STIEBEL ELTRON SBB 302 WP Manual For Operation And Installation
Floorstanding dhw cylinder
Hide thumbs
Also See for SBB 302 WP:
- Operation and installation manual (128 pages) ,
- Operation and installation (80 pages) ,
- Installation and operating instructions manual (40 pages)
Subscribe to Our Youtube Channel
Related Manuals for STIEBEL ELTRON SBB 302 WP
Summary of Contents for STIEBEL ELTRON SBB 302 WP
- Page 1 OPERATION AND INSTALLATION Floorstanding DHW cylinder » SBB 302 WP (AU) » SBB 401 WP SOL (AU) » SBB 501 WP SOL (AU)
-
Page 2: Table Of Contents
Failure to observe this information may result in non-seri- 14.1 Dimensions and connections ���������������������������������� 9 ous or minor injury. 14.2 Data table �������������������������������������������������������� 12 GUARANTEE ENVIRONMENT AND RECYCLING | SBB 302 WP (AU) | SBB 401-501 WP SOL (AU) www.stiebel-eltron.com... -
Page 3: Other Symbols In This Documentation
Any other use beyond that described shall be deemed inappro- priate. Observation of these instructions is also part of the correct use of this appliance. Any modifications or conversions to the appliance void all warranty rights. www.stiebel-eltron.com SBB 302 WP (AU) | SBB 401-501 WP SOL (AU) |... -
Page 4: Cleaning, Care And Maintenance
“Specification / Data table”. Made in Germany Operate the appliance only with pressure-tested taps and valves. | SBB 302 WP (AU) | SBB 401-501 WP SOL (AU) www.stiebel-eltron.com... -
Page 5: Appliance Description
Data table” for weight). f Use the adjustable feet to compensate for any unevenness in the floor. f Use the fixing straps to refit the thermal insulation sections after transportation. www.stiebel-eltron.com SBB 302 WP (AU) | SBB 401-501 WP SOL (AU) |... -
Page 6: Preparing For Installation
Connect the cold water supply directly to the cylinder or with for glycol are used throughout the installation. the connecting pipe routed between the cylinder feet. f During fitting, counterhold the fitting with an open-ended spanner (size 36). | SBB 302 WP (AU) | SBB 401-501 WP SOL (AU) www.stiebel-eltron.com... -
Page 7: Fitting The Thermometer And Dhw Sensor
For higher levels of DHW convenience, you can alter- natively insert the DHW sensor into the lower “Sensor heat pump DHW optional” sensor well (higher energy demand). www.stiebel-eltron.com SBB 302 WP (AU) | SBB 401-501 WP SOL (AU) |... -
Page 8: Troubleshooting
13.3 Replacing the signal anode f Replace the signal anode if it becomes depleted. Ensure there is a good connection between the anode and the cylin- der (maximum permissible transition resistance 0.3 Ω). | SBB 302 WP (AU) | SBB 401-501 WP SOL (AU) www.stiebel-eltron.com... -
Page 9: Specification
Sensor heat pump DHW optional Diameter Thermometer Diameter Flange Diameter Pitch circle diameter Screws M 12 Torque elec. emergency/booster heater Female thread G 1 1/2 Protective anode Female thread G 1 1/4 www.stiebel-eltron.com SBB 302 WP (AU) | SBB 401-501 WP SOL (AU) |... - Page 10 Sensor solar cylinder Diameter Thermometer Diameter Flange Diameter Pitch circle diameter Screws M 12 Torque elec. emergency/booster Female thread G 1 1/2 heater Protective anode Female thread G 1 1/4 | SBB 302 WP (AU) | SBB 401-501 WP SOL (AU) www.stiebel-eltron.com...
- Page 11 Sensor solar cylinder Diameter Thermometer Diameter Flange Diameter Pitch circle diameter Screws M 12 Torque elec. emergency/booster Female thread G 1 1/2 heater Protective anode Female thread G 1 1/4 www.stiebel-eltron.com SBB 302 WP (AU) | SBB 401-501 WP SOL (AU) |...
-
Page 12: Data Table
Weight (dry) Further details SBB 302 WP (AU) SBB 401 WP SOL (AU) SBB 501 WP SOL (AU) 200021 200022 200023 Maximum altitude for installation 2000 2000 2000 | SBB 302 WP (AU) | SBB 401-501 WP SOL (AU) www.stiebel-eltron.com... - Page 13 Component Warranty period All components, excluding 1 year from the date of completion of the PTR valve installation of the unit. www.stiebel-eltron.com SBB 302 WP (AU) | SBB 401-501 WP SOL (AU) |...
- Page 14 12.8. Non genuine parts other than those manufactured or ap- proved by us have been used on the unit. | SBB 302 WP (AU) | SBB 401-501 WP SOL (AU) www.stiebel-eltron.com...
- Page 15 The Stiebel Eltron warranty for the unit is in addition to any rights and remedies you may have under the Australian Consumer Law.
- Page 16 Deutschland Verkauf Tel. 05531 702-110 | Fax 05531 702-95108 | info-center@stiebel-eltron.de STIEBEL ELTRON GmbH & Co. KG Kundendienst Tel. 05531 702-111 | Fax 05531 702-95890 | kundendienst@stiebel-eltron.de Dr.-Stiebel-Straße 33 | 37603 Holzminden Ersatzteilverkauf Tel. 05531 702-120 | Fax 05531 702-95335 | ersatzteile@stiebel-eltron.de Tel.
