- Page 1 OperatiOn and installatiOn FlOOrstanding dHW cylinder » sBB 301 Wp (gB) » sBB 302 Wp (gB) » sBB 401 Wp sOl (gB) » sBB 501 Wp sOl (gB)
-
Page 2: Table Of Contents
cOntents | OperatiOn general inFOrMatiOn General information OperatiOn General information �����������������������������������������2 document information 1.1 Document information � ����������������������������������������� 2 1.2 Safety information � ���������������������������������������������� 2 The chapter "Operation" is intended for the equipment user and 1.3 Other symbols in this documentation ����������������������� 3 the heating contractor. 1.4 Units of measurement ������������������������������������������ 3 Safety � ���������������������������������������������������������3 The chapter "Installation" is intended for the heating contractor. 2.1 Intended use � ����������������������������������������������������� 3 2.2 Safety information � ���������������������������������������������� 3 Read these instructions carefully before using the appliance and retain them for future reference. -
Page 3: Operation
OperatiOn saFety Other symbols in this documentation safety Read the text next to this symbol carefully. intended use The appliance is specifically designed for heating DHW with heat pumps. symbol Appliance disposal Any other use beyond that described shall be deemed inappropriate. Observation of these instructions is also part of the correct use of this appliance. Any modifications or conversions to the appliance void all warranty rights. » These passages and the "»" symbol indicate that you have to do something. The action you need to take is described step safety information by step. – - Passages with the " " symbol show you lists of items. DANGER Scalding There is a risk of scalding at outlet temperatures in excess of 43 °C. -
Page 4: Cleaning, Care And Maintenance
Risk of damage facilitate and speed up your enquiry, please provide the serial If the consumption indicator changes colour from white number from the type plate (no. 000000-0000-000000): to red, have the signal anode checked by a heating contractor and if necessary replaced. SBB 301 WP Nr.: 000000 - 0000 - 000000 Behälter + WT: 300 l St em zul. Betriebsüberdruck: 1 MPa (10 bar) max. Betriebstemp. : 95 °C... -
Page 5: Safety
installatiOn saFety safety appliance description Only qualified contractors should carry out installation, standard delivery commissioning, maintenance and repair of the appliance. Delivered with the appliance: General safety instructions - Cold water inlet pipe with flat gasket We guarantee trouble-free operation and operational reliability - Adhesive rosettes for connecting lines only if the original accessories and spare parts intended for the appliance are used. - DHW sensor - Adjustable feet instructions, standards and regulations - Fixing straps with closure element Observe all applicable national and regional regulations - Thermometer (in its delivered condition located in the and instructions. DHW outlet) - Safety assembly Water installation... -
Page 6: Handling
installatiOn installatiOn Handling 8.3.2 checking the signal anode Risk of damage Risk of damage The appliance must not be operated without a We recommend removing the cylinder casing for consumption indicator or with a damaged one, otherwise transportation to the installation location to prevent it water will leak out once the anode is depleted. from becoming dirty or damaged. 8.3.3 Heating installation sBB 501 Wp sOl (GB) » Both side insulation sections can be removed for » Flush the indirect coils with water before connecting the transportation in tight spaces. To do this, remove the cylinder heating water pipes. -
Page 7: Commissioning
installatiOn cOMMissiOning 10. taking the appliance out of use » Run the pressure safety valve outlet and that of the T&P valve to a drain via a tundish. The purpose of the tundish is » Disconnect the appliance from the mains at the MCB/fuse in to let water be seen should these valves respond. The outlet the fuse box. pipe should not exceed 9 metres in length without forming » Drain the appliance. See chapter "Maintenance / Draining the an air break, i.e. tundish. The pipe must fall continuously throughout its length with no additional 90° bends. It must appliance". be heat resistant and discharge to a safe visible position 11. recommissioning away from any electrical devices. The pipe diameter must not be smaller than the valve outlet. The two discharge pipes can be joined together at the point of discharge into a single See chapter "Commissioning". tundish if required. 12. appliance handover » Size the drain so that water can drain off unimpeded when the safety valve is fully opened. The blow-off aperture of the » Explain the appliance function to users and familiarise them safety valve must remain open towards the atmosphere. with its operation. »... -
Page 8: Maintenance
Maintenance 14. maintenance 15. specification 15.1 dimensions and connections DANGER Electrocution Carry out all electrical connection and installation work in accordance with relevant regulations. sBB 301 Wp (GB) If you need to drain the appliance, observe chapter "Draining the appliance". 14.1 checking the safety assembly » Regularly vent the pressure safety valve on the safety assembly until a full water jet is discharged. » Close the pressure safety valve when the check is complete. » Check the T&P valve for tightness. 14.2 draining the appliance DANGER Scalding Hot water may escape during the draining process. If the cylinder needs to be drained for maintenance or to protect the whole installation when there is a risk of frost, proceed as follows: » Close the shut-off valve in the cold water line. - Page 9 installatiOn speciFicatiOn sBB 302 Wp (GB) dimensions Type SBB 301 WP (GB) SBB 302 WP (GB) Appliance Height 1710 1710 Height, thermal insulation 1695 1695 Diameter Diameter, thermal insulation Pitch circle diameter, adjustable feet Cold water inlet Height Male thread G 1 A G 1 A Cold water supply line Height Male thread G 1 A G 1 A DHW outlet Height 1710 1710 Male thread G 1 A G 1 A Heating flow, heat pump Height 1008 1408 Male thread G 1½...
- Page 10 installatiOn speciFicatiOn sBB 401 Wp sOl (GB) | sBB 501 Wp sOl (GB) |sBB 301-501 Wp sOl WWW.stieBel-eltrOn.cOM...
- Page 11 installatiOn speciFicatiOn dimensions Type SBB 401 WP SOL (GB) SBB 501 WP SOL (GB) Appliance Height 1880 1990 Height, thermal insulation 1960 1960 Width excl. side thermal insulation segments Diameter Diameter, thermal insulation Pitch circle diameter, adjustable feet Cold water inlet Height Male thread G 1 A G 1 A Cold water supply pipe Height Male thread G 1 A G 1 A DHW outlet Height 1880 1990 Male thread G 1 A G 1 A Flow, solar indirect coil Height Female thread G 1½ G 1½ Return, solar indirect coil Height Female thread G 1½...
-
Page 12: Hydraulic Diagram
installatiOn speciFicatiOn 15.2 Hydraulic diagram < 500 3 2 1 1 Discharge below fixed grate 2 Cold water supply 3 Shut-off valve 4 Line strainer 5 Pressure reducing valve 6 Balanced pressure; cold water outlet 7 Check valve 8 Safety assembly 9 Tundish 10 Metal discharge pipe (D2) from tundish, with continuous fall 11 Equipotential bond 12 Drain valve 13 Cylinder 14 DHW outlet 15 T&P valve 16 Metal discharge pipe (D1) from T&P valve to tundish 17 Expansion vessel 18 Pressure safety valve Minimum size of discharge pipe D1 Minimum size of discharge pipe D2 from tundish Maximum permissible pressure drop, expressed as a length of straight pipe (i.e. no elbows or bends) Pressure drop of each elbow or bend connection dimensions... -
Page 13: Specification
installatiOn speciFicatiOn 15.3 specification Model Floorstanding dHW cylinder Type SBB 301 WP (GB) Set SBB 302 WP (GB) Set SBB 401 WP SOL (GB) SBB 501 WP SOL (GB) Part number 228944 228945 228946 228947 Nominal capacity Flanged apertures Maximum permissible temperature °C Maximum permissible pressure Test pressure (cylinder and indirect coil) Maximum transition resistance Ω 0.3 0.3 0.3 0.3 between anode and cylinder connection Standby energy consumption / 24 h 2.1 Maximum flow rate l/min Maximum permissible pressure, heat pump indirect coil MPa Pressure drop at 1 m³/h, heat pump indirect coil 5400 7700 6600 8000 Surface area, heat pump indirect coil... -
Page 14: Environment And Recycling
garantie | envirOnMent and recycling Guarantee For guarantees please refer to the respective terms and conditions of supply for your country. The installation, electrical connection and first operati- on of this appliance should be carried out by a qualified installer. The company does not accept liability for failure of any goods supplied which have not been installed and ope- rated in accordance with the manufacturer‘s instructions. Environment and recycling Please help us to protect the environment by disposing of the packaging in accordance with the national regulations for waste processing. - Page 15 nOtes WWW.stieBel-eltrOn.cOM sBB 301-501 Wp sOl |...
