1 Introduction
This user guide describes the basic operation of the
software from Azoteq. The GUI provides a platform for
and development engineers to visualise the real time data stream from the
Touch and Swipe Sensor.
2 Setup
GUI Software can be downloaded from the "Software and Tools" section on the
The IQS213
Azoteq website: www.azoteq.com
2.1 General Setup
Ensure that the
programming of OTP (One Time Programmable) options can be accomplished with the
Azoteq USBProg.exe software and CT210 (or later) USB dongle.
Connect the GND, VDDHI, RDY, SDA and SCL lines on an
the Azoteq CT210 (Configuration Tool) or DS100 (DataStreamer) USB dongle.
Note: Pull-Up resistors (typ. 10kΩ) may be required on I
Run the IQS213
