1
Top panel
(
x
mm)
1180 750
2 Table Leg
x4
(
735
x
50
mm)
Chair Right Leg
3
(850 x 45 mm)
x4
Chair Left Leg
4
850 x 45 mm)
x4
Front Frame
5
x4
(430 x 38 mm)
Seat
6
x4
(430 x 410 mm)
Top back rail
7
x4
(319 x 50 mm)
Middle back rail
8
(319 x 50 mm)
x4
Bottom back rail
9
x4
(319 x 50 mm)
Larger rail
10
x8
(354 x 50 mm)
Narrow thick rail
11
x8
(330 x 32 mm)
Narrow slim rail
12
x4
(316 x 23 mm)
