Figure 20
1. Center section cover
7
Removing the
Undercarriage Shroud
No Parts Required
g032030
Procedure
1. Remove the 7 flange-head bolts (5/16 x 7/8 inch)
and 7 washers (5/16 inch) that secure the rear of the
undercarriage shroud to the chassis of the machine
(Figure
22).
Note: Retain the flange-head bolts and washers for
installation in step
Shroud (page
14
Figure 21
5
of
24 Installing the Undercarriage
54).
G032041
g032041
