PARTS LIST
1
Side rails
2
Full slats
3/19/2021
P A R T S L I S T
QTY
PARTS LIST
2 Pcs
3
Twin bookcase headboard
4 Pcs
4
Full footboard
5
Trundle bed (Optional)
3452360P FULL BOOKCASE WALL BED WALNUT
RTG SKU #
32723608
32723608
35123607
35123607
35223609
38100234
35323601
RTG SKU #
34713265
34713265
35113264
35113264
35213266
38100234
35313268
QTY HARDWARE LIST
A
1 1/4" Screws
2 Pc
B
Allen wrench
C
30mm conector
2 Pc
D
17mm cup nut
1 Pc
STYLE #
ITEM DESCRIPTION
3260812 TWIN BOOKCASE HEADBOARD
3260812 TWIN BOOKCASE HEADBOARD
3260815 FULL FOOTBOARD
3260815 FULL FOOTBOARD
3260771 2 PC. SIDE RAILS
100-646
FULL SLAT PACK (4)
3260744 TRUNDLE BED OPTIONAL
3451326P FULL BOOKCASE WALL BED WHITE
STYLE #
ITEM DESCRIPTION
3261812 TWIN BOOKCASE HEADBOARD
3261812 TWIN BOOKCASE HEADBOARD
3261815 FULL FOOTBOARD
3261815 FULL FOOTBOARD
3261771 2 PC. SIDE RAILS
100-646
FULL SLAT PACK (4)
3261744 TRUNDLE BED OPTIONAL
QTY
TOOLS NEEDED
Phillips screwdriver (not included)
8 Pcs
Allen wrench (included)
1 Pc
2 Pcs
2 Pc
Page 17 of
19
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ROOMS TO GO 3452360P
Summary of Contents for ROOMS TO GO 3452360P
- Page 1 P A R T S L I S T 3452360P FULL BOOKCASE WALL BED WALNUT RTG SKU # STYLE # ITEM DESCRIPTION 32723608 3260812 TWIN BOOKCASE HEADBOARD 32723608 3260812 TWIN BOOKCASE HEADBOARD 35123607 3260815 FULL FOOTBOARD 35123607 3260815 FULL FOOTBOARD 35223609 3260771 2 PC.
- Page 2 ASSEMBLY INSTRUCTIONS STEP 1 Loosen bolts in footboard posts (1/4" approx.) do not remove, BOLTS ARE PRE-ASSEMBLED. STEP 2 Assemble side rails STEP 4 STEP 3 tighten all bolts Install slats, one on each space between the small blocks, then fasten with 1 1/4" screws. MAKE SURE ALL BOLTS ARE TIGHTENED COMPLETELY Page 18 of 19 3/19/2021...
- Page 3 ASSEMBLY INSTRUCTIONS STEP 5 STEP 6 Place both headboards next to each other then slide doors to center. Fasten both headboards as shown. STEP 7 STEP 8 For optional Trundle bed follow assembly instructions inside Place all pieces in the room's desired position Trundle bed box, then slide under the bed as shown.
