ASSEMBLY
INSTRUCTIONS
Thank you for purchasing this quality product. Place all wooden parts on a clean and smooth surface such
as a rug or carpet to avoid the parts from being scratched. Be sure to check all packing materials carefully
for small parts may have come loose inside the carton during shipment, clarify and count all parts and
compare with the parts list below. Do not tighten all screws / bolts until all completely assembled.
Parts List
No.
Description
A
Tray Top
B
Drawer Frame
C
Side Frame
D
Upper Crossbar
E
Lower Crossbar
Bottom Panel
F
NOTE : YOU WILL ALSO NEED A SCREWDRIVER (NOT PROVIDED)
These parts are cumbersome and heavy. Therefore, two people are recommended in order to prevent
personal injury and insure the parts are not damaged during the assembly.
Important Notes
*Keep all hardware parts out of reach
of children!
*Tighten screws periodically! With the
use of this product bolts and screws
may become loose over time!
*Don't attempt to modify parts!
Cleaning instruction: Clean using soft cloth
Q.ty
No. Description
1PC
1
Allen Key
1PC
2
Allen Bolt
2PCS
3
Spring Washer
2PCS
4
Flat Washer
2PCS
5
Screws
1PC
6
Screws
7
Anti-tip kit
C
E
Page 1/5
Hardware List
Sketch
M4
1/4" x 16mm
Ø12 x 1/4" x 1mm
Ø16 x 1/4" x 2mm
#4 x 16mm
#4 x 12mm
Attached inside the drawer box
A
D
F
ITEM NO.: T147-05
Sofa / Console Table
Size
Q.ty
1pc
14pcs
14pcs
14pcs
10pcs
8pcs
1SET
D
B
E
Made in Vietnam
C
