ASSEMBLY
INSTRUCTIONS
Thank you for purchasing this quality product. Place all wooden parts on a clean and smooth surface such
as a rug or carpet to avoid the parts from being scratched. Be sure to check all packing materials carefully
for small parts may have come loose inside the carton during shipment, clarify and count all parts and
compare with the parts list below. Do not tighten all screws / bolts until all completely assembled.
Parts List
No.
Description
A
Upper left side frame
B
Lower left side frame
C
Upper right side frame
D
Lower right side frame
E
Lower Crossbar
F
Upper Crossbar
G
Top Panel
H
Shelf #1
I
Shelf #2
J
Shelf #3
K
Drawer Storage Box
L
Bottom Panel
Important Notes
*Keep all hardware parts out of reach
of children!
*Tighten screws periodically! With the
use of this product bolts and screws
may become loose over time!
*Don't attempt to modify parts!
Cleaning instruction: Clean using soft cloth
Q.ty
No. Description
1PC
1
Allen Key
1PC
2
Allen Bolt
1PC
3
Spring Washer
1PC
4
Flat Washer
2PCS
5
Screws
2PCS
6
Anti-tip kit
1PC
NOTE : YOU WILL ALSO NEED A
1PC
SCREWDRIVER (NOT PROVIDED)
1PC
These parts are cumbersome and heavy. Therefore, two
people are recommended in order to prevent personal injury
1PC
and insure the parts are not damaged during the assembly.
1PC
1PC
A
B
Page 1/6
Hardware List
Sketch
Attached inside the drawer box
E
E
H
I
J
K
L
F
ITEM NO.: T147-20
Bookcase
Size
Q.ty
1pc
M4
32pcs
1/4" x 16mm
32pcs
Ø12 x 1/4" x 1mm
32pcs
Ø16 x 1/4" x 2mm
#4 x 12mm
14pcs
1SET
G
C
D
F
Made in Vietnam
Advertisement
Related Manuals for ROOMS TO GO T147-20
Summary of Contents for ROOMS TO GO T147-20
- Page 1 ASSEMBLY ITEM NO.: T147-20 INSTRUCTIONS Bookcase Thank you for purchasing this quality product. Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the parts from being scratched. Be sure to check all packing materials carefully for small parts may have come loose inside the carton during shipment, clarify and count all parts and compare with the parts list below.
- Page 2 ASSEMBLY ITEM NO.: T147-20 INSTRUCTIONS Bookcase STEP 1: Bolt (2) x 4 A / C STEP 2: B / D Bolt (2) x 4 Cleaning instruction: Clean using soft cloth Made in Vietnam Page 2/6...
- Page 3 ASSEMBLY ITEM NO.: T147-20 INSTRUCTIONS Bookcase STEP 3: Bolt (2) x 9 STEP 4: Bolt (2) x 4 Cleaning instruction: Clean using soft cloth Made in Vietnam Page 3/6...
- Page 4 ASSEMBLY ITEM NO.: T147-20 INSTRUCTIONS Bookcase STEP 5: Bolt (2) x 9 STEP 6: Screws (5) x 8 Cleaning instruction: Clean using soft cloth Made in Vietnam Page 4/6...
- Page 5 ASSEMBLY ITEM NO.: T147-20 INSTRUCTIONS Bookcase Screws (5) x 6 STEP 7: Bolt (2) x 2 STEP 8: Cleaning instruction: Clean using soft cloth Made in Vietnam Page 5/6...
- Page 6 ASSEMBLY ITEM NO.: T147-20 INSTRUCTIONS Bookcase STEP 9: STEP 10: Anti Tip Kit (Inside White Plastic Bag) For product and personal safety, a furniture tipping restraint kit has been included with this unit which can help to minimize the risk of the unit accidentally tipping forward.
