Summary of Contents for Azoteq IQ Switch ProxFusion IQS7211AEV01
- Page 1 IQ Switch ® ProxFusion ® Series IQS7211AEV01 USER GUIDE ® ® IQ Switch - ProxFusion Series Copyright © Azoteq (Pty) Ltd 2022. IQS7211AEV01 User Guide Page 1 of 7 All Rights Reserved. Revision 1.0 February 2022...
-
Page 2: Iqs7211Aev01 User Guide
Table of Contents IQS7211AEV01 USER GUIDE .......................... 1 INTRODUCTION ............................3 SETTING UP FOR THE IQS7211A STAMP ..................... 4 REFERENCE DESIGNS ........................... 6 Copyright © Azoteq (Pty) Ltd 2022. IQS7211AEV01 User Guide Page 2 of 7 All Rights Reserved. Revision 1.0... -
Page 3: Introduction
USB support, along with the CT210A and the relevant IQS7211A software Graphical User Interface (GUI) available to download from the Azoteq website. The purpose of the IQS7211AEV01 EV-Kit is to help application and development engineers in evaluating this IC’s capabilities. A picture of the evaluation kit is shown below. -
Page 4: Setting Up For The Iqs7211A Stamp
To interface the IQS7211A Stamp to a PC we advise using the CT210A. This EV Kit can be setup with the following steps: ➢ Download & Install GUI from Azoteq website ➢ Plug the stamp board into the CT210A as shown below Copyright ©... - Page 5 Series ➢ Connect the CT210A to the PC with a USB cable (use USB data cable only) ➢ Run the IQS7211A GUI (latest version available from the www.azoteq.com website) ➢ Click “Start Streaming” button ➢ GUI should look as follow.
-
Page 6: Reference Designs
IQ Switch ® ProxFusion ® Series Reference Designs Figure 3-1 IQS7211A QFN20 Stamp Layout Copyright © Azoteq (Pty) Ltd 2022. IQS7211AEV01 User Guide Page 6 of 7 All Rights Reserved. Revision 1.0 February 2022...
