Page 1: Iqs72Xxxev01 User Guide
Series ® IQS72xxxEV01 USER GUIDE IQ Switch - ProxFusion Series ® ® CT210A is only included in the EV04 kit Copyright © Azoteq (Pty) Ltd 2019. IQS72xxxEV01 User Guide Page 1 of 12 All Rights Reserved. Revision 1.0 June 2021... -
Page 2: Table Of Contents
IQS7222A STAMP ............................ 6 IQS7222B STAMP ............................ 7 IQS7222C STAMP ............................ 8 IQS7228A STAMP ............................ 9 REFERENCE DESIGNS ......................... 10 Copyright © Azoteq (Pty) Ltd 2019. IQS72xxxEV01 User Guide Page 2 of 12 All Rights Reserved. Revision 1.0 June 2021... -
Page 3: Introduction
IQS72xxxEV01 EV-Kit is to help application- and development engineers to a range of Azoteq’s IC’s. Figure 1-1: IQS7211A Stamp, IQS7222A Stamp, IQS7222B Stamp, IQS7222C Stamp and IQS7228A Stamp with Connector board Copyright © Azoteq (Pty) Ltd 2019. IQS72xxxEV01 User Guide Page 3 of 12 All Rights Reserved. -
Page 4: Setting Up For The Iqs72Xxx Stamp
IQS72xxx GUI (latest version available from https://www.azoteq.com/design/software-and- tools/) to evaluate the capabilities. CT210A is only included in the EV04 kit Arduino not included Copyright © Azoteq (Pty) Ltd 2019. IQS72xxxEV01 User Guide Page 4 of 12 All Rights Reserved. Revision 1.0 June 2021... -
Page 5: Iqs7211A Stamp
ProxFusion Series ® IQS7211A Stamp Connect IQS7211A Stamp • Run IQS7211A GUI (available from https://www.azoteq.com/design/software-and-tools/) • Click “Start Streaming” button • GUI should resemble the below image • 6 x 5 Trackpad array of channels come with the default setup. -
Page 6: Iqs7222A Stamp
IQ Switch ® ProxFusion Series ® IQS7222A Stamp Connect IQS7222A Stamp • Run IQS7222A GUI (available from https://www.azoteq.com/design/software-and-tools/) • Click “Start Streaming” button • GUI should resemble the below image • Copyright © Azoteq (Pty) Ltd 2019. IQS72xxxEV01 User Guide Page 6 of 12 All Rights Reserved. -
Page 7: Iqs7222B Stamp
® ProxFusion Series ® IQS7222B Stamp Connect IQS7222B Stamp • Run IQS7222B GUI (available from https://www.azoteq.com/design/software-and-tools/) • Click “Start Streaming” button • GUI should resemble the below image • 20 Channels are enabled by default. Copyright © Azoteq (Pty) Ltd 2019. -
Page 8: Iqs7222C Stamp
IQ Switch ® ProxFusion Series ® IQS7222C Stamp Connect IQS7222C Stamp • Run IQS7222C GUI (available from https://www.azoteq.com/design/software-and-tools/) • Click “Start Streaming” button • GUI should resemble the below image • Copyright © Azoteq (Pty) Ltd 2019. IQS72xxxEV01 User Guide Page 8 of 12 All Rights Reserved. -
Page 9: Iqs7228A Stamp
IQ Switch ® ProxFusion Series ® IQS7228A Stamp Connect IQS7228A Stamp • Run IQS7228A GUI (available from https://www.azoteq.com/design/software-and-tools/) • Click “Start Streaming” button • GUI should resemble the below image • Copyright © Azoteq (Pty) Ltd 2019. IQS72xxxEV01 User Guide Page 9 of 12 All Rights Reserved. -
Page 10: Reference Designs
Azoteq IQ Switch ® ProxFusion Series ® Reference Designs Figure 8-1 QFN20 Stamp layout Figure 8-2 CSP18 stamp layout Copyright © Azoteq (Pty) Ltd 2019. IQS72xxxEV01 User Guide Page 10 of 12 All Rights Reserved. Revision 1.0 June 2021... - Page 11 Azoteq IQ Switch ® ProxFusion Series ® Figure 8-3 Base board layout Copyright © Azoteq (Pty) Ltd 2019. IQS72xxxEV01 User Guide Page 11 of 12 All Rights Reserved. Revision 1.0 June 2021...
- Page 12 Azoteq assumes no liability for any damages or injury arising from any use of the information or the product or caused by, without limitation, failure of performance, error, omission, interruption, defect, delay in operation or transmission, even if Azoteq has been advised of the possibility of such damages.
