Differential Electrometer; Voltage Measurement - Gamry Instruments Interface 1010 Operator's Manual

Unity Gain Bandwidth
Slew Rate

Differential Electrometer

Max Input Voltage
Input Current
Input Resistance
Differential (between inputs)
Common Mode (input to ground)
Input Capacitance
Differential (between inputs)
Common Mode (input to ground)
Bandwidth (–3 dB)
CMMR
DC to 10 kHz
10 kHz to 1 MHz

Voltage Measurement

A/D Full-scale Ranges
Resolution
Zero Offset Error
Gain Error
Offset Range
Post-Offset Gain
Interface 1010 Specifications
Typ 980, 260, 40, 4, 0.4
Typ 10, 4.5, 0.6, 0.06, 0.006
Min ±12
Max 20
Typ
20
1
Typ
0.3
12
Min 15
Min
86
60
Typ ±12.0, ±3.0
Typ 400, 100, 10, 1
Max 1
Max 0.3
Typ ±3.2768, ±13.1072
Typ 1×, 10×, 100×
68
kHz Notes 3, 4
V/µs Notes 3, 4
volts Note 5
pA Note 6
Note 5
TΩ
TΩ
Note 5
pF
pF
MHz Note 8
Note 9
dB
dB
V Notes 5, 10
µV/bit
mV Note 11
% Note 11
V Note 12
