- Page 1 INFORMATION FOR FIRST AND SECOND RESPONDERS EMERGENCY RESPONSE GUIDE NIO EL7 ELECTRIC VERSION: 001...
- Page 2 Take the used battery to a recycling center or to your service center. ONLINE USER MANUAL This guide provides the basic operating instructions of NIO EL7. For owners who want insights and detailed information about the features and functions of the car, an in-depth online...
-
Page 3: Table Of Contents
6. In case of fire Page 19 7. In case of submersion Page 20 8. Towing / transportation / storage Page 20 9. Important additional information Page 22 10. Explanation of pictograms used Page 24 NIO EL7 Emergency Response Guide... -
Page 4: Rescue Sheet
0. Rescue sheet This Emergency Response Guide covers the NIO EL7 corresponding rescue sheet. 1. Identification / recognition WARNING Silent movement or instant restart capability exists until vehicle is fully shut down. EL7 Information Vehicle manufacturer NIO hotline Refer to the contact table... - Page 5 You can find the vehicle certification label in the lower area of the right B-pillar. Vehicle brand label: NIO EL7 Emergency Response Guide...
- Page 6 Instrument Cluster and Controls Electronic switches on interior Gear selector and center console control door handles panel Control panel for windows Wireless charging pad Steering wheel buttons - left Accelerator pedal Light control lever for turn Brake pedal signals and headlights Digital instrument cluster *NOTE Steering wheel buttons - right...
- Page 7 C, K or L. Voltage ranges related to those identifiers are as follows: C: AC ≤ 480V K: DC 50V to 500V L: DC 200V to 920V NIO EL7 Emergency Response Guide...
- Page 8 Vehicle Identification Number (VIN) You can also read the VIN from diagnostic instruments that pair with the vehicle (safety The vehicle identification number (VIN) is module diagnosis tool BD2): stamped on the right of the hood. Connect the diagnostic instrument to the diagnostic interface of the vehicle and turn it on.
- Page 9 Driving Motor Identification Labels The front driving motor identification label is The rear driving motor identification label is located on the lower side of the motor. located on the lower side of the motor. NIO EL7 Emergency Response Guide...
-
Page 10: Immobilisation / Stabilisation / Lifting
PARK button In case of accidents such as collisions, floods, Hazard warning light button and battery fires, contact NIO immediately after setting up the warning triangle and Open the cargo cover inside the trunk and wait for the rescue team. - Page 11 In case your vehicle is not connected to • vehicle from slipping. the Internet, you can contact NIO via the NIO app. NOTE When the vehicle is connected to the Internet, it will automatically make an emergency call if an accident occurs and the airbag inflates.
- Page 12 Go to Settings from the control bar at the WARNING bottom of the center display, and tap Driving > Jack Mode to maintain Make sure the jack is positioned the suspension at the current height correctly under the jack point. and avoid height changes during tire Failure to do so may damage replacement.
-
Page 13: Disable Direct Hazards / Safety Regulations
Goggles • Rubber insulating boots • Insulated tools • Chemical Protection In case of electrolyte leakage, wear the following protective equipment to prevent skin and facial injuries: Protective face shield • Chemical-resistant gloves • NIO EL7 Emergency Response Guide... - Page 14 2. Alternative Method Lift the hood, and support it with the prop rod. In case of service operation or emergency, pull the connector position assurance out according to arrow direction, then disconnect the plug to cut off the high voltage circuit. There are 2 ways to cut off the high voltage circuit: 1.
-
Page 15: Access To The Occupants
1. Length of seat cushion Toggle the button back and forth to adjust the length of the seat cushion. 2. Inclination angle of seat Turn this button to adjust the inclination angle of seat cushion. NIO EL7 Emergency Response Guide... - Page 16 Opening and Closing the Tailgate with the WARNING Center Display Before seat adjustment • Swipe right on the left edge of the center (forward and backward, display to enter the Quick Settings page, height, backrest, etc.), make then touch Rear Trunk to open the rear trunk. sure that there is sufficient safe space for the seat and Opening and Closing the Tailgate with the...
- Page 17 When the whole vehicle is locked, if the door conventional methods (such as a smart key needs to be opened in an emergency (for fob, keyless entry, NIO app, or NFC), you can example, when the electronic switch on the use the emergency key to unlock the driver- door handle fails or the vehicle falls into side door.
- Page 18 Windows Laminated glass Tempered glass Vehicle Cutting WARNING When professional rescuers perform cutting operations, they must use appropriate tools such as a hydraulic cutter and wear appropriate personal protective equipment to avoid serious injury. The vehicle pillars use aluminum castings to better protect the occupants in case of an impact. Please use proper tools to cut the pillars during a rescue.
-
Page 19: Stored Energy / Liquids / Gases / Solids
High voltage heater for climate control Charge port Airbag Airbag control unit Side curtain airbag cylinder High pressure air pump Structural reinforcement High pressure air tank Curtain airbags A/C compressor 12V battery Seat belt pretensioner mechanism NIO EL7 Emergency Response Guide... - Page 20 High Voltage Battery 12V Battery The vehicle is equipped with a 350V lithium- The 12V battery powers the Supplemental ion high voltage battery. Do not damage it Restraint System, windows, locks, when lifting from under the vehicle. When touchscreen, and vehicle lighting. using rescue tools, please take special care to avoid breaking the underbody.
-
Page 21: In Case Of Fire
Particular injury. attention should be paid when transporting the battery. If the vehicle fire doesn't involve the high voltage battery, you can use the fire extinguisher to put out the fire. NIO EL7 Emergency Response Guide... -
Page 22: In Case Of Submersion
7. In case of submersion Rescuing the Vehicle in Water If the vehicle body and chassis are not damaged, there will not be any additional CAUTION risks of electric shock. However, the rescue of When driving, do not submerge the vehicle a submerged vehicle should be carried out in deep water for a long period of time. - Page 23 Do not slam on the brake pedal or • accelerator pedal when exiting Tow/Wash Mode on the center display. NIO EL7 Emergency Response Guide...
-
Page 24: Important Additional Information
9. Important additional information Must read Thank you for choosing NIO's EL7 model (hereinafter referred to as "EL7"). EL7 is a smart electric vehicle. During your green journey with EL7, you will get a seamless and considerate user experience. Before starting your journey with EL7, it is recommended that you read the User Manual from the center display to get all the information you need to use the vehicle. - Page 25 This content gives you suggestions for better use of your vehicle. If you have any questions about this guide, please contact us by phone, or log on to the NIO official website to obtain the latest version of the EL7 User Manual.
-
Page 26: Explanation Of Pictograms Used
10. Explanation of pictograms used Warning high voltage Flammable Caution Hazardous to the human health Air-conditioning component Acute toxicity Electric vehicle Corrosives Bonnet Gases under pressure Boot Explosive Use thermal Infrared camera Use water to extinguish the fire...
