Mocka Newport Change Table Assembly Instructions Manual page 6

Newport Change Table
A B
bolt locking
x47 nut x47
CL
CR
L+R
slide rail
x6
W
safety
strap x 1
WARNING: Any furniture that is not anchored to a wall has the potential to tip over in certain
circumstances, i.e. if a child attempts to climb up on the furniture or in the event of an earthquake.
Accordingly, we recommend that all furniture is anchored to a wall. We supply a free safety wall
anchor with all furniture sold and we recommend these are used to prevent your product tipping.
The fixing device provided should fit most wall types, but please
mocka.co.nz I mocka.com.au
C
dowel medium
x12
DL
DR
L+R
slide rail
x6
HARDWARE SUPPLIED
Y
screw
x 5
WALL STRAP
E
D
screw small screw
x4 x30
I
J
cover
clip
x20
x2
X
wall
anchor x 1 screw x 1
Phillips & Flathead screwdrivers
and hammer required
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
F
medium screw
18
V Z
wall washer
x 1
