- Page 1 www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk...
-
Page 2: Table Of Contents
www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk Contents 1. Symbols 2. General warnings 2.1 Safety requirements for assembly and first use 3. Terms and conditions 4. Area of application 5. Guidelines 6. Fixing material building 7. System summary 7.1 Pre-assembled rail set 7.2 Springmatrix EXS70 7.3 Standard hardware box 8. -
Page 3: Symbols
www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk 1. Symbols Danger Attention Additional manuals 2. General warnings This manual has been prepared for use by qualified personnel and therefore not by trainees or “do it yourselfers” In case of doubt about the assembly and/or maintenance, please contact DOCO International To avoid severe personal injury, carefully read and observe all indications and warnings in this manual. -
Page 4: Guidelines
www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk damage. 5. Guidelines DOCO International had carried out the “Product Test“ of this door (Initial Type Testing = ITT) by the SP institute in Sweden, known as Notified Body No. 0402. Documents regarding this ITT can, in consultation with DOCO, be transferred to the company which produces the door. - Page 5 www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk...
- Page 6 www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk...
- Page 7 www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk...
- Page 8 www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk NOTE “C” is pre fixed screws AA (115001) – BB (115002) www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk...
- Page 9 www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk...
- Page 10 www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk AA - BB Before fitting panels ensure weather seal is screwed CC (115003) – DD (115004) www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk...
- Page 11 www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk G (24624) Pre-fitted springs connection plates 115005 www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk...
- Page 12 www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk PLEASE NOTE TRACK MAY DIFFER FROM THAT SHOWN IN DIAGRAM Attach curve to guide using nuts and bolts E and B www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk...
- Page 13 www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk...
- Page 14 www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk OTE: Ensure diagonal dimensions (A=B) are exactly square and corners are 90 degrees www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk...
- Page 15 www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk On Side Mount this bracket is to be used 24622 www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk...
- Page 16 www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk A 14019 x 4 T (25052) D 14027 x 2 www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk...
- Page 17 www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk V 1152 xx U 15008.1 JJ (115011) T 25052 – Roller carrier PLEASE NOT When installing bottom rollers (L/hand + R/hand) ensure panel is evenly spaced between guides using the “Distance Rings” supplied www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk...
- Page 18 www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk PLEASE NOT When building stack (panel) use distance rings to ensure panels are equil between the guides. W (25333) www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk...
- Page 19 www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk PLEASE NOT When installing bottom rollers (L/hand + R/hand) ensure panel is evenly spaced between guides using the “Distance Rings” supplied www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk...
- Page 20 www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk...
- Page 21 www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk CC - DD AA - BB FF (115007) www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk...
- Page 22 www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk CC - DD AA - BB www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk...
- Page 23 www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk...
- Page 24 www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk EE (115006) www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk...
- Page 25 www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk...
- Page 26 www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk...
-
Page 27: Assembly
www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk 10. Handover Handover the following documents to advise the end user: - This manual (assembly, maintenance and disassembly) - Declaration of conformity (in accordance with EN-13241-1) for automation if supplied (see 11) - Inform the end user how to handle in case of malfunctions 10.1. -
Page 28: Disassembly
www.samsondoors.co.uk 0800 328 6250 www.samsondoors.co.uk 11.1 Operator settings Adjustment to the operator should be carried out in accordance with the operator manufacturer’s manual. Please note that our hardware kits have been CE approved for use with the operators specified in our ITT report and enclosure B.
