- Page 1 macchine agricole Rotary Tiller USZ1600200/0 Operating Maintenance Manual Read these operating instructions carefully before using the machine...
-
Page 2: Table Of Contents
Instruction for use ................................9 SECTION 5 Maintenance ..................................14 SPARE PARTS TABLES ..........................17 Data shown on the machine identification plate. Technical assistence centre authorised by BREVIGLIERI Spa to be contacted for all Model: technical assistance needs. Serial number: Dealer:... -
Page 3: Descriptions And Main Features
” rotary tiller (also called machine in the text) manufactured by BREVIGLIERI SpA of Nogara (VR) Italy, also called Manufacturer in the text. The information and indications do not give a full description of the various components or a detailed illustration of how they operate. -
Page 4: Warranty Exclusions
macchine agricole 1.2.1 WARRANTY EXCLUSIONS (Besides the circumstances indicated in the supply contract) the warranty becomes void: ▪ When the damage can be ascribed to insufficient maintenance. ▪ When, following repairs made by the user without the Manufacturer’s consent or owing to the installation of spurious spare parts, the machine has been subjected to changes and the damage is ascribable to these changes. -
Page 5: Description
macchine agricole DIMENSIONS Fig.2 Model 65” 50” - 125 73” 58” - 145 36” 33” 81” 65” - 165 89” 74” - 185 1.3.1 DESCRIPTION Rotary Tiller mainly comprises a metal framework with a central linkage and three-point hitches (1 Fig. 1), and a bladed rotor situated in the lower part (9 Fig. -
Page 6: General Safety Regulations
macchine agricole 1.5 NOISE LEVEL The noise level (overhead noise) has been measured in compliance with the current laws, with the following results: ▪ Acoustic pressure LpAm (A) ............................ dB 82 ▪ Acoustic power LwA (A) ............................dB 98 CAUTION The operator is advised to wear adequate ear muffs as personal protective equipment to prevent damage to his hearing during daily work with the machine. -
Page 7: Safety And Accident Preventing Rules
macchine agricole Carefully Before Sharp Danger of read the proceeding with objects lower limbs instruction maintenance could be being cut manual operations, thrown off. stop Keep before the machine, lower up by the at a safety beginning it to the ground distance machine. - Page 8 macchine agricole ▪ When driving round bends with and without the machine, take care of the centrifugal force exercised when the center of gravity is in a different position. ▪ Check the rpm rate before engaging the power take-off. Do not switch the 540 rpm rate with the 1000 rpm one. ▪...
-
Page 9: Transport And Handling
macchine agricole SECTION 3 Transport and handling 3.1 TRANSPORT AND HANDLING CAUTION If the machine, hitched to the tractor, must circulate on the public roads, comply with the Highway Code regulations in force in the country in which the machine itself is used. The machine must be raised at least 40 cm from the ground for road transport. -
Page 10: Driveline
macchine agricole «Section 2» about safety. Before beginning work, make sure that the machine is in order, that the lubricating oils are at the right level and that all parts subject to wear and deterioration are fully efficient. Also make sure that the guards are correctly positioned. DANGER Adjustments and operations required to prepare the machine for work must always be carried out with the machine off and blocked. -
Page 11: Work Position
macchine agricole CAUTION If the clutch still slips even when all the nuts have been tightened, the friction plates must be changed as they could be worn or because the springs have become slack. Never fully tighten the nuts as this eliminates the function of the springs and clutch itself, to the detriment of the transmission components. -
Page 12: During Work
macchine agricole 0,2 T Fig. 5 4.4 DURING WORK Proceed in the following way after you have correctly hitched the machine, sat down in the driver’s seat of the tractor and started the tractor engine: ▪ Raise the machine about 10 cm from the ground so that the rotor does not touch the vegetation that needs to be cut ▪... -
Page 13: Tools
macchine agricole Cut plants shredded to much ▪ Slightly lift the cutter from the ground, adjusting the height with the wheels (the blades of the cutter must not touch the ground). ▪ Increase the ground speed. Cut plants not shredded enough ▪... -
Page 14: Maintenance
macchine agricole 4.6.1 PARKING To park the machine and unhitch it from the tractor, the operator must: ▪ Make sure that no one is standing or crossing the place where the machine will be parked ▪ Make sure that the place in which the machine is to be parked is suitable, flat and uncluttered ▪... -
Page 15: Lubrication
macchine agricole depending on the type of service, whether the environment is dirty or not, seasonal factors, etc. The servicing operations must obviously be carried out more frequently in heavier duty service conditions. CAUTION Before injecting lubricating grease into the grease nipples, carefully clean the unions to prevent mud, dust or foreign bodies from mixing with the grease as this would reduce or even annul its lubricating effects. -
Page 16: Preparing For Storage
macchine agricole 5.3 PREPARING FOR STORAGE Proceed with the following operations at the end of the season or if the machine is to remain idle for a long period of time: ▪ Wash all fertilizers and chemical products from the machine and dry it ▪... - Page 17 macchine agricole • S P A R E P A R T S T A B L E S • Table 1 Frame ............................... 18 Table 2 Three-point hitch ............................20 Table 3 Gear box ..............................22 Table 4 Chain side transmission ..........................24 Table 5 Geared side transmission ..........................
- Page 18 macchine agricole - 18 -...
- Page 19 macchine agricole - 19 -...
- Page 20 macchine agricole - 20 -...
- Page 21 macchine agricole - 21 -...
- Page 22 macchine agricole - 22 -...
- Page 23 macchine agricole - 23 -...
- Page 24 macchine agricole - 24 -...
- Page 25 macchine agricole - 25 -...
- Page 26 macchine agricole Table 5 - 26 -...
- Page 27 macchine agricole Table 5 POS. CODE DESCRIPTION Z1600156 CASE BOTTOM FOR GEARS VERSION Z1600170 GEAR Z=35 Z1600159 GEAR Z=31 Z1600157 GEAR Z=20 0055254 SNAP RING Ø85 INNER 0012028 SNAP RING Ø45 OUTER 8066295 BEARING NUP 209 EC 45.85.19 8066290 SPACER RING 45x56X3 - 27 -...
- Page 28 macchine agricole - 28 -...
- Page 29 macchine agricole - 29 -...
- Page 30 macchine agricole - 30 -...
- Page 31 macchine agricole - 31 -...
- Page 32 macchine agricole - 32 -...
- Page 33 macchine agricole - 33 -...
- Page 34 • • ..................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
- Page 35 • • ..................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
- Page 36 Via Labriola, 2 - 37054 NOGARA (Verona) - ITALY Phone +39 0442 537402 - Fax +39 0442 537444 www.breviglieri.com - export@breviglieri.com...
