781 Wrights Rd, Ste 1233, Oviedo, FL 32765 Phone: (407) 790-7862 / Fax: (407) 790-7863 Website: www.citrusamerica.com Training: www.citrusamerica.com/training NOTICE: ALL USERS OF THIS JUICER MUST UNDERSTAND THE IMPORTANT SAFEGUARDS SECTION AND THE CONTENTS OF THIS MANUAL.

  • Page 2: Table Of Contents

    CONTENTS IMPORTANT GENERAL INFORMATION AND SAFEGUARDS CITROCASA LIMITED WARRANTY TECHNICAL SPECIFICATIONS PRESSING KITS AND FRUIT SIZES MACHINE PART OVERVIEW SETTING UP YOUR CITROCASA 8000 OPERATING YOUR CITROCASA 8000 CLEANING YOUR CITROCASA 8000 SPARE PARTS CERTIFICATIONS...

  • Page 3: Important General Information And Safeguards

    • Citrocasa juicers are certified and in accordance with the NSF, UL, CE, GS and TUV safety standards. • The technical data of the Citrocasa juicer is located on the ID plate on the rear of the machine. When ordering spare parts, be sure to mention the model and serial number.
  • Page 4 IMPORTANT SAFEGUARDS (CONTINUED) • Please read the section on cleaning and hygiene and be sure that all personnel are adequately trained on machine usage prior to their using the equipment. • Before cleaning the machine, making any repairs or maintenance, FOR YOUR SAFETY please ensure that the machine is unplugged from its power supply.
  • Page 5 They can take this product for environmentally safe recycling. Citrocasa may make changes to this instruction manual without prior notice. The most current version of this manual may be obtained by contacting Citrus America, Inc. directly. If you have any suggestions to improve this manual or our products, or any questions regarding the training of users or machine operation and maintenance, or any other comments, please contact your dealer/supplier or Citrus America, Inc.

  • Page 6: Citrocasa Limited Warranty

    Citrus America, Inc. be liable for any loss, damage, whether direct, indirect, incidental, special, consequential, or punitive, or for any costs or expenses incurred, arising out of or in connection with the use of the Citrocasa juicer. Manufacturer’s and Citrus America, Inc.’s liability shall not exceed the purchase price paid.

  • Page 7: Technical Specifications

    8000XB: 159 lb / on cabinet: 246 lb (72 kg) (111.5 kg) • 8000SB-ATS: must be mounted on a Citrocasa Cabinet. • 8000XB: Citrocasa Cabinet highly recommended. Power Supply 120 V/60 Hz • Use the handles on the side of the machine to lift it. Do not lift at Power 0.28 kW...

  • Page 8: Pressing Kits And Fruit Sizes

    4. PRESSING KITS AND FRUIT SIZES 8000SB-ATS and 8000XB LARGE PRESSING KIT STANDARD PRESSING KIT SMALL PRESSING KIT Fruit Size Diameter: 3.15 - 3.50 in Fruit Size Diameter: 2.55 - 3.14 in Fruit Size Diameter: 1.96 - 2.55 in (80 - 89 mm) (65 - 80 mm) (50 - 65 mm) Typical Fruit Squeezed...

  • Page 9: Machine Part Overview

    10. Rotation plate (inside hopper) 23. Fruit sieve support (with fine sieve inside) 11. Digital display (side of machine) 24. Self-service (SB) tap 12. Main power switch (back of machine) *Model shown is mounted on a Citrocasa Cabinet 13. ID plate (back of machine)
  • Page 10 11. Stainless steel ON/OFF button (side of machine) 25. Juice tank 12. Digital display (side of machine) 26. Manual tap 13. Front cover nuts (2x) *Model shown is mounted on a Citrocasa Cabinet 14. Main power switch (back of machine) 15. ID Plate (back of machine)

  • Page 11: Setting Up Your Citrocasa 8000

    Place the machine on a flat, level, and stable surface. Ensure that the surface can bear the weight of the machine (see technical specifications). • Due to its size, the Citrocasa 8000 must be stabilized and mounted properly. Citrus America offers three different mounting options: –...
  • Page 12 SETTING UP YOUR CITROCASA 8000 ON A CABINET If you choose to operate your Citrocasa 8000 on a Citrocasa Cabinet, please follow these steps for installation: • Place the rolling cabinet on a flat and even surface. • Leave enough room for the cabinet door to be opened. You must be able to easily access and remove the waste container inside the cabinet! •...
  • Page 13 8000SB-ATS: INSTALLING THE AUTOMATIC TRANSPORT SYSTEM (ATS) • When installing the ATS external module, ensure that the drive shaft of the ATS module (Pic 1) fits correctly into the drive shaft adapter (Pic 2). Use the adjustment screw (Pic 3) to install the ATS belt correctly (Pic 4). •...
  • Page 14 8000XB: SETTING UP THE JUICE TANK • The juice tank is delivered disassembled as shown in picture 1. Juice tank parts • Rinse the juice tap and juice tank prior to first use. • Take the juice tank agitator and loop the short end into the hole on the side Juice tank of the juice tank.

  • Page 15: Operating Your Citrocasa 8000

    7. OPERATING YOUR CITROCASA 8000 To begin juicing, follow these steps: • Clean all the parts that come into contact with the juice prior to juicing for the first time. • Fill the fruit basket with fruit (Pic 1). •...
  • Page 16 SWITCH ON THE JUICER: • Plug the machine into a standard grounded outlet. • Turn on the main switch on the back of machine (Pic 1). The switch will light up. • By pressing the function button (Pic 2) you will be able to view several different menu options, which are explained over the next few pages.
  • Page 17 8000SB-ATS: SELECT AN OPERATING MODE On the 8000SB-ATS, you can choose between two operating modes: self-service and continuous pressing. • SELF-SERVICE MODE (Pic 5): – With the function button select the self-service mode. You will see “Self service Push 〈Press〉” on the display. –...
  • Page 18 8000XB: SELECT AN OPERATING MODE On the 8000XB, you can choose between two operating modes: programmed and continuous pressing. PROGRAMMED MODE (Pic 7): • Select this function by pressing the function button (No 1) until you see “Current-00 Push 〈ON〉” on the display. •...
  • Page 19 INTELLIGENT STOP FUNCTION: For improved peel management, it is possible to set the machine to automatically stop pressing after a certain amount of fruit has been pressed, reminding you to empty the peel bucket in order to avoid peel jams. •...
  • Page 20 LOCK/UNLOCK THE DISPLAY: It is possible to lock the display in the preset pressing mode to avoid unintentional setting Pic 12 changes. To lock the display: • Select the desired pressing mode. • 8000SB-ATS (Pic 12): Press the function button and the OFF button at the same time. •...
  • Page 21 SHUTTING DOWN YOUR CITROCASA 8000 CAUTION: DO NOT SHUT THE MACHINE OFF WITH THE MAIN POWER SWITCH OR BY PULLING THE CORD WHILE IT IS STILL JUICING AND THE PRESSING ELEMENTS ARE STILL MOVING. AN IMPROPER SHUTDOWN MAY CAUSE THE PRESSING ELEMENTS TO STOP IN THE INCORRECT END POSITION (Pic 1).

  • Page 22: Cleaning Your Citrocasa 8000

    • Wipe down the machine itself and the juicing area on a regular basis using warm water. If you are using a Citrocasa Fantastic Cabinet or a Citrocasa Counter Installation Kit, also be sure to clean the stainless-steel peel chute and all cabinet/kit parts properly.
  • Page 23 STEP-BY-STEP CLEANING INSTRUCTIONS The below mentioned cleaning steps must be completed at least once every 24 hours. Frequent juicing will require more frequent cleaning. For optimal efficiency and hygiene, we recommend using a cleaning log. IMPORTANT: ü Make sure to properly shut down the machine (see page 20). ü...
  • Page 24 Remove the splash protector (Pic 5). Remove the side chutes by pressing the fastening clip (Pic 6a) and sliding the chute upward out of the slide mount (Pic 6b). Remove the fastening screws of the front cover (Pic 7). Remove the front cover: Pull the lower part of the front cover slightly towards the front.
  • Page 25 11. Pull out the cross holder screw to separate the knife guide from the cross holder (Pic 11a). You will have three individual parts: the cross holder, the knife guide and the screw (Pic 11b). ATTENTION: When re-installing the cross holder, ensure that the blade rests completely in its proper position and that the screw is properly tightened by hand.
  • Page 26 16. Open the fruit supply tunnel locking lever and remove the supply tunnel (Pic 16). 17. Remove the double cover (Pic 17). 8000SB-ATS: For cleaning the ATS system and SB tap, see page 26. 8000XB: CLEANING THE MTS SYSTEM 18. Remove the MTS (Pic 18). 19.
  • Page 27 8000SB-ATS: CLEANING THE ATS SYSTEM 22. Remove the SB tap by unscrewing it from the machine (Pic 22). 23. Unscrew and separate the lower tap part from the upper tap part (Pic 23). Rinse both tap parts thoroughly before you place them in the dishwasher. 24.
  • Page 28 27. Wipe down the housing with warm, clean water and a soft cloth (Pic 27). Dry thoroughly before reassembling the machine. Be sure to wipe down the stainless-steel posts to remove any juice residue. ATTENTION: The four O-ring seals protect the inside of the machine from juice and increase hygiene and machine life.
  • Page 29 ü DO NOT SPRAY OR HOSE DOWN THE MACHINE! ü DO NOT USE CHEMICAL CLEANING AGENTS OR ABRASIVES TO CLEAN THE HOUSING AND THE O-RING SEALS. USE FRESH, CLEAN, WARM WATER AND A SOFT TOWEL! ü ALL PARTS EXCEPT FOR THE ACRYLIC FRONT COVER, THE ACRYLIC SIDE CHUTES AND THE ACRYLIC JUICE TANK CAN BE PLACED IN THE DISHWASHER FOR CLEANING.

  • Page 30: Spare Parts

    9. SPARE PARTS Be sure to provide machine model and serial number when ordering spare parts to ensure that the proper parts are supplied. For additional spare parts not listed below, please contact your customer service representative or Citrus America directly. Left peel ejector complete with brackets and screws...
  • Page 31 Be sure to provide machine model and serial number when ordering spare parts to ensure that the proper parts are supplied. For additional spare parts not listed below, please contact your customer service representative or Citrus America directly. Fruit sieve support nut Side chute front Front cover nut 8000 series...
  • Page 32 Be sure to provide machine model and serial number when ordering spare parts to ensure that the proper parts are supplied. For additional spare parts not listed below, please contact your customer service representative or Citrus America directly. ATS system Adjustment knob ATS Art.

  • Page 33: Certifications

    10. CERTIFICATIONS All Citrocasa machines have been NSF certified and are certified to meet UL-763 and be in compliance with normal OSHA requirements as certified by a Nationally Recognized Testing Laboratory (NRTL). Should you require updated certification documents, please contact your representative or our toll-free number/technical service at: 1-855-MY-CITRO (855-692-4876).
