Page 1: Iqs7211Aev02A User Guide
IQ Switch ® ProxFusion ® Series IQS7211AEV02A USER GUIDE ® ® IQ Switch - ProxFusion Series Copyright © Azoteq (Pty) Ltd 2022. IQS7211AEV02A User Guide Page 1 of 12 All Rights Reserved. Revision 1.0 February 2022... -
Page 2: Table Of Contents
® ProxFusion ® Series Table of Contents IQS7211AEV02A USER GUIDE ........................1 INTRODUCTION ............................3 STAMPS ..............................4 TRACKPAD CAREFUL CONSIDERATION ..................... 6 SETTING UP FOR THE IQS7211A RECTANGLE TRACKPAD .............. 7 SETTING UP FOR THE IQS7211A FLOWER TRACKPAD ..............8 REFERENCE DESIGNS ........................... -
Page 3: Introduction
® ProxFusion ® Series Introduction This user guide describes the operation of the IQS7211AEV02A Evaluation Kit. The EV-Kit consists of five parts: ➢ IQS7211A Rectangle Trackpad x 1 ➢ IQS7211A Flower Trackpad x 1 ➢ CT210A x 1 ➢ IQS7211A Stamp x 2 ➢... -
Page 4: Stamps
To interface the IQS7211A Stamp to a PC we advise using the CT210A. This EV Kit can be setup with the following steps: ➢ Download & Install GUI from Azoteq website ➢ Plug the stamp board into the CT210A as shown below Copyright ©... - Page 5 Series ➢ Connect the CT210A to the PC with a USB cable (use USB data cable only) ➢ Run the IQS7211A GUI (latest version available from the www.azoteq.com website) ➢ Click “Start Streaming” button ➢ GUI should look as follow.
-
Page 6: Trackpad Careful Consideration
Take care in ensuring pin alignment is correct as shown in picture below. The pin on the right must line up directly below the black triangle (shown below as white triangle to clearly indicate) on the CT210A. Copyright © Azoteq (Pty) Ltd 2022. IQS7211AEV02A User Guide Page 6 of 12 All Rights Reserved. -
Page 7: Setting Up For The Iqs7211A Rectangle Trackpad
➢ Connect the CT210A to the PC with a USB cable (use USB data cable only) ➢ Run the IQS7211A GUI (latest version available from the www.azoteq.com website) ➢ Click “Start Streaming” button ➢ Click “IMPORT H FILE”... -
Page 8: Setting Up For The Iqs7211A Flower Trackpad
➢ Connect the CT210A to the PC with a USB cable (use USB data cable only) ➢ Run the IQS7211A GUI (latest version available from the www.azoteq.com website) ➢ Click “Start Streaming” button ➢ Click “IMPORT H FILE”... -
Page 9: Reference Designs
IQ Switch ® ProxFusion ® Series Reference Designs Figure 6-1 IQS7211A Rectangle Trackpad Layout Copyright © Azoteq (Pty) Ltd 2022. IQS7211AEV02A User Guide Page 9 of 12 All Rights Reserved. Revision 1.0 February 2022... - Page 10 IQ Switch ® ProxFusion ® Series Figure 6-2 IQS7211A Flower Trackpad Layout Copyright © Azoteq (Pty) Ltd 2022. IQS7211AEV02A User Guide Page 10 of 12 All Rights Reserved. Revision 1.0 February 2022...
- Page 11 IQ Switch ® ProxFusion ® Series Figure 3 IQS7211A QFN20 Stamp Layout Copyright © Azoteq (Pty) Ltd 2022. IQS7211AEV02A User Guide Page 11 of 12 All Rights Reserved. Revision 1.0 February 2022...
- Page 12 Azoteq assumes no liability for any damages or injury arising from any use of the information or the product or caused by, without limitation, failure of performance, error, omission, interruption, defect, delay in operation or transmission, even if Azoteq has been advised of the possibility of such damages.
- Page 13 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: Azoteq IQS7211AEV02A-S...
