LOW RAIL POSITION
SKU #
34626878
34726870
35026877
TWIN CUBBY HEADBOARD PARTS LIST
A
Headboard
Headboard Leg
B
( L / R )
C
Stretcher
This product is manufactured by HOUS for
DO NOT USE SUBSTITUTE PARTS. PLEASE CONTACT YOUR RETAIL STORE OR WWW.ROOMSTOGO.COM
Version #1 - JUN 1 . 2024
VIVIEN
TWIN CUBBY BED
3402687P - TWIN CUBBY BED - WIREBRUSH GRAY
ITEM#
2687-17H
2687-17F
2687-17R
1PC
2PCS
1PC
WITH SERVICE OR PARTS REPLACEMENT REQUEST
ITEM DESCRIPTION
TWIN CUBBY HEADBOARD
TWIN PANEL FOOTBOARD
TWIN / FULL RAILS
TWIN PANEL FOOTBOARD PARTS LIST
D
Footboard
E
Slat
TWIN / FULL RAILS PARTS LIST
F
Twin / Full Rails
HIGH RAIL POSITION
Q'TY
1
1
1
1PC
5PCS
2PCS
Page 1 of 4
