5. Operation Steps
5. Operation Steps
1) Power supply: Use the 12V standard adapter to power the probe.
1) Power supply: Use the 12V standard adapter to power the probe.
2) Zero Calibration: Make sure the slider is in the "LOCK" position and press the zero
2) Zero Calibration: Make sure the slider is in the "LOCK" position and press the zero
button.
button.
3) Connect to the oscilloscope: Connect the probe to the oscilloscope and make sure
3) Connect to the oscilloscope: Connect the probe to the oscilloscope and make sure
the grounding of the oscilloscope is normal.
the grounding of the oscilloscope is normal.
4) Select the range: Select the appropriate range according to the range of the
4) Select the range: Select the appropriate range according to the range of the
measured current.
measured current.
5) Connect to DUT: Push the slider to the "OPEN" position, place the measured con-
5) Connect to DUT: Push the slider to the "OPEN" position, place the measured con-
ductor into the wire grip, and then push the slider to the "LOCK" position. Make sure
ductor into the wire grip, and then push the slider to the "LOCK" position. Make sure
you hear a "click" sound indicating that it has been tightly clamped.
you hear a "click" sound indicating that it has been tightly clamped.
6) Start the power supply of the DUT.
6) Start the power supply of the DUT.
7) Set up the oscilloscope
7) Set up the oscilloscope
6. Warranty
6. Warranty
1) Micsig warrants the main body of this differential probe for 1 year.During the
warranty period, Micsig will be responsible for free maintenance for any failure caused
by the quality of the product under normal use.
2) Under the following circumstances, Micsig will refuse to provide maintenance
services or charge for a fee:
a. No packaging or anti-counterfeiting label.
b. Anti-counterfeit label has been altered or blurred beyond recognition.
c. Unauthorized disassembly, such as: changing wires, dismantling internal
components, etc.
d. No sales voucher or the content of sales voucher does not match the product.
7. Safety Precautions
7. Safety Precautions
1) Non-professionals do not open the product casing
2) Do not use while case is open
3) Do not touch any bare metal while testing
4) Disconnect the power supply and circuit immediately when over range
5) Do not use in flammable and explosive environments
Shenzhen Micsig Technology Co., Ltd.
Shenzhen Micsig Technology Co., Ltd.
Tel: +86-755-88600880 Email: sales@micsig.com Web: www.micsig.com
Add: A106 , Huafeng Robot Industrial Park, Hangcheng Rd, Bao'an,
Shenzhen, Guangdong, China, 518126
Quick Guide
Quick Guide
High Frequency AC/DC Current Probe CP series
High Frequency AC/DC Current Probe CP series
1. Overview
1. Overview
Micsig high frequency AC/DC current probe CP series has bandwidth up to
100MHz, accuracy up to 1%. With 5A/30A dual range design, degaussing and
Auto-Zero completed in one press.
The wire grip able to measure 5mm diameter conductor. It has compact
design, light weight, and a universal BNC interface allows it to work on all
brands of oscilloscopes.
