SERIES ‛A' & ‛AA' CONTINUOUS CURTAIN ROLLER DOORS
For all popular sizes of garage openings
Your Gliderol Roller door is designed to highest engineering standards and manufactured from high quality materials. If it is installed in accordance with
the instructions given in this manual it will give many years of service with a minimum of maintenance.
Warning! No guarantee will be given or responsibility accepted by the manufacturer if the door is not installed by an authorised Gliderol Installer.
PLEASE FOLLOW THE INSTRUCTIONS CAREFULLY
Branches
Victoria: Gliderol Garage Doors, 23 Kitchen Rd, Dandenong, VIC 3175. Phone: 03 97935455 Fax: 03 9706 8492
NSW: Gliderol Garage Doors, 45 Sammut St, Smithfield, NSW 2164. Phone: (02) 9725 1033 Fax: (02) 9725 1115
Queensland: Gliderol Garage Doors, 241 Elliott road Banyo, QLD 4014. Phone: 07 3260 9000 Fax: 07 3260 9055
Western Australia: Gliderol Garage Doors, 21 Prindiville Dr, Wangara, WA 6065. Phone: 08 94093000 Fax: 08 94093200
New Zealand: Gliderol Garage Doors, 12 Cape Hill Road, Pukekohe, Auckland NZ. Phone: 09 835 0211Fax: 09 237 0440
UK: Gliderol Garage & Industrial Doors Ltd. 1 Davy Drive, North West Industrial Estate, Peterlee Co, Durham, SR8 2JF UK. Phone: 1915 18 0455 Fax: 1915 18 0548
1
PREPARATION
Remove all parts. THE WRAPPING HOLDING THE DOOR MUST NOT BE CUT AT THIS STAGE.
The doors are positioned inside the opening and, therefore, overlap the opening on each side by 25mm for series A and 50mm for Series AA doors. A
minimum of 75mm is required between the opening and the side wall for Series A doors, 150mm for Series AA.
Before commencing, measure both the opening and the door curtain and mark the overlap on the wall to facilitate the fixing of brackets and guides.
2
AFFIXING MOUNTING BRACKETS
The minimum headroom required between the underside of the rafters and the top of the opening is
400mm for Series A doors and 450mm for Series AA doors.
Firmly secure one of the mounting brackets with appropriate fixings for the material you are fixing to,
(Refer table 2.0 for maximum pull out strength requirements while selecting fixings). It is important that
the outside face (smooth side) of the angle brackets faces the side wall of the garage.
The clearance on either side between the door curtain and mounting brackets is 10mm minimum and
100mm maximum. (Manual Doors Only)
The top of the bearing surface of the mounting brackets should be 150mm from the top of the opening,
and 250mm minimum from the underside of the rafters. In the event of shallower headroom, the
250mm dimensions must be maintained. Shallower headroom's down to 300mm can be maintained,
but will result in the underside of the rolled up door showing when the door is in the open position.
The second mounting bracket should then be positioned. The use of a line level or spirit level and
straight edge is recommended as IT IS VITAL THAT THE BRACKETS ARE EXACTLY LEVEL WITH
EACH OTHER, otherwise the door will not sit square. The minimum 250mm dimension must be
maintained.
Installation Instructions - Series A & AA Roller doors, Page-1
SPECIFICATION AND
INSTALLATION INSTRUCTIONS
Made under license Aust Patent No. 413178 and Patent Application No. 483904
GLIDEROL GARAGE DOORS
32 Jacobsen Crescent Holden Hill SA 5088
Phone (08) 8261 9633 Fax (08) 8261 9700
Fig- 1
