Symmons FSTF367220 Operation & Maintenance Manual

Floor Standing Tub Filler
Operation & Maintenance Manual
Warranty
Limited Lifetime - to the original end
purchaser in consumer/residential
installations.
10 Years - for commercial/industrial
installations. Refer to
www.symmons.com/warranty for
complete warranty information.
Installation A) Wooden Subfloor With Access Underneath
Section A
Product Care
Clean finished trim area with a soft cloth using mild
soap and water or a non-abrasive cleaner and then
quickly rinse with water.
Sction A: (Steps 1-4)
1. Measure and mark centerlines for mounting
bracket installation using dimensions in the
subfloor(1 1/2" thick) where you would like the
faucet to be located.
2. Drill a hole 2" and (4x) 1/4" holes. Use the floor
flange(1) as a template.
3. Align with the holes of the floor flange(1) and
the holes in the floor and insert (4x) bolts(2).
4. From underneath, install the holding plate,
washers,lock washers, and nuts(4). Tighten
the nuts with a wrench.
