Citrocasa Fantastic ECO User Manual

Hide thumbs Also See for Fantastic ECO:

Advertisement

Quick Links

User Manual
Manual version:
October 2020
Fantastic ECO
Citrus America, Inc.
2781 Wrights Rd, Ste 1233, Oviedo, FL32765
Phone: (407) 790-7862 / Fax: (407) 790-7863
Website:
www.citrusamerica.com
Training:
www.citrusamerica.com/training
NOTICE: ALL USERS OF THIS JUICER MUST UNDERSTAND THE IMPORTANT SAFEGUARDS SECTION AND THE CONTENTS OF THIS MANUAL. THIS INSTRUCTION MANUAL SHOULD
BE LOCATED IN AN ACCESSIBLE LOCATION FOR ALL USERS OF THE JUICER.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Fantastic ECO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Citrocasa Fantastic ECO

  • Page 1 User Manual Manual version: October 2020 Fantastic ECO Citrus America, Inc. 2781 Wrights Rd, Ste 1233, Oviedo, FL32765 Phone: (407) 790-7862 / Fax: (407) 790-7863 Website: www.citrusamerica.com Training: www.citrusamerica.com/training NOTICE: ALL USERS OF THIS JUICER MUST UNDERSTAND THE IMPORTANT SAFEGUARDS SECTION AND THE CONTENTS OF THIS MANUAL. THIS INSTRUCTION MANUAL SHOULD...
  • Page 2: Table Of Contents

    CONTENTS IMPORTANT GENERAL INFORMATION AND SAFEGUARDS CITROCASA LIMITED WARRANTY TECHNICAL SPECIFICATIONS PRESSING KITS AND FRUIT SIZES MACHINE PART OVERVIEW SETTING UP YOUR CITROCASA FANTASTIC ECO OPERATING YOUR CITROCASA FANTASTIC ECO CLEANING YOUR CITROCASA FANTASTIC ECO SPARE PARTS CERTIFICATIONS...
  • Page 3 • Citrocasa juicers are certified and in accordance with the NSF, UL, CE, GS and TUV safety standards. • The technical data of the Citrocasa juicer is located on the ID plate on the rear of the machine. When ordering spare parts, be sure to mention the model and serial number.
  • Page 4: Citrocasa Limited Warranty

    Citrus America, Inc. be liable for any loss, damage, whether direct, indirect, incidental, special, consequential, or punitive, or for any costs or expenses incurred, arising out of or in connection with the use of the Citrocasa juicer. Manufacturer’s and Citrus America, Inc.’s liability shall not exceed the purchase price paid.
  • Page 5: Technical Specifications

    3. TECHNICAL SPECIFICATIONS Model Fantastic M/AS / Fantastic M/SB Fruit Specifications Citrus fruit, diameter (standard pressing kit): 2.55 - 3.14 in (65- 80mm); Do not use frozen fruit! Only use juice fruit! Net Weight 126 lb Measurements W Footprint: 11”/W Handle: 22”/D: 19.5/H: 29.5” Drive Manual drive •...
  • Page 6: Machine Part Overview

    5. MACHINE PART OVERVIEW Fruit supply tunnel Locking lever (for fruit supply tunnel) Front cover Front cover screws, left and right Flywheel* Cross holder MTS (Manual Transport System) Peel bucket SCS knife Double cover *Flywheel Upper pressing elements and handle Lower pressing elements can be Peel ejectors...
  • Page 7: Setting Up Your Citrocasa Fantastic Eco

    Place the machine on a flat, level, and stable surface. Ensure that the surface can bear the weight of the machine (see technical specifications). • The Fantastic ECO has an adjustable base plate and can be operated either as a tabletop unit or with one of the following options: –...
  • Page 8 FLYWHEEL AND HANDLE: CHOOSING A COLOR FOR YOUR HANDLE LEVER: • Included in the original packaging are lever inserts in different colors (Pic 6) and strips of double-sided tape. • Clean the surface of the lever to improve the adhesive bond. •...
  • Page 9: Operating Your Citrocasa Fantastic Eco

    7. OPERATING YOUR CITROCASA FANTASTIC ECO To begin juicing, follow these steps: • Clean all the parts that come into contact with the juice prior to juicing for the first time. • Please refer to the Fruit Size Specifications on page 5 of this manual and use the sizing tool supplied (Pic 1). The fruit must be the same size as or larger than the smaller end of the tool (Pic 2) and it must be the same size as or smaller than the wider end of the tool (Pic 3).
  • Page 10: Cleaning Your Citrocasa Fantastic Eco

    • Wipe down the machine itself and the juicing area on a regular basis using warm water. If you are using a Citrocasa Fantastic Cabinet or a Citrocasa Counter Installation Kit, also be sure to clean the stainless steel peel chute and all cabinet/kit parts properly.
  • Page 11 STEP-BY-STEP CLEANING INSTRUCTIONS The below mentioned cleaning steps must be completed at least once every 24 hours. Frequent juicing will require more frequent cleaning. For optimal efficiency and hygiene, we recommend using a cleaning log. NOTE: All re-movable parts, except for the plastic front cover, can be placed in the dishwasher for cleaning! 1.
  • Page 12 Pull out the cross holder screw to separate the knife guide from the cross holder. You will have three individual parts: the cross holder, the knife guide and the screw. ATTENTION: When re-installing the cross holder, ensure that the blade rests completely in its proper position and that the screw is properly tightened by hand.
  • Page 13 14. Remove the MTS system. 15. Remove the MTS swiper by pressing the fixation clip and pulling the swiper out. 16. Press the lifting lever to remove the fruits sieve from the fruit sieve support. 17. Remove the peel bucket or peel chute. 18.
  • Page 14 CLEANING THE SB TAP Remove and disassemble the tap as follows: 20. Press the tap lever upwards and at the same time push it to the front. 21. Pull the bottom of the tap downwards. 22. Press the lever upwards and at the same time push it towards the back (22a) to release it (22b).
  • Page 15 ü DO NOT SPRAY OR HOSE DOWN THE MACHINE! ü DO NOT USE CHEMICAL CLEANING AGENTS OR ABRASIVES TO CLEAN THE HOUSING AND THE O-RING SEALS. USE FRESH, CLEAN, WARM WATER AND A SOFT TOWEL! ü ALL PARTS EXCEPT FOR THE ACRYLIC FRONT COVER CAN BE PLACED IN THE DISHWASHER FOR CLEANING.
  • Page 16: Spare Parts

    9. SPARE PARTS Be sure to provide machine model and serial number when ordering spare parts to ensure that the proper parts are supplied. For additional spare parts not listed below, please contact your customer service representative or Citrus America directly. Peel ejector left Peel ejector right SCS up &...
  • Page 17 Be sure to provide machine model and serial number when ordering spare parts to ensure that the proper parts are supplied. For additional spare parts not listed below, please contact your customer service representative or Citrus America directly. Fruit Supply Tunnel Upper pressing Lower pressing Fantastic ECO element (Standard element (Standard size) size) Art.
  • Page 18: Certifications

    Call our toll-free number: 1-855-MY-CITRO (855-692-4876) Citrocasa, TMP GmbH, and Citrus America, Inc. reserve the right to make technical changes and modifications to the equipment and specifications. We do our best to supply accurate and up to date information. Even so, from time to time information that is inaccurate or out of date may be in our...

This manual is also suitable for:

Fantastic m/asFantastic m/sb
