STIEBEL ELTRON SB 302 S GB Operation & Installation
Sealed unvented floorstanding dhw combi cylinder
Hide thumbs
Also See for SB 302 S GB:
- Operation and installation (60 pages) ,
- Operation and installation (56 pages) ,
- Operating and installation instructions (20 pages)
Related Manuals for STIEBEL ELTRON SB 302 S GB
Summary of Contents for STIEBEL ELTRON SB 302 S GB
- Page 1 OPERATION AND INSTALLATION SEALED UNVENTED FLOORSTANDING DHW COMBI CYLINDER » SB 302 S (GB) » SB 402 S (GB)
-
Page 2: Table Of Contents
CONTENTS | OPERATION GENERAL INFORMATION OPERATION ��������������������������������������������� 2 1. General information 1. General information ��������������������������������������������2 1.1 Information about this document 1.1 Information about this document ������������������������������� 2 1.2 Symbol key ����������������������������������������������������������� 2 The chapter Operation is intended for the equipment user and the heating contractor. 2. Safety ������������������������������������������������������������3 2.1 Correct use �����������������������������������������������������������... -
Page 3: Safety
OPERATION SAFETY 2. Safety 4. Cleaning, care and maintenance Have a contractor regularly check the appliance, the safety » 2.1 Correct use assembly and all fitted special accessories. The appliance is a pressure appliance for universal DHW provision. 4.1 Protective anode Suitable dummy flanges, indirect coils and flanged immersion heaters can be fitted by contractors. -
Page 4: Installation
INSTALLATION SAFETY 6. Safety 8. Installation Only qualified contractors should carry out installation, 8.1 Installation location commissioning, maintenance and repair of the appliance. Always install the appliance in a room free from the risk of frost 6.1 General safety instructions and near to a hot water draw-off point, and secure the appliance to the floor. - Page 5 INSTALLATION INSTALLATION 8.3.4 Fitting the thermometer 1 Cold water connection 2 Cold water connecting pipe Connect the cold water supply directly to the cylinder or with the » connecting pipe routed between the cylinder feet. During fitting, counterhold the fitting with a spanner (across »...
-
Page 6: Commissioning
INSTALLATION COMMISSIONING 9. Commissioning 14. Maintenance Open a downstream draw-off valve until the appliance has filled » Danger to life through electrocution! up and the pipework is free of air. Before any work on the appliance, disconnect all poles Carry out a tightness check. from the power supply. » Switch the mains power ON if required. If you need to drain the appliance, observe chapter "Draining »... -
Page 7: Specification
INSTALLATION SPECIFICATION 15. Specification 15.2 Hydraulic diagram 15.1 Dimensions < 500 3 2 1 1 Discharge below fixed grate 2 Cold water supply 3 Shut-off valve 4 Line strainer 5 Pressure relief valve 6 Balanced pressure; cold water outlet Ø o 7 Check valve 8 Safety assembly 9 Tundish... -
Page 8: Data Table
INSTALLATION SPECIFICATION 15.3 Data table Model DHW combi cylinder Type SB 302 S SB 402 S (GB) Set (GB) Set Part number 228937 228938 Operating details Nominal capacity Flanged apertures Maximum DHW temperature °C Permissible operating pressure Test pressure (unfinished cylinder) Ω... -
Page 9: Customer Service And Warranty
CUSTOMER SERVICE AND WARRANTY | ENVIRONMENT AND RECYCLING Guarantee For guarantees please refer to the respective terms and conditions of supply for your country. The installation, electrical connection and first operati- on of this appliance should be carried out by a qualified installer. The company does not accept liability for failure of any goods supplied which have not been installed and ope- rated in accordance with the manufacturer‘s instructions. Environment and recycling Please help us to protect the environment by disposing of the packaging in accordance with the national regulations for waste processing. - Page 10 NOTES | SB S (GB) WWW.STIEBEL-ELTRON.COM...
