Puerto Rico - Double Bed Assembly Instructions - Please keep for future reference 658/3129 658/3136 Dimensions Width - 148.5cm Depth - 205cm Height - 110cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400 800 Issue 1 - 17/08/10... - Page 6 Safety and Care Advice Important Please read these instructions fully before starting assembly Check you have all the This product has been produced We do not components and tools listed on from natural timber; you may recommend the notice some variation in the grain pages 2 and 3.
- Page 7 Components - Panels Please check you have all the panels listed below 1 Headboard (110 x 148.5cm) 2 Footboard (88 x 148.5cm) 3 Side rail x 2 (188 x 11.2cm) 4 Centre rail (193.5 x 6.5cm) 5 Slats x 26 6 Middle support (68.2 x 6.5cm) (28.3 x 6.5cm)
- Page 8 Components - Fittings If you have damaged or missing components, call the Customer Helpline: 08456 400 800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 9 Assembly Instructions Step 1 Fixing metal brackets. Fix metal brackets into the pre drilled holes in the headboard footboard using screws Step 2 Assembling centre rail and inserting dowels. Attach centre rail into the pre drilled holes in the middle support using screws Insert dowels into the...
- Page 10 Assembly Instructions Step 3 Assembling side rails. Important: Two people are required for an easier assembly. Attach centre rail the metal bracket of headboard using bolt and nut With help, assemble side rails to headboard using fixings with the allen key as shown.
- Page 11 Assembly Instructions Step 5 Fix metal studs into the headboard Yes! footboard at the dimensions shown. 42mm 42mm Fix wooden covers into the holes in the headboard footboard as shown. Warning: While fixing wooden covers be careful not to damage them. Step 6 Assembling slats.
