*** Thank you for purchasing this quality product. Be sure to check all packaging materials
carefully for small parts which may have come loose inside the carton during shipment.
Identify and count all parts and compare with the parts list / hardware list below.
PARTS LIST
1
Mirror: 1pc
HARDWARE LIST
A
M6x35mm
Spring Washer:
Bolt : 8pcs
8pcs
ASSEMBLY TIPS:
1. Remove hardware from box and sort by size.
2. Please check to see that all hardware and parts are present prior start of assembly.
3. Please follow attached instructions in the same sequence as numbered to assure fast and easy assembly.
STEP 1
Hardware Pack Location: Inside Mirror
MIRROR , SKU #32273687 & DRESSER, SKU #32173685
ASSEMBLY INSTRUCTIONS
TCHI 7368-2 MIRROR SKU #32273687
TCHI 7368-1 DRESSER SKU# 32173685
2
Mirror Support
Rail: 2pcs
Flat Washer:
8pcs
2
B
M4 Allen Key :
1pc
2
A
B
x4
Page 1 of 2
