Single Robe
234046
Assembly Instructions -
Please keep for future reference
Dimensions
Width - 50cm
Depth - 59cm
Height - 210cm
Important -
Please read these instructions fully before starting assembly
For all enquiries please contact : 0845 6002420
Ref. no HB 01.06 Date: 30/07/09
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos Single Robe 234046
Summary of Contents for Argos Single Robe 234046
- Page 1 Single Robe 234046 Assembly Instructions - Please keep for future reference Dimensions Width - 50cm Depth - 59cm Height - 210cm Important - Please read these instructions fully before starting assembly For all enquiries please contact : 0845 6002420 Ref. no HB 01.06 Date: 30/07/09...
- Page 2 Safety and care advice Important – Please read these instructions fully before starting assembly • Check you have all the • Assemble on a soft level • We do not components and tools listed on surface to avoid damaging the recommend the pages 2 and 3.
- Page 3 Components - Panels Please check you have all the panels listed below 1) Left end panel 2) Right end panel 3) Back panel 4) Top/Bottom Panels 5) Shelf 6) Structural plinth 7) Rear base support rail x1...
- Page 4 Components - Fittings For enquiries relating to spare parts please contact : 0845 6002420 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. Wooden dowel x 8 Metal dowel x 10 15mm Screw x 14...
- Page 5 Assembly Instructions Step 1 important Prepare panels The picture refers to the assembly of a left hand door. For right hand door, mount the hinge mounting plate on right end panel. Repeat with the right side panel Bottom use cams to top panel use Knock-in plastic fitting to bottom panel...
- Page 6 Assembly Instructions Step 2 Bottom Front Back Step 3...
- Page 7 Assembly Instructions Step 4 Insert back panels Step 5 Important: Fixing back panels The cabinet MUST be ‘square’ when the back is attached. Note: For additional stability secure back to height adjustable shelf after assembly (step 14)
- Page 8 Assembly Instructions Step 6 Step 7 Ø5mm...
- Page 9 Assembly Instructions Step 8...
-
Page 10: Care And Maintenance
A Guide to Wall Mounting & Fixings IMPORTANT: When drilling into walls always check that there are no hidden wires or pipes etc. Make sure that the screws and wall plugs being used are suitable for supporting your unit. Consult a qualified tradesperson if you are unsure. HINTS: 1) General Rule Always use a larger screw and wall plug if you are not sure. - Page 11 Assembly Instructions Step 10 Wall fixing WALL PLUG AND SCREW NOT INCLUDED Please see Guide to wall mounting Step 11 Decor end fixing Ø5 Skirting Profile...
- Page 12 Assembly Instructions Step 11 B Breakfronted configuration Ø5 Skirting Profile...
- Page 13 Assembly Instructions Step 12 Ø5 No end panel when fitting more than one robe unit. Colour specific plinth. Step 13 Modesty block...
- Page 14 Assembly Instructions Step 14 Shelf positioning Step 15 Cornice cutting + assembly 45° 45°...
- Page 15 Assembly Instructions Step 16 Application of hinges to door Repeat with the right side door Step 17 For classic door only Cover caps included with door...
- Page 16 Assembly Instructions Step 18 Blind holes are pre-drilled on the back face of the doors & drawers. Use these as a guide to drill through with 5mm. drill bit together with scrap piece of wood to avoid chipping the front face. Included with handle important HAVE YOU A...
- Page 17 Assembly Instructions Step 18B Blind holes are pre-drilled on the back face of the doors & drawers. Use these as a guide to drill through with 5mm. drill bit together with scrap piece of wood to avoid chipping the front face. Included with handle important ONLY CARRY OUT THIS STEP...
- Page 18 Assembly Instructions Step 19 Hang door CLICK PUSH Step 20 Door adjustment...
- Page 19 Assembly Instructions Step 21 Fit soft close mechanism to door hinge CLICK Adjustment dictates the position from which the door starts the slow motion closing...
-
Page 20: Cleaning Instructions
Assembly Instructions That's the Robe completed. Take care of your unit by using a damp cloth to clean it. Please remember to occasionally check that all Cams and Screws are tight. CLEANING INSTRUCTIONS This product has been manufactured using modern manufacturing methods and materials.
