Huawei UPS5000-H-1200 kVA Quick Manual

UPS5000-H-1200 kVA
(Three-Phase Three-Wire)
Quick Guide
• Before installing the equipment, read the product documentation carefully to get
familiar with product information and safety precautions. Huawei shall not be liable
for any consequence caused by violation of the storage, transportation, installation,
and operation regulations specified in this document. Log in to the technical support
website to view the product documentation and safety precautions.
•
The information in this document is subject to change without notice. Every effort
has been made in the preparation of this document to ensure accuracy of the
contents, but all statements, information, and recommendations in this document do
not constitute a warranty of any kind, express or implied.
• Only qualified personnel are allowed to perform operations on the equipment.
Operation personnel should understand the system, its working principles, and
relevant national/regional standards.
• Wear dedicated personal protective equipment during operations. Use dedicated
insulated tools during electrical operations.
Preparations for Installation
Environment and Space Requirements
2650 kg
Relative humidity
Operating
Floor and support
Airtight equipment
0%–95% RH
temperature
load capacity
room
(non-condensing)
0°C–55°C
Heat source,
Water source,
inflammable or Direct sunlight
conductive metal dust
water vapor
explosive article
Unit: mm
Issue: 03
Date: 2024-05-20
Recommended Circuit Breaker Specifications when the Short-Circuit
Current Going Through the Device Is less than 65 kA in a 380 V AC/400
Capacity
1200 kVA
1100 kVA
1000 kVA
900 kVA
800 kVA
700 kVA
600 kVA
Excessive salt
content
500 kVA
400 kVA
300 kVA
Dust,
Volatile or
corrosive substance
200 kVA
Dimensions
Power
Bypass Inductor
cabinet
cabinet cabinet
V AC/415 V AC Voltage System
Bypass Maintenance Bypass
Mains Input Output
Input (Single UPS)
2500 A/3P 2000 A/3P 2000 A/3P 2000 A/3P
2500 A/3P 2000 A/3P 2000 A/3P 2000 A/3P
2000 A/3P 1600 A/3P 1600 A/3P 1600 A/3P
2000 A/3P 1600 A/3P 1600 A/3P 1600 A/3P
1600 A/3P 1250 A/3P 1250 A/3P 1250 A/3P
1600 A/3P 1250 A/3P 1250 A/3P 1250 A/3P
1250 A/3P 1000 A/3P 1000 A/3P 1000 A/3P
1000 A/3P 800 A/3P 800 A/3P 800 A/3P
800 A/3P 630 A/3P 630 A/3P 630 A/3P
630 A/3P 630 A/3P 630 A/3P 630 A/3P
400 A/3P 400 A/3P 400 A/3P 400 A/3P
1
2
Recommended Cable Specifications (mm ) in a 380 V AC/400 V AC/415 V
AC Voltage System
Capacity Mains Input Bypass Input Output
1200 kVA
L1: 6 x 240 L1: 6 x 240 U: 6 x 240
L2: 6 x 240 L2: 6 x 240 V: 6 x 240
L3: 6 x 240 L3: 6 x 240 W: 6 x 240
PE: 3 x 240 PE: 3 x 240 PE: 3 x 240
1100 kVA
1000 kVA
L1: 5 x 240 L1: 5 x 240 L1: 5 x 240
L2: 5 x 240 L2: 5 x 240 L2: 5 x 240
L3: 5 x 240 L3: 5 x 240 L3: 5 x 240
PE: 3 x 240 PE: 3 x 240 PE: 3 x 240
900 kVA
800 kVA
L1: 4 x 240 L1: 4 x 240 U: 4 x 240
L2: 4 x 240 L2: 4 x 240 V: 4 x 240
L3: 4 x 240 L3: 4 x 240 W: 4 x 240
PE: 2 x 240 PE: 2 x 240 PE: 2 x 240
700 kVA
L1: 4 x 185 L1: 4 x 185 U: 4 x 185
L2: 4 x 185 L2: 4 x 185 V: 4 x 185
600 kVA
L3: 4 x 185 L3: 4 x 185 W: 4 x 185
PE: 2 x 185 PE: 2 x 185 PE: 2 x 185
L1: 3 x 185 L1: 3 x 185 U: 3 x 185
L2: 3 x 185 L2: 3 x 185 V: 3 x 185
500 kVA
L3: 3 x 185 L3: 3 x 185 W: 3 x 185
PE: 2 x 150 PE: 2 x 150 PE: 2 x 150
L1: 2 x 240 L1: 2 x 240 U: 2 x 240
L2: 2 x 240 L2: 2 x 240 V: 2 x 240
400 kVA
L3: 2 x 240 L3: 2 x 240 W: 2 x 240
PE: 240 PE: 240 PE: 240
L1: 2 x 150 L1: 2 x 150 U: 2 x 150
L2: 2 x 150 L2: 2 x 150 V: 2 x 150
300 kVA
L3: 2 x 150 L3: 2 x 150 W: 2 x 150
PE: 150 PE: 150 PE: 150
L1: 2 x 95 L1: 2 x 95 U: 2 x 95
L2: 2 x 95 L2: 2 x 95 V: 2 x 95
200 kVA
L3: 2 x 95 L3: 2 x 95 W: 2 x 95
PE: 95 PE: 95 PE: 95
Equipotential
Battery Input
Ground
+: 6 x 240
-: 6 x 240 GND: 16
PE: 3 x 240
+: 6 x 240
-: 6 x 240 GND: 16
PE: 3 x 240
+: 4 x 240
-: 4 x 240 GND: 16
PE: 2 x 240
+: 3 x 240
-: 3 x 240 GND: 16
PE: 2 x 185
+: 3 x 185
-: 3 x 185 GND: 16
PE: 2 x 150
+: 2 x 240
-: 2 x 240 GND: 16
PE: 240
+: 2 x 185
-: 2 x 185 GND: 16
PE: 185
+: 2 x 120
-: 2 x 120 GND: 16
PE: 120
