Symmons DURO FSTF367220 Operation & Maintenance Manual

FSTF367220
Floor Standing Tub Filler
Operation & Maintenance Manual
Model Numbers
☐
FSTF367220
Floor standing tub filler
Options/Modifications
☐
STN
Satin nickel finish
☐
MB
Matte black finish
☐
BBZ
Brushed bronze finish
Note: Append appropriate -suffix to model number.
Compliance
- ASME A11.18.1
- CSA B125.1
Dimensions
Note: Dimensions subject to change without notice.
A
C
B
DURO™
Feature Highlights
• Ceramic cartridge
• Push button to divert from spout to hand shower
• 60" flexible metal hose
• 1 mode hand shower
• 2.0 gpm (7.6 L/min) hand shower
• Floor Standing Tub Filler shall be metal construction
plated in standard polished chrome finish
• 5.3 gpm (20.1 L/min) at 45 psi tub filler
• 6.5 gpm (24.6 L/min) at 60 psi tub filler
Warranty
Limited Lifetime - to the original end
purchaser in consumer/residential
installations.
10 Years - for commercial/industrial
installations. Refer to
www.symmons.com/warranty for
c
complete warranty information.
D
E
F
Measurements
A
7", 178mm
B
2X1/2-14NPSM
C
32-5/16", 821mm
D
11-5/8", 296mm
E
8-7/8", 225mm
F
31-1/8", 790mm
