1 Introduction
This user manual describes the operation of
the IQS132/33/43EV02 Evaluation Kit.
EV-Kit is manufactured in four parts, consisting
of a
mainboard, and three separate plug-in
module boards. To adjust IC OTP settings, the
main board can be interfaced to any personal
computer with the Azoteq Configuration Tool
(CTxxx), and making the adjustments by
means of the USBProg software. The purpose
of the IQS132/33/43EV02 EV-Kit is to help
application and development engineers
evaluating the IQS132, IQS133 and IQS143
proximity and touch sensors.
2 EV-Kit Mainboard
Figure
mainboard and the three supplied controller
modules. The mainboard supplies power and
other functions to the controller module boards
and is easily operated.
desired module board into the mainboard and
turn on the mainboard by means of the on/off
slide switch. Features included in the EV-Kit
mainboard:
Modular design: Connect one of the
supplied IC modules into the mainboard,
or
prototyping
Reference designs for IQS132, IQS133
and IQS143 with user proximity & touch
detection ability
LEDs to indicate
