Summary of Contents for Micsig TO Series

  • Page 2: Table Of Contents

    Table of Contents Version Info Version Date Remarks V1.0 2022.06 Added features, TO1004, etc. V1.1 2022.12 Update Oscilloscope Interface Display, added FFT V1.2 2024.04.09 persist, measure setting etc.
  • Page 3 Preface Dear customers, Congratulations! Thank you for buying Micsig instrument. Please read this manual carefully before use and particularly pay attention to the “Safety Precautions”. If you have read this manual, please keep it properly for future reference. The information contained herein are furnished in an “as-is” state, and may be subject to change in future versions without notice.
  • Page 4 Table of Contents Features Parameters:  Channels: 4 x Analog Channel, 1 x Auxout Channel  Analog Channel Bandwidth: Max. 300MHz  Max. Real Time Sampling Rate: 2GSa/s  Memory Depth: 220Mpts  Max. Waveform Capture Rate: 300,000 wfms/s  Vertical Sensitivity Range: 1mV/div~10V/div（1MΩ），1mV/div~1V/div（50Ω） Timebase Range: 1ns/div~1000s/div ...
  • Page 5  Portable and Benchtop, built-in 7500mAh lithium battery, only 1.9kg Functions:  Equipped with Sigtest™ multitasking system, stable and reliable operation  Built-in User Manual, large screen for easy reading  Support channel label rename, quick setting of channel parameters ...
  • Page 6 Table of Contents  Support 256-level grayscale digital fluorescent display and color temperature display  Support persistence display Support one-press zero calibration , manual zero calibration  (TO1004 does not support this function)  Support 1MΩ/50Ω impedance switching (TO1004 does not support this function) ...
  • Page 7  Rich trigger functions: edge, pulse width, logic, N edge, runt, slope, timeout, video, UART, I2C, SPI, CAN, CAN FD, LIN, 429, 1553B  Rich serial bus decoding function (optional): UART, I2C, SPI, CAN, CAN FD, LIN, 429, 1553B, support 2 decoding channels, support decoding text mode ...
  • Page 8  Support online firmware upgrade function  Optional current probe, differential probe, optical isolated probe, special suitcase, handbag and other oscilloscope accessories Note: Unless otherwise specified, this user manual uses TO3004 as an example to illustrate the TO series and its basic operations.

  • Page 9: Table Of Contents

    Table of Contents TABLE OF CONTENTS ................................ X CHAPTER 1. SAFETY PRECAUTIONS ........................... 1 1.1 S ..............................1 AFETY RECAUTIONS 1.2 S AFETY ERMS AND YMBOLS ............................5 CHAPTER 2. QUICK START GUIDE OF OSCILLOSCOPE ......................8 2.1 I ............................9 NSPECT ACKAGE ONTENTS...
  • Page 10 Table of Contents 2.8 U NDERSTAND THE SCILLOSCOPE ISPLAY NTERFACE ....................18 2.9 I NTRODUCTION ASIC PERATIONS OF OUCH CREEN ....................24 2.10 M OUSE PERATION ..............................26 2.11 C ........................27 ONNECT ROBE TO THE SCILLOSCOPE 2.12 U .................................. 28 2.13 L ............................
  • Page 11 3.5 Z ................................57 CHAPTER 4 VERTICAL SYSTEM ............................60 4.1 O ) ............... 62 LOSE AVEFORM HANNEL EFERENCE AVEFORMS 4.2 A ............................ 67 DJUST ERTICAL ENSITIVITY 4.3 A DJUST ERTICAL OSITION ............................68 4.4 O HANNEL ..............................68 4.4.1 Set Channel Coupling ............................. 70 4.4.2 Set Bandwidth Limit ..............................
  • Page 12 Table of Contents CHAPTER 5 TRIGGER SYSTEM ............................83 5.1 T ........................... 84 RIGGER AND RIGGER DJUSTMENT 5.2 E ................................97 RIGGER 5.3 P .............................. 102 ULSE IDTH RIGGER 5.4 L ................................109 OGIC RIGGER 5.5 N ..............................115 RIGGER 5.6 R ................................
  • Page 13 6.3 C ..................................155 URSOR CHAPTER 7 SCREEN CAPTURE, MEMORY DEPTH AND WAVEFORM STORAGE ..............161 7.1 S ............................162 CREEN APTURE UNCTION 7.2 V ..............................164 IDEO ECORDING 7.3 W ..............................165 AVEFORM TORAGE 7.4 O SCILLOSCOPE SETTING SAVE .............................
  • Page 14 Table of Contents 9.3 P ..............................199 ERSISTENCE ETTING 9.4 H ..........................202 ORIZONTAL XPANSION ENTER 9.5 C ..........................202 OLOR EMPERATURE ETTING 9.6 T ............................ 203 ELECTION CHAPTER 10 SAMPLING SYSTEM ........................... 204 10.1 S AMPLING VERVIEW ............................... 205 10.2 R SEQ K ........................
  • Page 15 CHAPTER 11 SERIAL BUS TRIGGER AND DECODE (OPTIONAL) ..................233 11.1 UART (RS232/RS422/RS485) B ..................238 RIGGER AND ECODE 11.2 LIN B ..........................249 RIGGER AND ECODE 11.3 CAN(FD) B RIGGER AND ECODE ........................257 11.4 SPI B ..........................264 RIGGER AND ECODE 11.5 I2C B...
  • Page 16 Table of Contents 12.6 B ................................. 309 ROWSER 12.7 G ................................. 310 ALLERY 12.8 C ................................313 ALENDAR 12.9 E ..............................313 LECTRONIC OOLS 12.10 C ................................... 314 LOCK 12.11 P OWER ................................318 12.12 ES F ..............................319 XPLORER CHAPTER 13 REMOTE CONTROL ............................
  • Page 17 13.2 M ............................332 OBILE EMOTE ONTROL 13.3 SCPI ..................................335 CHAPTER 14 UPDATE AND UPGRADE FUNCTIONS ......................336 14.1 S ..............................337 OFTWARE PDATE 14.2 A ............................338 PTIONAL UNCTIONS CHAPTER 15 REFERENCE ............................... 341 15.1 M EASUREMENT ATEGORY ............................

  • Page 18: Chapter 1. Safety Precautions

    Chapter 1. Safety Precautions Chapter 1. Safety Precautions 1.1 Safety Precautions The following safety precautions must be understood to avoid personal injury and prevent damage to this product or any products connected to it. To avoid possible safety hazards, it is essential to follow these precautions while using this product.
  • Page 19 ⚫ Do not operate without covers. Do not operate the product with covers or panels removed. ⚫ Do not operate with suspected failures. If you suspect that there is damage to this product, have it inspected by service personnel designated by Micsig.
  • Page 20 Chapter 1. Safety Precautions ⚫ Use adapter correctly. Supply power or charge the equipment by power adapter designated by Micsig, and charge the battery according to the recommended charging cycle. ⚫ Avoid exposed circuitry. Do not touch exposed connections and components when power is present.
  • Page 21 Measurement Category Definition Measurement category I is for measurements performed on circuits not directly connected to the MAINS. Examples are measurements on circuits not derived from MAINS, and specially protected (internal) MAINS derived circuits. In the latter case, transient stresses are variable; for that reason, the user must understand the transient withstand capability of the equipment.

  • Page 22: Safety Terms And Symbols

    Chapter 1. Safety Precautions 1.2 Safety Terms and Symbols Terms in the manual These terms may appear in this manual: Warning. Warning statements indicate conditions or practices that could result in injury or loss of life. Caution. Caution statements indicate conditions or practices that could result in damage to this product or other property.
  • Page 23 Symbols on the product The following symbols may appear on the product: Hazardous Voltage Caution Refer to Manual Protective Ground Terminal Chassis Ground Measurement Ground Terminal Please read the following safety precautions to avoid personal injury and prevent damage to this product or any products connected to it.
  • Page 24 Chapter 1. Safety Precautions ⚫ User only insulated voltage probes supplied with the instrument, or the equivalent product indicated in the schedule. ⚫ Before use, inspect voltage probes, test leads, and accessories for mechanical damage and replace when damaged. ⚫ Remove voltage probes and accessories not in use. ⚫...

  • Page 25: Chapter 2. Quick Start Guide Of Oscilloscope

    Chapter 2. Quick Start Guide of Oscilloscope This chapter contains checks and operations of the oscilloscope. You are recommended to read them carefully to understand appearance, power on/off, settings and related calibration requirements of the Smart series oscilloscope. ⚫ Inspect package contents ⚫...

  • Page 26: Inspect Package Contents

    If any damage to oscilloscope is found by the appearance inspection or it fails to pass the performance test, please contact Micsig’s agent or local office. If the instrument is damaged due to transportation, please retain the package and contact the transportation company or Micsig’s agent, and Micsig will make arrangement.

  • Page 27: Use The Bracket

    2.2 Use the Bracket Put the front panel of the oscilloscope flatly on the table. Use your two index fingers to hold the underside of the bracket and open the bracket by slightly upwards force, as shown in Figure 2-1.
  • Page 28 Chapter 2. Quick Start Guide of Oscilloscope Figure 2-1 Open Bracket...

  • Page 29: Side Panel

    2.3 Side Panel Figure 2-2 Side Panel There are various interfaces on the side of the oscilloscope, from left to right: Power-on button, Grounding, Probe compensation signal output, USB Host, HDMI, USB Device, Power-off lock, and Power port.

  • Page 30: Rear Panel

    Chapter 2. Quick Start Guide of Oscilloscope 2.4 Rear Panel Figure 2-3 Rear Panel...
  • Page 31 a) Ch1 – Ch4 are signal measurement channels b) Aux out is an auxiliary channel, which is mainly used to measure the waveform refresh rate of the oscilloscope and cascade the current oscilloscope signal to other oscilloscopes.

  • Page 32: Top Panel

    Chapter 2. Quick Start Guide of Oscilloscope 2.5 Top Panel Figure 2-4 Top Panel of Tablet Oscilloscope On top of the oscilloscope is the BNC interface for probe connection.

  • Page 33: Front Panel

    2.6 Front Panel Figure 2-5 Front Panel of Tablet Oscilloscope...

  • Page 34: Power On/Off The Oscilloscope

    Chapter 2. Quick Start Guide of Oscilloscope 2.7 Power on/off the Oscilloscope Power on/off the oscilloscope First time start ⚫ Connect power adapter to the oscilloscope, and the oscilloscope should not be pressed on the adapter cable. ⚫ Check the Power-off lock on the side of oscilloscope and press the power button to start the instrument.

  • Page 35: Understand The Oscilloscope Display Interface

    ⚫ Turn the power-off lock switch to OFF, the oscilloscope cannot be turned on. Caution: Forced power-off may result in loss of unsaved data, please use with caution. 2.8 Understand the Oscilloscope Display Interface This section provides a brief introduction and description of the Smart Series oscilloscope user’s interface. After reading this section, you can be familiar with the oscilloscope display interface content within the shortest possible time.
  • Page 36 Chapter 2. Quick Start Guide of Oscilloscope Figure 2-6 Oscilloscope Interface Display...
  • Page 37 Description Micsig logo Oscilloscope status, including RUN, STOP, WAIT, Auto；Tap to switch to STOP Trigger point Sampling rate, memory depth The area in “[]” indicates the position of waveform displayed on the screen throughout the memory depth Delay time, the time at which the center line of the waveform display area is relative to the trigger...
  • Page 38 Chapter 2. Quick Start Guide of Oscilloscope Description Trigger level indicator CH1、CH2、CH3、CH4 channel icons and vertical sensitivity icon. Tap the channel icons to open channels; Click to adjust the vertical sensitivity of channels; Open the channel menu by swipe left from the desired channel and swipe right to close; Display the vertical sensitivity of channels;...
  • Page 39 Description Horizontal time base control icon. Tap the left/right time base buttons to adjust the horizontal time base of the waveform. Tap the time base to open the time base table. Tap to select the desired time base. Quick save. Tap to quickly save the waveform as a reference waveform. Fine adjustment button.
  • Page 40 Chapter 2. Quick Start Guide of Oscilloscope Description 50%: Touch to set: ⚫ The vertical position of the current channel waveform to the zero point ⚫ The horizontal position of the current channel waveform to center of the screen ⚫ The trigger level to the center of the trigger channel's waveform ⚫...

  • Page 41: Introduction Basic Operations Of Touch Screen

    2.9 Introduction Basic Operations of Touch Screen The Smart Series oscilloscope operates mainly by tap, swipe, single-finger drag. Tap button on the touch screen to activate the corresponding menu and function. Tap any blank space on the screen to exit the menu. Swipe Single-finger swipe: to open/close menus, including main menu, shortcut menu button and other channel menu operations.
  • Page 42 Chapter 2. Quick Start Guide of Oscilloscope Figure 2-7 Slide out of Main Menu Tap the options in the main menu to enter the corresponding submenu.

  • Page 43: Mouse Operation

    Single-finger drag For coarse adjustments of vertical position, trigger point, trigger level, cursor, etc. of the waveform. Refer to “4.1 Waveform” and “5.3 Adjust Vertical Position” for details. Horizontal Move 2.10 Mouse Operation Connect the mouse to the “USB Host” interface, then operate the oscilloscope with the mouse. The left button, right button and scroll wheel of the mouse have the same functions as the finger touch function.

  • Page 44: Connect Probe To The Oscilloscope

    Chapter 2. Quick Start Guide of Oscilloscope Figure 2-8 Mouse Cursor 2.11 Connect Probe to the Oscilloscope Connect the probe to the oscilloscope channel BNC connector. Connect the retractable tip on the probe to the circuit point or measured equipment. Be sure to connect the probe ground wire to the ground point of the circuit.

  • Page 45: Use Auto

    Maximum input voltage of the analog input Category I 300Vrms, 400Vpk. 2.12 Use Auto Once the oscilloscope is properly connected and a valid signal is input, tap the Auto Set button to quickly configure the oscilloscope to be the best display effects for the input signal. While the oscilloscope in auto state, the Auto Set button will turn to green Auto is divided into Auto Set and Auto Range.
  • Page 46 Chapter 2. Quick Start Guide of Oscilloscope Source can be automatically triggered, and the triggered source channel can be automatically set to select priority to the current signal or to the maximum signal. Open the main menu. Tap “Auto” to open the auto set menu, including channel open/close setting, threshold voltage setting and trigger source setting.
  • Page 47 Note: The application of Auto Set requires that the frequency of measured signal is no less than 20Hz, the duty ratio is greater than 1% and the amplitude is at least 2mVpp. If these parameter ranges are exceeded, Auto Set will fail. Figure 2-10 Auto Set Waveform Auto Range - Continuously automatic, the oscilloscope continuously adjusts the vertical scale, horizontal time base and trigger level in a real-time manner according to the magnitude and frequency of signal.
  • Page 48 Chapter 2. Quick Start Guide of Oscilloscope Open the main menu and tap “Auto” to open the auto range menu for the corresponding settings. When the oscilloscope auto range function is turned on, the oscilloscope will automatically set various parameters, including: vertical scale, horizontal time base, trigger level, etc.
  • Page 49 Figure 2-11 Open Auto Range Auto Range is usually more useful than Auto Set under the following situations: It can analyze signals subject to dynamic changes. It can quickly view several continuous signals without adjusting the oscilloscope. This function is very useful if you need to use two probes at the same time, or if you can only use the probe with one hand because the other hand is full.

  • Page 50: Load Factory Settings

    Chapter 2. Quick Start Guide of Oscilloscope 2.13 Load Factory Settings Open the main menu, tap “User Settings” to enter the user setting page. Tap “Factory Settings” and the dialog box for loading factory settings will pop-up. Press “OK” and load the factory settings. The dialog box for loading factory settings is shown in Figure 2-12.
  • Page 51 “Calibrating” in red, and after calibrating is finished, the word in red disappears. When the temperature changes largely, the auto-calibration function can make the oscilloscope maintain the highest accuracy of measurement. ⚫ Auto-calibration should be done without probe. ⚫ Auto-calibration process takes about two minutes. ⚫...
  • Page 52 Chapter 2. Quick Start Guide of Oscilloscope Manual zero calibration- The oscilloscope supports manual zero calibration for each channels. Click the "Fine" button in the lower left corner would open the forced channel selection menu and display the offset value, select the channel to be adjusted, and slide the waveform up and down to manually adjust the zero position.

  • Page 53: Passive Probe Compensation

    2.15 Passive Probe Compensation Before connecting to any channels, users should make a probe compensation to ensure the probe match the input channel. The probe without compensation will lead to larger measurement errors or mistakes. Probe compensation can optimize the signal path and make measurement more accurate. If the temperature changes 10℃ or above, this program must run to ensure the measurement accuracy.
  • Page 54 Chapter 2. Quick Start Guide of Oscilloscope Figure 2-14 Probe Connection Open the channel (if the channel is closed). Adjust the oscilloscope channel attenuation coefficient to match the probe attenuation ratio.
  • Page 55 button or manually adjust the waveform vertical sensitivity and horizontal time base. Observe the shape of the waveform, see Figure 2-15. Figure 2-15 Probe Compensation...
  • Page 56 Chapter 2. Quick Start Guide of Oscilloscope If the waveform on the screen is shown as “under-compensation” or “over-compensation”, please adjust the trimmer capacitor until the waveform shown on the screen as “correct-compensation”. The probe adjustment is shown in Figure 2-16. Figure 2-16 Probe Adjustment...
  • Page 57 The safety ring on the probe provides a safe operating range. Fingers should not exceed the safety ring when using the probe, so as to avoid electric shock. Connect the probe to all other oscilloscope channels (Ch2 of a 2-channel oscilloscope, or Ch 2, 3 and 4 of a 4- channel oscilloscope).

  • Page 58: Modify The Language

    Chapter 2. Quick Start Guide of Oscilloscope 2.16 Modify the Language To modify the display language, please refer to “12.3 Settings - Language and Input Method”.

  • Page 59: Chapter 3 Horizontal System

    Chapter 3 Horizontal System This chapter contains the detailed information of the horizontal system of the oscilloscope. You are recommended to read this chapter carefully to understand the set functions and operation of the horizontal system of the Smart series oscilloscope. ⚫...
  • Page 60 Chapter 3 Horizontal System Figure 3-1 Horizontal system...

  • Page 61: Move The Waveform Horizontally

    3.1 Move the Waveform Horizontally Put one finger on the waveform display area to swipe left and right, for the coarse adjustment of the waveform position horizontally of all analog channels; after moving the waveform, tap the fine adjustment button in the lower left corner of the screen for fine adjustment.

  • Page 62: Adjust The Horizontal Time Base (Time/Div)

    Chapter 3 Horizontal System 3.2 Adjust the Horizontal Time Base (time/div) Method 1: Soft Keys buttons to adjust the horizontal time base of all analog channels (current channels). Tap button to increase the horizontal time base; tap button to zoom out the horizontal time base (see Figure 3-3 Adjust the Horizontal Time Base).
  • Page 63 Figure 3-3 Adjust the Horizontal Time Base Method 2: Time Base Knob to open the time base list (see Figure 3-4 Horizontal Time Base List), then tap the list to select the appropriate time base. The time base with the blue filled background is the currently selected time base.

  • Page 64: Pan And Zoom Single Or Stopped Acquisitions

    Chapter 3 Horizontal System Figure 3-4 Horizontal Time Base Knob 3.3 Pan and Zoom Single or Stopped Acquisitions After the oscilloscope is stopped, the stopped display screen may contain several acquired data with useful information, but only the data in the last acquisition can be horizontally moved and zoomed. The data of the single...

  • Page 65: Roll, Xy

    acquisition or stopped acquisition is moved horizontally and zoomed. For details, refer to “3.1 Move the Waveform Horizontally” and “3.2 Adjust the Horizontal Time Base (time/div)”. 3.4 Roll, XY In the main menu, tap the soft key , then select the desired time base mode. The time base mode is divided into YT, ROLL, and XY.
  • Page 66 Chapter 3 Horizontal System In YT mode, the relative relationship between vertical voltage and horizontal time is displayed. Y axis represents the voltage, X axis represents the time, and the waveform is displayed after triggering (waveform displayed from left to right). Note: When the time base is large (such as 200ms and above), sometimes the waveform will not be displayed for a long time;...
  • Page 67 Figure 3-6 ROLL Mode In ROLL mode, press to stop waveform display; press again to clear waveform display and restart acquisition; press to execute single sequence, it will stop automatically after completing a full screen acquisition. ROLL mode is generally used to observe waveforms with frequencies below 5 Hz.
  • Page 68 Chapter 3 Horizontal System ROLL mode is defaulted as open. When the time base is greater than 100ms, it automatically enters the ROLL mode. If the signal to be triggered under a large time base needs to be viewed, turn off the ROLL mode. Roll mode on and off: In the main menu, tap the soft key .
  • Page 69 XY——XY Mode The vertical amount of CH1 is displayed on the horizontal axis in XY mode, and the vertical amount of CH2 is displayed on the vertical axis (see Figure 3-8 XY Mode). You can use XY mode to compare the frequency and phase relationship of two signals. XY mode can be used for sensors to display stress-displacement, flow-pressure, voltage-frequency or voltage- current, for example: plotting a diode curve.
  • Page 70 Chapter 3 Horizontal System Figure 3-8 XY Mode XY Mode Example This exercise shows the usual practice of XY display mode by measuring the phase difference between two signals of the same frequency using the Lissajous method.
  • Page 71 Connect sine wave signals to CH1 and connect sine wave signals of the same frequency and different phases to CH2. Press “Auto” set button, tap “Display” in the main menu, then select “XY” in “Time Base”. Drag signals so that they are centered on the display screen. Adjust the vertical sensitivity of CH1 and CH2, and extend signals for viewing.
  • Page 72 Chapter 3 Horizontal System Figure 3-9 XY Time Base Mode Signal, Center on the Display Screen Tap the “Cursor” button to open the horizontal cursor. Set the cursor y2 at the top of the signal and the cursor y1 at the bottom of the signal. Record the Δy value in the upper right corner of the screen.
  • Page 73 Figure 3-10 Phase Difference Measurement and Using the Cursor The following formula is used to calculate the phase difference. For example, if the first Δy value is 9.97V, the second Δy value is 5.72V:...

  • Page 74: Zoom Mode

    Chapter 3 Horizontal System 3.5 Zoom Mode Zoom is a horizontally expanded version of the normal display. Open the zoom function, the display is divided into two parts (see Figure 3-11 Zoom Interface). The upper part of the display screen shows the normal display window view and the lower part shows the zoomed display window.
  • Page 75 Zoom window view is the enlarged portion of the normal display window. You can use “Zoom” to view a portion of the normal window that is horizontally expanded to learn more about signal analysis. Zoom on/off: Open the pull-up menu and tap button to turn the zoom function on/off.
  • Page 76 Chapter 3 Horizontal System Note: The minimum time base is displayed in the normal window when the waveform in the screen is exactly within the memory depth. If the current time base is smaller than the minimum time base in the normal window at the current memory depth, when the zoom window is opened, the time base in the normal window is automatically set to the minimum time base in the normal window at the current memory depth.

  • Page 77: Chapter 4 Vertical System

    Chapter 4 Vertical System This chapter contains the detailed information of the vertical system of the oscilloscope. You are recommended to read this chapter carefully to understand the set functions and operation of the vertical system of the Smart series oscilloscope.
  • Page 78 Chapter 4 Vertical System The figure below shows the “CH1 Channel Menu” displayed after opening the CH1 channel menu. Figure 4-1 Channel Menu Display Interface The ground level of each displayed analog channel signal is indicated by the channel indicator icon on the far left of the display screen.

  • Page 79: Open/Close Waveform (Channel, Math, Reference Waveforms)

    4.1 Open/Close Waveform (Channel, Math, Reference Waveforms) The channel icons on the right side of the oscilloscope waveform display area (swipe up or down to switch to math channel and reference channel) correspond to the six channels of CH1, CH2, CH3, CH4, math function and reference channel. The channel icons in open state will shows like .
  • Page 80 Chapter 4 Vertical System Figure 4-2 Current Channel and Non-Current Channel The display content of the oscilloscope channel display interface includes the vertical scale, vertical scale sensitivity button, coupling mode, invert, bandwidth limitation of the channel, as shown in Figure 5-3.
  • Page 81 Figure 4-3 Channel Display Interface When CH1 is on, but the state is not the current channel, tap CH1 waveform or vertical sensitivity or channel indicator or vertical sensitivity button or current channel selection button to set CH1 as the current channel, as shown in Figure 4-4.
  • Page 82 Chapter 4 Vertical System Figure 4-4 Channel Open, Close and Switching...
  • Page 83 Figure 4-5 Using the Current Channel Selection Button Tap the current channel icon at the bottom of the screen to pop up the current channel switching menu and press the button to light it up, as shown in Figure 4-5. Tap the button in the menu to switch the current channel. When this function is opened:...

  • Page 84: Adjust Vertical Sensitivity

    Chapter 4 Vertical System the current channel may be switched in the channel switching menu; the current channel menu can be moved anywhere on the screen; only the open channel is displayed in the channel switching menu; when the math or reference waveform is opened, the current channel switching menu is automatically opened. 4.2 Adjust Vertical Sensitivity Tap the vertical sensitivity buttons on the right side of the channel icon to adjust the vertical display...

  • Page 85: Adjust Vertical Position

    The vertical sensitivity coefficient adjusts the vertical sensitivity of the analog channel in steps of 1-2-5 (the probe attenuation coefficient is 1X), and the vertical sensitivity range of 1:1 probe is 1mV/div-10V/div (optionally minimum at 500uV/div). 4.3 Adjust Vertical Position The method of adjusting vertical position is as follows: Coarse adjustment: In the waveform display area, hold the waveform and put one finger to slide up and down for changing the vertical position of the waveform.
  • Page 86 Chapter 4 Vertical System The channel menu is shown in Figure 4-6. Channel waveform inversion, channel bandwidth limit, probe type, probe attenuation factor, channel coupling mode, vertical expansion reference, channel label and channel on/off can be set in the vertical menu. Figure 4-6 Channel menu...

  • Page 87: Set Channel Coupling

    4.4.1 Set Channel Coupling Tap the icon under “Coupling Mode” and select “DC”, “AC” and “GND” channel coupling modes in the pop-up box. DC: DC coupling. Both the DC component and the AC component of the measured signal can pass, and can be used to view waveforms as low as 0 Hz without large DC offset.
  • Page 88 Chapter 4 Vertical System Figure 4-7 DC Coupling Figure 4-8 AC Coupling...
  • Page 89 Figure 4-9 GND Coupling Note: This setting is only valid for the current channel. To switch from the current channel, just tap the channel icon, channel indicator icon or horizontal position pointed by the channel indicator icon for direct switching. You do not need to exit the menu.

  • Page 90: Set Bandwidth Limit

    Chapter 4 Vertical System 4.4.2 Set Bandwidth Limit Open the channel menu, find the “Bandwidth” selection box in the channel menu, set bandwidth limit, high-pass filtering and low-pass filtering as needed. Full Bandwidth: Allows signals of all frequencies to pass. 20M Bandwidth: Only signals with frequencies below 20MHz are allowed to pass, and signals above 20MHz are effectively attenuated.
  • Page 91 For TO3004, high-pass filtering and low-pass filtering can be set within the frequency range of 30Hz-300MHz. The difference in bandwidth limitation can be visualized by the waveform. The full bandwidth is shown in Figure 4-10, the 20M bandwidth is shown in Figure 4-11, the high pass is shown in Figure 4-12, and the low pass is shown in Figure 4-13.

  • Page 92: Waveform Inversion

    Chapter 4 Vertical System Figure 4-12 High Pass Figure 4-13 Low Pass 4.4.3 Waveform Inversion After selecting “Invert”, the voltage value of the displayed waveform is inverted. Inversion affects the way the channel is displayed. When using a basic trigger, you need to adjust the trigger level to keep the waveform stable.

  • Page 93: Set Probe Type

    Figure 4-14 Before Inversion Figure 4-15 After Inversion 4.4.4 Set Probe Type Probe types are divided into voltage probe and current probe. Probe type adjustment steps: Open the channel menu, find the “Probe Type” checkbox in the channel menu, then select: ⚫...

  • Page 94: Set Probe Attenuation Coefficient

    Chapter 4 Vertical System ⚫ Cur - corresponding the current probe. 4.4.5 Set Probe Attenuation Coefficient When measuring with a probe, the correct measurement result can only be obtained by setting the correct probe attenuation ratio. In order to match the actual probe attenuation ratio, it is necessary to adjust the channel attenuation factor correspondingly under the channel menu.
  • Page 95 Probe attenuation ratio and menu attenuation ratio are shown in the table below: Probe attenuation ratio Probe attenuation ratio Probe attenuation ratio Probe attenuation ratio Menu attenuation ratio Menu attenuation ratio Menu attenuation ratio Menu attenuation ratio 0.001:1 0.1:1 100mx 10:1 1000:1 0.002:1...

  • Page 96: Vertical Expansion Reference

    Chapter 4 Vertical System 4.4.6 Vertical Expansion Reference When using vertical expansion, click the center or zero point. Center: Click the center, adjust the vertical scale, and the oscilloscope waveform is expanded with the screen center as reference Zero point: Click the zero point, adjust the vertical scale, and the oscilloscope waveform is expanded with the waveform zero point as reference 4.4.7 Labels Labels can be added to each analog channel as needed, and the added label is displayed behind the channel...
  • Page 97 Figure 4-16 Label Note: Customization supports up to 16 characters.

  • Page 98: Channel Input Impendance

    Chapter 4 Vertical System 4.4.8 Channel Input impendance Choose the appropriate impedance according to the actual test matching cable or probe, you can choose "1MΩ" or "50Ω", the default input impedance is 1MΩ. 1MΩ-also known as high resistance, matching most passive probes, can minimize the load effect of the oscilloscope on the device under test.
  • Page 99 Figure 4-17 Channel Input impendance Note: When switching channel input impedance, you need to pay attention to the input voltage not to exceed the allowable voltage; In order to obtain protection for the channel input, the oscilloscope input impedance is 1MΩ by default in the shutdown state.

  • Page 100: Chapter 5 Trigger System

    Chapter 5 Trigger System Chapter 5 Trigger System This chapter contains the detailed information of the trigger system of the oscilloscope. You are recommended to read this chapter carefully to understand the set functions and operation of the trigger system of the Smart series oscilloscope.

  • Page 101: Trigger And Trigger Adjustment

    5.1 Trigger and Trigger Adjustment What is Trigger? The oscilloscope can capture a waveform only when it meets a preset condition first. This action of capturing the waveform according to the condition is Trigger. The so-called capture waveform is that the oscilloscope grabs a signal and displays it.
  • Page 102 Chapter 5 Trigger System The oscilloscope can stably display a periodic signal. Figure 5-1 Stably Displayed Periodic Signal Figure 5-2 Non-Stably Displayed Periodic Signal...
  • Page 103 Grab the segment you want to observe from a fast and complex signal Figure 5-3 Abnormal Signal in Periodic Signals Figure 5-4 Abnormal Signal Captured by Setting Trigger Level...
  • Page 104 Chapter 5 Trigger System What is Forced Trigger? When the oscilloscope does not meet the trigger condition, the artificial or automatic oscilloscope trigger is the forced trigger. It means that the oscilloscope only grabs a signal segment for display regardless of whether the condition is met or not.
  • Page 105 Figure 5-5 Oscilloscope Trigger Mode Setting If a signal feature is not understood, the oscilloscope should be set as “Auto” mode, which can ensure that the oscilloscope can also display the waveform when other trigger settings are not correct. Although the waveform is not necessarily stable, it can provide the intuitive judgment for our further adjustment of the oscilloscope.
  • Page 106 Chapter 5 Trigger System When we set a specific trigger condition for a specific signal, especially when the time interval for satisfying the trigger condition is long, we need to set the trigger mode to “Normal” so as to prevent the oscilloscope from automatic forced trigger.
  • Page 107 messages. The number of delay ranges available (pre-trigger and post-trigger messages) depends on the selected time base and memory depth. Adjust trigger position (horizontal delay) Fingers swipe left and right in the waveform display area, the trigger point will move horizontally, the horizontal delay time changes, and the delay time is displayed at the top center of the screen, that is, the distance between the trigger point and the center line...
  • Page 108 Chapter 5 Trigger System When the trigger point is located on the left side to the center line of the waveform display area, the delay time is displayed as a positive value; When the trigger point is located on the right side to the time reference point , and the delay time is displayed as a negative value;...
  • Page 109 Figure 5-8 Trigger Level Adjust trigger level The trigger level can be coarsely adjusted and finely adjusted. Coarse adjustment: Slide up and down in the trigger level adjustment area.
  • Page 110 Chapter 5 Trigger System Fine adjustment: Tap the fine adjustment button in the lower left corner of the screen for fine adjustment of the trigger level. Trigger setting shortcut Left swipe from trigger level slide bar to open trigger setting shortcut, which includes trigger source, trigger mode etc.
  • Page 111 Set trigger hold-off time The trigger hold-off time can set up the waiting time of the oscilloscope after the trigger and before the trigger circuit is reconnected. During hold-off time, the oscilloscope does not re-trigger until the end of the hold-off time, and the hold-off time can be used to stably trigger complex waveforms.
  • Page 112 Chapter 5 Trigger System Set trigger hold-off time: Tap “Trigger” on the main menu to open the trigger menu. Under “Common”, tap the box after “Rejection Time” to open the hold-off time adjustment interface. The trigger time is displayed on the upper left, the fine adjustment time scale is displayed on the upper right, and the coarse time scale is displayed below, as shown in Figure 5-11.
  • Page 113 Trigger hold-off operation prompt It is typically used for complex waveforms. The correct rejection setting is usually slightly smaller than one repetition of the waveform. Setting the hold-off time to this time can become the only trigger point for the repetitive waveform.

  • Page 114: Edge Trigger

    Chapter 5 Trigger System 5.2 Edge Trigger When the edge of trigger signal reaches a certain trigger level, the set signal is triggered and generated. Trigger occurs on either edge of the rising edge (indicating icon at the top of the screen), falling edge ( ) or dual edge ( ), and the trigger level can be set to change the vertical position of the trigger point on the trigger edge, namely the intersection point of the trigger level line and the signal edge.
  • Page 115 Rising edge Set signal trigger on the rising edge Slope Falling edge Set signal trigger on the falling edge Dual edge Set signal trigger on either rising edge or falling edge AC and DC components getting through trigger signals Filter out the DC component of trigger signals HF rejection Suppress signals above 50KHz in trigger signals Coupling...
  • Page 116 Chapter 5 Trigger System ⚫ Trigger coupling mode: DC; ⚫ Trigger edge: rising. Figure 5-12 Edge Trigger Setting Menu Adjust the trigger level to ensure that the waveform can be triggered stably, for example, the trigger level is set to 1V. Trigger coupling description...
  • Page 117 When the edge trigger setup menu is opened, the trigger coupling option is displayed below the menu. Trigger coupling includes DC, AC, HFRei., LFRej., NoiseRej, see Figure 5-13: Figure 5-13 Trigger Coupling Menu DC coupling - allows DC and AC signals to enter the trigger path. AC coupling - removes any DC offset voltage from the trigger waveform.
  • Page 118 Chapter 5 Trigger System LFRej. (Low Frequency Rejection Coupling) - removes any unnecessary low frequency components from the trigger waveform, for example, power line frequencies that can interfere with correct trigger. When there is low frequency noise in the waveform, stable edge triggering can be obtained using LF rejection coupling.

  • Page 119: Pulse Width Trigger

    5.3 Pulse Width Trigger The trigger happens when the trigger signal pulse width (8ns~10s, the trigger type indication icon at the top of the screen is ) reaches the set condition and the signal voltage reaches the set trigger level. Pulse width trigger menu is shown in the following table: Description Trigger Option...
  • Page 120 Chapter 5 Trigger System Description Trigger Option Setting Trigger when the signal pulse width is equal to pulse width T ＝T ≠T Trigger when the signal pulse width is not equal to pulse width T Trigger Pulse 8ns~10s Set the trigger pulse width Width Notes: Conditions of greater than, smaller than, equal to or not equal to indicating that the error is 6%.
  • Page 121 ⚫ Trigger condition and pulse width time: “greater than”, the adjustment time is 180us. Figure 5-14 Pulse Width Trigger Setting Menu Pulse width trigger setting description: 1) Pulse polarity selection The selected pulse polarity icon is displayed in the upper right corner of the display screen. The positive pulse is higher than current trigger level (CH1 positive pulse indication icon ), and the negative pulse is...
  • Page 122 Chapter 5 Trigger System lower than current trigger level (CH1 negative pulse indication icon ). When triggered on positive polarity pulse, if the restrictions are true, the trigger will happen on the high-to-low transition of the pulse; when triggered on negative polarity pulse, if the restrictions are true, the trigger will happen on the low-to-high transition.
  • Page 123 Trigger condition and pulse width time setting Time restrictions that can set in the trigger condition: <, >, ＝, ≠. ⚫ Smaller than the time value (<) For example, for positive pulse, if it is set as T<80ns, the trigger will happen stably only when the pulse width is smaller than 80ns (Figure 5-16 Trigger Time T<80ns).
  • Page 124 Chapter 5 Trigger System Trigger Figure 5-17 Trigger Time T>80ns ⚫ Equal to the time value (=) For example, for positive pulse, if it is set as T=80ns, the trigger will happen stably only when the pulse width is equal to 80ns (Figure 5-18 Trigger Time T=80ns). Trigger Figure 5-18 Trigger Time T=80ns ⚫...
  • Page 125 For example, for positive pulse, if it is set as T≠80ns, the trigger will happen stably only when the pulse width is not equal to 80ns (Figure 5-19 Trigger Time T≠80ns). Trigger Figure 5-19 Trigger Time T≠80ns The trigger pulse width time can be set as 8ns~10s. Tap the pulse width time setting box to pop up the time adjustment interface (as shown in Figure 5- 20), and adjust the pulse width time.

  • Page 126: Logic Trigger

    Chapter 5 Trigger System 5.4 Logic Trigger Trigger happens when the level between analog channels satisfies a certain logical operation (AND, OR, NAND, NOR) and the signal voltage reaches the set trigger level and the trigger logic width (8ns~10s). Logic trigger menu descriptions are shown in the table below: Trigger Option Setting...
  • Page 127 Set CH3 as low None Set CH3 as none High Set CH4 as high Set CH4 as low None Set CH4 as none Select the logic of trigger source as “AND” Select the logic of trigger source as “OR” Trigger Logic NAND Select the logic of trigger source as “NAND”...
  • Page 128 Chapter 5 Trigger System Notes: Conditions of greater than, smaller than, equal to or not equal to indicating that the error is 6%. Logic trigger operation steps between channels: Tap “Trigger” on the main menu to open the trigger menu, select logic trigger in the trigger type, and set the logic trigger as follows, as shown in Figure 5-21: ⚫...
  • Page 129 Figure 5-21 Logic Trigger Setting Menu Logic trigger setting description: Logic level setting After trigger source, select High, Low and None for the channel. The corresponding trigger level value is displayed in the upper right corner of the display screen.
  • Page 130 Chapter 5 Trigger System High: means a value higher than the current trigger level, and the icon indication is “ ”. Low: means a value lower than the current trigger level, and the icon indication is “ ”. None: This channel is invalid. Switch the trigger level channel: Tap the trigger level slide bar arrow or use trigger setting shortcut Logic conditions True: Trigger when the logic changes to true value...
  • Page 131 Figure 5-22 Trigger Level Adjustment Trigger pulse width time can be set as 8ns~10s. Tap the time setting box ( ) to pop up the time adjustment interface and adjust the logic time. Please refer to the Pulse Width Adjustment section for details.

  • Page 132: Nth Edge Trigger

    Chapter 5 Trigger System 5.5 Nth Edge Trigger When the trigger signal is triggered on the Nth edge after the specified idle time, it is Nth edge trigger. Menu descriptions of the Nth edge trigger are shown in the table below: Trigger Option Setting Description...
  • Page 133 Set CH1 to trigger on the 5th rising edge after 500us. The steps are as follows: Tap “Trigger” on the main menu to open the trigger menu, select Nth edge trigger in the trigger type, and set the Nth edge trigger as follows, as shown in Figure 5-23: ⚫...
  • Page 134 Chapter 5 Trigger System Figure 5-23 Nth Edge Trigger Menu Adjust the trigger level to ensure that the waveform can be triggered stably, for example the trigger level is set to 1.692V.

  • Page 135: Runt Trigger

    5.6 Runt Trigger By setting the high and low thresholds, trigger on a pulse that cross one threshold but fail to cross a second threshold. There are two types available: positive short pulse and negative short pulse. Positive Short Pulse High Level Low Level Negative Short Pulse...
  • Page 136 Chapter 5 Trigger System Trigger Option Setting Description Set CH3 as trigger signal source Set CH4 as trigger signal source Set signal to trigger on positive runt pulse Positive Set signal to trigger on negative runt pulse Polarity Negative Set signal to trigger on either positive or negative runt pulse <T Trigger when the signal pulse width is smaller than pulse width T >T...

  • Page 137: Slope Trigger

    Figure 5-25 Runt Trigger Setting Menu 5.7 Slope Trigger Slope Trigger means trigger when the waveform reaches a set time condition from one level to another.
  • Page 138 Chapter 5 Trigger System Positive slope time: Time takes for the waveform to go from low to high. Negative slope time: Time takes for the waveform to go from high to low. As shown in Figure 5-26 High Level Positive Slope Time Negative Slope Time Figure 5-26 Positive/Negative Slope Time When the trigger signal slope has the hold time (8ns~10s), the trigger type on the top of the screen is only the icon...
  • Page 139 Trigger Option Setting Description Set CH2 as trigger signal source Set CH3 as trigger signal source Set CH4 as trigger signal source Set trigger on positive signal slope Rising Set trigger on negative signal slope Edge Falling Set trigger on detecting a signal slope change <T Trigger when the signal slope hold time is smaller than T >T...
  • Page 140 Chapter 5 Trigger System Tap “Trigger” on the main menu to open the trigger menu, select the slope trigger in the trigger type, and set the slope trigger as follows, as shown in Figure 5-27: ⚫ Trigger source: CH1; ⚫ Edge: Rise; ⚫...
  • Page 141 Figure 5-27 Slope Trigger Setting Menu The slope hold time can be set as 8ns~10s. Note: A stable trigger waveform can only be obtained by selecting the channel to which signals are connected as trigger source.

  • Page 142: Timeout Trigger

    Chapter 5 Trigger System 5.8 Timeout Trigger Timeout trigger happens when the time from the intersection of signal and trigger level and above (or below) the trigger level reaches the set time, as shown in Figure 5-28: Duration Set Level Figure 5-28 Timeout Trigger Schematics...
  • Page 143 Timeout trigger menu descriptions are shown in the table below: Trigger Option Setting Description Set CH1 as trigger signal source Set CH2 as trigger signal source Trigger Source Set CH3 as trigger signal source Set CH4 as trigger signal source Select to count time when the rising edge of input signal gets through the Positive trigger level...
  • Page 144 Chapter 5 Trigger System Set the polarity of CH1 trigger signal to be positive and the timeout time as 15us. The steps are as follows: Tap “Trigger” on the main menu to open the trigger menu, select timeout trigger in the trigger type, and set the timeout trigger as follows, as shown in Figure 5-29: ⚫...

  • Page 145: Video Trigger

    Figure 5-29 Time-out Trigger 5.9 Video Trigger The triggering method for video signals depends on video formats. Generally, there are PAL/625, SECAM, NTSC/525, 720P, 1080I and 1080P formats. The video trigger can be triggered at different voltage scales, and the...
  • Page 146 Chapter 5 Trigger System appropriate voltage scale can be adjusted as needed to observe the waveform. The video trigger menu descriptions are shown in the table below: Trigger Setting Description Option Set CH1 as trigger signal source Trigger Set CH2 as trigger signal source Source Set CH3 as trigger signal source Set CH4 as trigger signal source...
  • Page 147 525/NTSC Based on NTSC signal trigger 720P Base on 720P(50Hz, 60Hz) signal trigger 1080I Base on 1080I(50Hz, 60Hz) signal trigger Base on 1080P (24Hz, 25Hz, 30Hz, 50Hz, 60Hz) 1080P signal trigger Line Trigger lines Trigger on the rising edge of the first tooth pulse Odd fields in odd fields Trigger on the rising edge of the first tooth pulse...
  • Page 148 Chapter 5 Trigger System 625 line (PAL,SECAM) 263 odd line 262 even line Lines Trigger on a specified line in odd or even fields (NTSC) 750 line (720P) 1125 line (1080I,1080P) Set CH1 as trigger channel, positive polarity, NTSC standard video, all fields trigger, and the steps are as follows: Tap “Trigger”...
  • Page 149 ⚫ Trigger: Odd fields Figure 5-30 Video Trigger Prompts: ⚫ In order to better observe the waveform details in the video signal, first set the memory depth to be larger.

  • Page 150: Serial Bus Trigger

    Chapter 5 Trigger System ⚫ During the trigger debugging of the video signal, since the digital oscilloscope has multi-level gray scale display function, different brightness can reflect the frequency of different parts of the signal. Experienced users can quickly judge the quality of the signal during the debugging process and find abnormal conditions. 5.10 Serial Bus Trigger Please refer to Chapter 11 Serial Bus Trigger and Decode (Optional)

  • Page 151: Chapter 6 Analysis System

    Chapter 6 Analysis System This chapter contains the detailed information of the analysis system of the oscilloscope. You are recommended to read this chapter carefully to understand the set functions and operation of the analysis system of the Smart series oscilloscope.

  • Page 152: Automatic Measurement

    Chapter 6 Analysis System 6.1 Automatic Measurement Measurement setting Slide down from top, open the main menu, tap “Measure” to enter the measurement menu. There are 23 measurement items on the measurement menu. Measurement menu, selected measurement item display and measurement item display are shown in Figure 6-1: Figure 6-1 Automatic Measurement Menu...
  • Page 153 Automatic measurement Select channel: Select the channel to be measured above the measurement menu. Select measurement: Select the desired measurement item on the measurement menu. The selected measurement item is displayed in the “Selected Parameters” display area below. Cancel measurement item: In the “Selected Parameters” display area below measurement menu, tap the measurement item to be cleared;...
  • Page 154 Chapter 6 Analysis System All measurements Slide from bottom, open the pull-up menu, see Figure 6-2, click to open all measurement items, display the current channel measurement value. Switch the current channel to open all the measurement items of other channels, as shown in Figure 6-3;...
  • Page 155 Rise Time Fall Time Threshold Upper Limit Negative Pulse Positive Pulse Width Width Threshold Median Threshold Lower Limit Period Figure 6-4 Time Parameter Period Time of the first complete signal cycle in the waveform Frequency Reciprocal to the cycle time Rise time Time required for the first rising edge of the waveform to rise from the amplitude of 10% to 90% Fall time...
  • Page 156 Chapter 6 Analysis System Time required for the first falling edge of the waveform to rise from the amplitude of 10% to 90% Delay Time delay between rising or falling edges of channels may be measured, and there are nine effective measurement combinations Delay Figure 6-5 Delay Measurement Schematics...
  • Page 157 The left channel is defaulted as the current channel, and other channels can be selected by the channel area that has been opened (except the reference channel); there are four edge selections: first rising edge, first falling edge, last rising edge, last falling edge. The right channel is a contrast delay channel, which can be selected between each channel and math channel.
  • Page 158 Chapter 6 Analysis System Positive pulse width Measured value of the first positive pulse in the waveform, taking the time between two 50% amplitude points Negative pulse width Measured value of the first negative pulse in the waveform, taking the time between two 50% amplitude points Burst width Duration of a burst measured over the entire waveform Overshoot...
  • Page 159 Phase Timing measurement. The amount of time that one waveform leads or lags another waveform, expressed in degrees where 360°comprises one waveform cycle. Period Delay Figure 6-6 Phase Measurement Schematics Peak-peak In the entire waveform measurement, peak-peak = max - min Amplitude In the entire waveform measurement, amplitude = high (100%) - low (0%) The figure below shows voltage measurement points.
  • Page 160 Chapter 6 Analysis System The channel probe type setting is used to set the measurement unit for each input channel to Volts or Amperes. Refer to “4.4.4 Set Probe Type”. Amplitude Peak-peak Figure 6-7 Voltage Measurement High Take 100% in the entire waveform, and calculated using either the min/max or histogram method. Take 0% in the entire waveform, and calculated using either the min/max or histogram method.
  • Page 161 Highest positive peak measured over the entire waveform Highest negative peak measured over the entire waveform True root mean square value over the entire waveform C RMS True root mean square value of the first cycle in the waveform Mean Arithmetic mean over the entire waveform C mean Arithmetic mean over the first cycle in the waveform...
  • Page 162 Chapter 6 Analysis System AC RMS True root mean square value of the AC component of the entire waveform +Rate The ratio of the difference between the high and low values of the first rising edge of the waveform to the rise time. -Rate The ratio of the difference between the low and high values of the first falling edge of the waveform to the fall time.
  • Page 163 If source channel is clipped, the measured value of math waveform is the source channel value during screen wave clipping. Statistics Swipe down from the top to open the main menu, tap "Measure", then select "Statistics" to enter the statistics menu. The oscilloscope supports statistics and displays the current value of multiple measurement results, including Mean,...
  • Page 164 Chapter 6 Analysis System Max, Min, Deviation, and Count. The number of counts can be up to 10,000 times. Click the "Reset" button to clear the historical data of all measurement items and perform statistics again, as shown in Figure 6-8: Figure 6-8 Frequency Meter Measurement Menu Open...
  • Page 165 Measure Range The default setting for measure is to calculate the waveform across the entire screen, but it can also be set to only calculate the waveform within the cursor. Open the top menu, select "Measure," and click on "Settings" to adjust the measurement range.
  • Page 166 Chapter 6 Analysis System Figure 6-9 Measure Range...
  • Page 167 Indicator Open the top menu, select "Measure," and click on the sub-menu "Setting" to open the measurement item indicators, as shown in Figure 6-10. Figure 6-10 Indicator menu After opening the indicator, you can select the displayed measurement items by clicking on them. The selected measurement item will be highlighted with a box, and its calculation object will be indicated by a white line in the waveform.
  • Page 168 Chapter 6 Analysis System Figure 6-11 Indicator...
  • Page 169 Measure Thresholds Each channel (CH1, CH2, CH3, CH4, Math) can be independently set with threshold values. The threshold type can be selected as "%" or "Absolute", as shown in Figure 6-12. Figure 6-12 Measure Thresholds The setting of thresholds will affect the results of the measurement items. The setting of the high and low values will impact the measurement results of rise time and fall time.
  • Page 170 Chapter 6 Analysis System When the set high value is lower than the current mid value, the mid value will automatically equal the high value; the high value cannot be lower than the mid value, and if the set value is lower than the low value, it will be automatically set to 1% or 10mV (absolute value) higher than the low value.

  • Page 171: Frequency Meter Measurement

    6.2 Frequency Meter Measurement Open the main menu, tap Measure and Counter to enter the hardware frequency meter setting menu, and select the channel to be measured, as shown in Figure 6-14. The measured value is displayed in the upper left corner of the screen, as shown in Figure 6-15.

  • Page 172: Cursor

    Chapter 6 Analysis System Figure 6-15 Frequency Meter Measurement 6.3 Cursor Open cursor and place it on the measurement point to read the waveform measurement value. There are two types of cursors: horizontal cursor and vertical cursor. The horizontal cursor measures the vertical direction magnitude, and the vertical cursor measures the horizontal direction magnitude, as shown in Figure 6-16.
  • Page 173 Figure 6-16 Cursor Measurement Description Note: △ reading: indicates the difference between two cursor positions. Voltage readings after Y1, Y2: indicate the position of activated horizontal cursors relative to the zero potential.
  • Page 174 Chapter 6 Analysis System Time readings after X1, X2: indicate the position of activated vertical cursors relative to the trigger point. 1/△X: frequency Vertical cursor on/off and activation Vertical cursor on/off Vertical cursor on: Tap cursor icon to open vertical cursors and the icon is on and activated. Vertical cursor off: Tap cursor icon to turn off vertical cursors.
  • Page 175 Figure 6-17 Open Cursor Selection Box and Close Cursor Vertical cursor movement descriptions: Use a single finger to press and hold the cursor indicator line on the screen to make coarse adjustment to the cursor; tap the fine adjustment button in the lower left corner of the screen to fine-adjust the cursor that has just been adjusted.
  • Page 176 Chapter 6 Analysis System Cursor linkage: When the cursor is opened, two finger slide and enter the cursor linkage state. Note: During the sliding process, the current operation is changed unless the initial two fingers leave the screen. If one finger leaves the screen and the other finger does not leave, the current linkage adjustment is continued.
  • Page 177 Figure 6-18 Cursor Measurement Pulse Width Figure 6-19 In XY Mode, Cursor Measurement In the XY horizontal mode, X cursor displays CH1 value (V or A), and Y cursor displays CH2 value (V or A).

  • Page 178: Chapter 7 Screen Capture, Memory Depth And Waveform Storage

    Chapter 7 Screen Capture, Memory Depth and Waveform Storage Chapter 7 Screen Capture, Memory Depth and Waveform Storage This chapter contains the detailed information of the screen capture function and memory depth of the oscilloscope. You are recommended to read this chapter carefully to understand the storage system of the Smart series oscilloscope.

  • Page 179: Screen Capture Function

    7.1 Screen Capture Function The screen capture function can locally store the display information on the current display screen in picture format. Screen capture method: Slide upward from bottom to open pull-up menu. Tap the icon to have a screen capture in the oscilloscope application.
  • Page 180 Chapter 7 Screen Capture, Memory Depth and Waveform Storage Please refer to “12.7 Gallery” for details on viewing pictures. Timestamp and InverseColor Invert and time-stamp screenshots is possible in oscilloscope. Open the main menu, tap Save and enter Picture menu, turn off/on Timestamp and InverseColor button as desired. Figure 7-2 Timestamp &...

  • Page 181: Video Recording

    7.2 Video Recording The video recording function is similar to the screen capture function, and the display information of the current display screen can be stored locally in video format. Video recording method is sliding down from top in non-oscilloscope application, open pull-down menu, tap the screen to start recording, and count down to three seconds to complete the video recording, as shown in Figure 7-3.

  • Page 182: Waveform Storage

    Chapter 7 Screen Capture, Memory Depth and Waveform Storage Figure 7-3 Video Recording Method Figure 7-4 Video Recording Please refer to “12.7 Gallery” for details of viewing videos. 7.3 Waveform Storage The oscilloscope can save the analog channel or math channel waveform locally or in USB device. The file type can be WAV, CSV or BIN.
  • Page 183 The oscilloscope provides four reference channels, which can be called to load WAV format files into the reference channel and open the reference channel to display the reference waveform. Save reference file Slide down from top, open main menu and tap "Save" to open the menu. Save the reference waveform interface of the specified channel as follows: Figure 7-5 Save CH1 Reference Waveform Interface...
  • Page 184 Chapter 7 Screen Capture, Memory Depth and Waveform Storage Location: Stored locally and in USB device. File types: WAV, CSV, and BIN. File name: The initial file name is displayed as year + month + day + storage serial number. Press the file name box to pop up the virtual keyboard, tap “Backspace”...
  • Page 185 Save the reference waveform by steps as follows: The current channel is set to the channel to be saved, which can be analog channel, math channel or reference. In the main menu, tap "Save" to enter the save menu. In the Save menu, tap "Save" to open the Save Reference Waveform menu and make the following settings: ⚫...
  • Page 186 Chapter 7 Screen Capture, Memory Depth and Waveform Storage In the Save Reference Waveform menu, tap R* (R1, R2, R3, R4) button to save the current channel waveform directly to the corresponding reference channel, and the save success prompt will pop up. The file name is displayed as Ref* in the reference channel (* is the corresponding reference channel name).
  • Page 187 Figure 7-6 Delete Reference Files...
  • Page 188 Chapter 7 Screen Capture, Memory Depth and Waveform Storage CSV files CSV file structure CSV format contains the basic information of the saved data: save time, file name, data length, sampling interval, trigger time, source, vertical scale, vertical offset, vertical accuracy, horizontal time base, horizontal accuracy, probe multiples.

  • Page 189: Oscilloscope Setting Save

    Explanation: If the oscilloscope sampling rate is 1GSa/s, sampling will be once every 1ns. If the horizontal scaling is set to 10us/div, the data of 140us will be displayed (because there are 14 divisions on screen). To find the total number of samples, the oscilloscope will perform: 140us×1GSa/s=140K sampling, which require the oscilloscope to display 140K times of sampling using 600-pixel columns.
  • Page 190 Chapter 7 Screen Capture, Memory Depth and Waveform Storage Open the main menu, tap Save and enter Setting menu, as shown in Figure 7-7. Figure 7-7 oscilloscope setting save Tap the black box area to rename save settings, tap the Save button to store, the Recovery button to restore the settings.

  • Page 191: Chapter 8 Math And Reference

    Chapter 8 MATH and Reference This chapter contains the detailed information of the MATH operation and reference channel of the oscilloscope. You are recommended to read this chapter carefully to understand the setting functions and operations of the MATH and reference channels of the Smart series oscilloscope. ⚫...

  • Page 192: Dual Waveform Calculation

    Chapter 8 MATH and Reference 8.1 Dual Waveform Calculation Figure 8-1 MATH Channel Waveform Display math waveform Swipe up or down at the channel selection area to enter the second channel selection area. Tap the soft key open the math channel. After the math waveform is opened, the current channel selector is automatically opened.
  • Page 193 Left swipe math channel icon to open the math channel menu. While opening math for the first time, the math operation is defaulted as the dual channel calculation. Math operation prompt If the analog channel or math function is clipped (not fully displayed on the screen), the resulting math function will also be clipped.
  • Page 194 Chapter 8 MATH and Reference For details of movement, vertical sensitivity adjustment, time base adjustment and vertical expansion reference of the math channel, please refer to “Chapter 3 Horizontal System” and “Chapter 4 Vertical System”. The vertical sensitivity, unit and time base corresponding to the math waveform are displayed in the channel area of the math channel.
  • Page 195 Note: If the units of two operation source channels are different and the unit combination cannot be identified, the unit of math function will be displayed as? (undefined). Math operators Math operators perform arithmetic operations on the analog input channels. Addition or subtraction If addition or subtraction is selected, the values of function sources 1 and 2 will be added or subtracted point by point and the results will be displayed.
  • Page 196 Chapter 8 MATH and Reference Figure 8-2 Mathematical Operation of CH1 adding CH2 Multiplication or division When multiplication or division is selected, the values of function sources 1 and 2 values will be multiplied or divided point by point and the results will be displayed. Multiplication is useful when viewing the power relationship, if one of the channels is proportional to the current.

  • Page 197: Fft Measurement

    8.2 FFT Measurement FFT is used to calculate the Fast Fourier Transform using the analog input channel. FFT record specifies the digitization time of the source and converts it to the frequency domain. After selecting the FFT function, FFT spectrum is plotted as amplitude in V-Hz or dB-Hz on the oscilloscope display screen. The reading of the horizontal axis changes from time to frequency (Hz), while the unit of the vertical axis changes from volt to V or dB.
  • Page 198 Chapter 8 MATH and Reference Open FFT Swipe up or down at the channel selection area to enter the second channel selection area. Tap the soft key to open the math channel, left swipe to open math channel menu. spectrum type “Line/Decibel” to open the FFT window (see Figure 8-3 FFT Window). Tap the Operation Source box to select the channel for which FFT transform is required.
  • Page 199 ⚫ Rectangular window This is the best window type for resolution frequencies that are very close to the same value, but this type is the least effective at accurately measuring the amplitude of these frequencies. It is the best type of measuring the spectrum of non-repetitive signals and measuring the frequency component close to DC.
  • Page 200 Chapter 8 MATH and Reference ⚫ Hanning window This is the best window type for measuring amplitude accuracy but less effective for resolving frequencies. Use Hanning to measure sinusoidal, periodic, and narrowband random noises. This window is used for measuring transients or bursts of signal levels before or after events with significant differences. ⚫...
  • Page 201 different, resulting in high-frequency transient interruption at the junction. In the frequency domain, this effect is called leakage. Therefore, to avoid leakage, the original waveform is multiplied by a window function, forcing the values at the beginning and at the end to be zero. Note: Signals with DC components or deviations can cause errors or deviations in the FFT waveform components.
  • Page 202 Chapter 8 MATH and Reference Figure 8-4 Spectrum Amplitude as V-Hz...
  • Page 203 Adjust FFT waveforms Waveform position ⚫ Select math channel as the current channel. After touching math waveform on the screen with one finger, adjust the waveform display position by dragging upward and downward, leftward and rightward, or tap the fine adjustment button in the lower left corner of the screen for fine adjustment ⚫...

  • Page 204: Advanced Math

    Chapter 8 MATH and Reference For FFT measurement, the reading of the horizontal axis changes from time to frequency (Hz), and it no longer shares the same time base with other analog channels. Therefore, before adjusting the horizontal frequency scale, the math channel must be set as the current channel.
  • Page 205 Click the corresponding button to input and edit the waveform (please click in order, the ones that are grayed out cannot be clicked). Figure 8-5 Advanced Math...
  • Page 206 Chapter 8 MATH and Reference Type Description Item Remark Function Sqrt()、Abs()、Deg()、 Functions can be nested Rad()、Exp()、Diff()、 ln()、Sine()、Cos()、 Tan()、Intg()、Log()、 arcsin()、arccos()、 arctan() Channel Source Ch1、Ch2、Ch3、Ch4 Variable Source variable1、variable2 When a variable is written in the expression, the input box of the variable appears in the math menu, indicating that it can be input;...
  • Page 207 example, input 4.1235 -3 for variable 1, which means 4.1235×10 Variable value range -9.9999~9.9999, variable power range -9~9 Operator +、-、*、/、==、!=、＞、 ＜、≥、≤、&&、||、!( symbol brackets （、） Value Source 0、1、2、3、4、5、6、7、8、 9、.、π、E × Source Numerical f、p、n、u、m、K、M、G、T unit Table 8-2 List of Advanced Math...

  • Page 208: Reference Waveform Call

    Chapter 8 MATH and Reference 8.4 Reference Waveform Call Reference waveform call and close Swipe up or down at the channel selection area to enter the second channel selection area. Left swipe button to open the reference menu, see Figure 8-5.
  • Page 209 Figure 8-6 Reference Channel Menu When there are already waveforms loaded into the reference channel, click “Open/Close” button to open or close the reference channel; the reference waveform is displayed in blue-violet, and the four stored waveforms can be displayed simultaneously, wherein the current reference waveform is brighter than non-current reference waveforms.
  • Page 210 Chapter 8 MATH and Reference Take R1 as an example, with operation steps as follows: Open reference menu. Tap the “Call” file box under R1 to open the reference file column. Click the name of the reference waveform file to be called. The file is loaded into R1 channel. Then, R1 channel is turned on as the current channel waveform, and the reference waveform channel icon highlighted.
  • Page 211 Figure 8-7 Restore Reference Waveform Close the reference waveform: In the reference menu, tap “Open/Close” button in R1 to close the reference waveform. Repeat step 1 to close other reference channels.
  • Page 212 Chapter 8 MATH and Reference Right swipe to turn off all reference waveforms. Reference waveform movement and time base adjustment The horizontal or vertical movement and zoom of reference waveforms are independent of analog channels, and the adjustments among different reference waveform channels are also independent of each other. To adjust the reference waveform of a channel, first set the channel as the current channel, and then adjust the reference waveform by move or zoom (in accordance with the analog channel method).

  • Page 213: Chapter 9 Display Settings

    Chapter 9 Display Settings This chapter contains the detailed information of the display settings and function buttons of the oscilloscope. You are recommended to read this chapter carefully to understand the display setting functions and operations of the Smart series oscilloscope. ⚫...
  • Page 214 Chapter 9 Display Settings In the main menu, tap Display button to enter display settings menu, as shown in Figure 9-1. Figure 9-1 Display Settings and Function Buttons...

  • Page 215: Waveform Settings

    9.1 Waveform Settings Open the display menu, tap Waveform button to open the waveform display menu. This menu is used to set the display mode and brightness of waveform. The waveform display mode is divided into two types: dots and vectors. The waveform brightness percentage is adjustable, and the waveform display setting is shown in Figure 9-2.

  • Page 216: Persistence Setting

    Chapter 9 Display Settings Figure 9-3 Graticule Menu Display 9.3 Persistence Setting Open the display menu and tap Persist key to open the persistence settings menu. 1) Persistence setting In the persistence setting menu, select: ⚫ None: None - no persistence. ⚫...
  • Page 217 ⚫ Normal: Normal - set the persistence time — After selecting the variable persistence, tap the box on the right of “Adjust” to pop up the persistence time selection box (Figure 9-4) and set the persistence time. It can be set between 10ms and 10s. ⚫...
  • Page 218 Chapter 9 Display Settings Figure 9-4 Persist time adjust 2) Erase persistence To erase the previously acquired results from the display, tap key or adjust the horizontal time base and vertical sensitivity. The oscilloscope will erase the persistence display and start the cumulative acquisition again.

  • Page 219: Horizontal Expansion Center

    9.4 Horizontal Expansion Center Horizontal expansion is divided into two types: screen center and trigger position: Screen center Select "Center" to adjust the time base waveform to expand or contract toward both sides with the screen center as the base point, and the delay time does not change. Trigger position Select "TrigPos"...

  • Page 220: Time Base Mode Selection

    Chapter 9 Display Settings Figure 9-5 Color Temperature Open Mode 9.6 Time Base Mode Selection For details, please refer to “3.4 ROLL, XY“ in Chapter 3.

  • Page 221: Chapter 10 Sampling System

    Chapter 10 Sampling System This chapter contains the detailed information of the sampling system of the oscilloscope. You are recommended to read this chapter carefully to understand the setting and operation of the sampling system of the Smart series oscilloscope. ⚫...

  • Page 222: Sampling Overview

    Chapter 10 Sampling System 10.1 Sampling Overview To understand the sampling and sampling modes of the oscilloscope, you need to understand the sampling principle, aliasing, oscilloscope bandwidth and sampling rate, oscilloscope rise time, required oscilloscope bandwidth, and the influence of memory depth on the sampling rate. Sampling principle According to the Nyquist sampling principle, for a bandwidth-limited signal with the maximum frequency f , the...
  • Page 223 Figure 10-1 Aliasing Oscilloscope bandwidth and sampling rate The oscilloscope bandwidth usually refers to the lowest frequency at which the input signal sine wave is attenuated by 3dB (-30% amplitude error). For oscilloscope bandwidth, according to the sampling principle, the required sampling rate is f .
  • Page 224 Chapter 10 Sampling System Frequency Figure 10-2 Theoretical Brick-Wall Frequency Response However, digital signals have frequency components that exceed the fundamental frequency (the square wave consists of sine waves at fundamental frequency and an infinite number of odd harmonics), and for bandwidths of 500MHz and below, the oscilloscope typically has Gaussian frequency response.
  • Page 225 Aliasing Frequency Figure 10-3 Sampling Rate and Oscilloscope Bandwidth The oscilloscope bandwidth is limited to 1/4 sampling frequency and reduces the frequency response above the Nyquist frequency. ≥4f Therefore, in fact, the oscilloscope sampling rate should be 4 times or more of its bandwidth: f .
  • Page 226 Chapter 10 Sampling System Oscilloscope rise time The oscilloscope rise time is closely related to its bandwidth. The rise time of an oscilloscope with Gaussian type frequency response is approximately 0.35/f (based on the standard from 10% to 90%). The oscilloscope rise time is not the fastest edge speed that an oscilloscope can accurately measure. It is the fastest edge speed that the oscilloscope can produce.
  • Page 227 According to Dr. Howard W. Johnson’s book “High-Speed Digital Design–A Handbook of Black Magic”, all fast edges have wirelessly continuous frequency components. However, there is a turning point (or “inflection point”) in the fast edge spectrum at which frequency components above f are negligible in determining the knee signal shape.

  • Page 228: Run/Stop Key And Single Seq Key

    Chapter 10 Sampling System Figure 10-4 Bandwidth Corresponding to Oscilloscope Measurement Accuracy 10.2 Run/Stop Key and Single SEQ Key Use softkeys in the button area to start and stop the oscilloscope acquisition system: Run/Stop button Single Sequence Acquisition button. ⚫ When the Run/Stop button is displayed in green, it indicates that the oscilloscope is running, that is, it meets the trigger condition and data acquisition is being performed.

  • Page 229: Select Sampling Mode

    10.3 Select Sampling Mode Open the main menu, tap the sampling mode option under “Sample”, and choose among the four sampling modes: normal, average, peak and envelope in the pop-up box. The sampling modes of all channels are same. That is, if the sampling mode of any channel is changed, the sampling mode of all channels is changed at the same time.
  • Page 230 Chapter 10 Sampling System Peak sampling mode In peak sampling mode, when the horizontal time base setting is low, the minimum and maximum sample values are retained to capture rare events and narrow events (with any noise expanded). This mode will display all pulses that are at least as wide as the sampling period.
  • Page 231 Figure 10-5 Sine Wave with Burr Figure 10-6 Sine Wave with Burr Normal Sampling Mode Peak Sampling Mode...
  • Page 232 Chapter 10 Sampling System Use peak detection mode to find burrs Connect signal to the oscilloscope to be stably displayed. To find burr, select the peak sampling mode in Sampling Mode option in the Channel menu. In the menu, tap “Display” → “Persistence”, then tap “∞” (infinite persistence). The oscilloscope will restart sampling data and display them on the screen.
  • Page 233 Average sampling mode The average sampling mode averages multiple acquisition results to reduce random or unrelated noises in the displayed signal. The average of multiple sampling results requires stable trigger. The average number can be set in the selection box after the average sampling mode, and can be set to eight order of magnitudes: 2, 4, 8, 16, 32, 64, 128 and 256.
  • Page 234 Chapter 10 Sampling System Figure 10-7 Waveform after choosing the average sampling mode, with average number 32 Envelope sampling mode In the envelope sampling mode, the superposition effect of several sampled waveforms can be observed. The maximum and minimum values of one signal can be captured in the specified N sample data, and the number of waveform superpositions can be set to 2, 4 , 8, 16, 32, 64, 128, 256 or ∞.

  • Page 235: Record Length And Sampling Rate

    Figure 10-8 AM Signal in Envelope Sampling Mode (32) 10.4 Record Length and Sampling Rate The record length is the data volume for each captured waveform. For example, if the record length is 700K, it means that 700K sample points are captured by one trigger.
  • Page 236 Chapter 10 Sampling System In the main menu, tap "Sample" to enter the record length setting menu, which can be set by tapping the corresponding record length. Figure 10-9 Record Length In normal refresh mode, if it is a single channel, or only open CH1 and CH3, or only open CH2 and CH4, the record length can be set to 22k, 220k, 2.2M, 22M, 220M, and Auto;...
  • Page 237 The oscilloscope record length and sampling rate have the following relationship: Sampling rate = record length/acquisition time Generally, the oscilloscope acquisition time is exactly the display time on the current entire screen (current horizontal time base× 14). For example, if the oscilloscope has the memory depth of 700K, the sampling rate of 1GSa/s, and the horizontal time base of 50us/div, the acquisition time is 700us, which is 50us/div×...

  • Page 238: Segmented Memory

    Chapter 10 Sampling System When the 2 channels (CH1+CH2 or CH3+CH4) are opened at the same time, the sampling rate of the 2 channels will be halved. For example, when CH1 and CH2 are open, the sampling rates of CH1 and CH2 are both 1GSa/s; but when CH1 + CH3, or, CH2 + CH4 are opened, the sampling rates of the two channels will not change, for example, when CH1 and CH3 are open, the sampling rates of ch1 and CH3 are both 2GSa/s;...

  • Page 239: Segment Number Setting

    Figure 10-10 Segmented memory settings 10.5.1 Segment number setting Open the main menu, tap "Sample", and select the "Segmented storage" option in the secondary menu to set up segmented memory.
  • Page 240 When the record length is set to "Auto", the number of segments can be set freely between 1 and the maximum number of segments. The maximum number of segments in TO series is 10000. When the record length is selected, the maximum number of segments allowed for different record lengths is different.

  • Page 241: Acquire Waveform

    time the record length is 220/110K In the case of, the maximum number of segments allowed is 1791, so the number of segments for segmented memory will be automatically set to 1791, and the user can also modify the number of segments required between 1-1791. 10.5.2 Acquire Waveform There are two collection methods, conventional collection and single collection.

  • Page 242: Display And View

    Chapter 10 Sampling System Figure 10-11 Segmented memory waveform acquisition 10.5.3 Display and View Divided into single frame display and fitting display.
  • Page 243 Single frame display is to display each segment of the waveform on the screen individually in turn. During regular acquisition, each frame of waveform will be displayed in the normal display mode. In a single acquisition, only the last frame of waveform acquired is displayed. In the stopped state, you can view the stored segments frame by frame, the previous frame/next frame, locate to a certain frame, you can play in sequence, in reverse, and you can change the playback rate.
  • Page 244 Chapter 10 Sampling System Figure 10-12 Single frame view of segmented storage Fitting display is to superimpose the waveforms of a certain range selected and display them on the screen. The start frame and end frame of the fitting display can be set. Usually the last frame of the waveform can be fitted and...
  • Page 245 displayed on the screen to check whether there is an abnormality, and then locate the abnormality by changing the start frame and the end frame after finding an abnormality. Figure 10-13 Segmented storage fitting view In both single frame display and fitting display, you can change the gear and position of the waveform, use zoom, etc.

  • Page 246: Example Of Segmented Storage

    Chapter 10 Sampling System The navigation bar and the menu are mutually exclusive. When the menu is opened, the navigation bar disappears. If necessary, it can be opened in the shortcut menu at the bottom. To save waveforms in segmented memory, please refer to Chapter 8 "7.3 Waveform Storage".
  • Page 247 4) Set the number of fitting segments to 1-100; 5) Turn on segmented storage; 6) Select single sequence. Figure 10-14 Single sequence segmented storage...
  • Page 248 Chapter 10 Sampling System There is no waveform display on the screen during the sampling process. After the sampling is completed, all the waveforms in the 1-100 segments are fitted and displayed on the screen. After observation, close the fitting display: 1) Click the play button to start playing frame by frame;...
  • Page 249 Figure 10-15 View after segment collection is completed...

  • Page 250: Chapter 11 Serial Bus Trigger And Decode (Optional)

    Chapter 11 Serial Bus Trigger and Decode (Optional) Chapter 11 Serial Bus Trigger and Decode (Optional) This chapter contains the detailed information of serial bus decoding. You are recommended to read this chapter carefully to understand the setting and operation of Smart bus trigger and decode. This chapter mainly include the below contents: ⚫...
  • Page 251 Swipe up or down at the channel selection area to enter the second channel selection area, tap enable decoding, open bus configuration menu, select bus type, there are seven bus types: UART (RS232/RS422/RS485), LIN, CAN(FD), SPI, I2C, ARINC429, 1553B, where channels S1 and S2 can be used for decoding simultaneously.
  • Page 252 Chapter 11 Serial Bus Trigger and Decode (Optional) Figure 11-1 Bus Type Selection Menu Open the pull-up menu and tap key to open or close the text mode, as shown in Figure 11-2.
  • Page 253 Figure 11-2 Bus Decode Text Mode Description: Two decode channels S1&S2 in the text interface must be configured identically to be opened, and each channel is displayed in chronological order with different colors;...
  • Page 254 Chapter 11 Serial Bus Trigger and Decode (Optional) S1/S2/S1&S2 are the channel configuration bus information, the label is switched to change the bus channel; Clicking save during the text acquisition process can save all currently acquired data. If the date volume is too large, “wait”...

  • Page 255: Uart (Rs232/Rs422/Rs485) Bus Trigger And Decode

    11.1 UART (RS232/RS422/RS485) Bus Trigger and Decode For correctly decoding UART(RS232/RS422/RS485) bus data and making trigger stable, the bus configuration, trigger mode setting and trigger level need to be adjusted. ⚫ Bus configuration Left swipe to open the bus configuration menu, as shown in Figure 11-4. The RX channel must be chosen and the following parameters must be set according to measured signals: Idle Level —...
  • Page 256 Chapter 11 Serial Bus Trigger and Decode (Optional) Baud Rate — Choose the baud rate that matches signal in measured equipment. The baud rate can be set within the range from 1.2Kb/S to 8.000Mb/S. Bus Display — Choose hexadecimal, binary or ASCII code display. Figure 11-4 UART Bus Configuration Menu...
  • Page 257 When word is displayed in ASCII, 6-bit ASCII format is used. Valid ASCII characters are between 0x00 and 0x7F. To display in ASCII, at least 7 bits in the “Bus Configuration” must be chosen. If ASCII is chosen and the data exceeds 0x7F, the data will be displayed in hexadecimal.
  • Page 258 Chapter 11 Serial Bus Trigger and Decode (Optional) Figure 11-5 Baud Rate Default Setting Note: When there is parity bit, the data word length indicates the total length of data bit plus parity bit. When there is no parity bit, the data word length is considered to be the length of data bit. For example, if the data word length is 8bit, when there is no parity bit, it means that the total length of data bits is 8bit;...
  • Page 259 ⚫ Trigger mode Open the trigger configuration menu and select the appropriate trigger type; when choosing UART bus trigger, the trigger type, trigger relationship and trigger data need to be set, as shown in Figure 11-6: Figure 11-6 Trigger Setting Menu After selecting the trigger data, use the pop-up virtual keyboard to modify it, enter the value, and click “Enter”...
  • Page 260 Chapter 11 Serial Bus Trigger and Decode (Optional) Stop bit — trigger at the stop bit of the measured signal, no matter the measured signal uses 1, 1.5, or 2 stop bits or not, the trigger will occur at the first stop bit. [data] —...
  • Page 261 ⚫ UART serial decode The measured signal word length is 8bit; parity bit, none; baud rate, 19.2kb/s, hexadecimal; trigger mode as data bit:55; follow the steps as below: (1) Tap S1 to open the decode channel, and click S1 again to open the bus configuration menu; (2) Select the bus type as “UART”, click “Ch1”, “Idle High”, “Parity None”, “8bit”, “19.20kb/s”, display “hexadecimal”, then close menu;...
  • Page 262 Chapter 11 Serial Bus Trigger and Decode (Optional) Figure 11-7 UART Decode Level Adjustment...
  • Page 263 Figure 11-8 UART Graphic Interface UART graphic interface description: (1) Trigger position (2) Trigger type...
  • Page 264 Chapter 11 Serial Bus Trigger and Decode (Optional) (3) Threshold level (4) Configuration information (5) Decode the data packet, detailed as follows (6) Decode data and the corresponding waveform area UART decode data packet description: (1) Decode data packet displays real-time data about the bus activities; (2) Decode data displays as hexadecimal system in white;...
  • Page 265 Figure 11-9 UART Text Interface UART text interface description, see Figure11-9: (1) S1/S2/S1&S2 is channel configuration bus information. (2) Area for decode data.

  • Page 266: Lin Bus Trigger And Decode

    Chapter 11 Serial Bus Trigger and Decode (Optional) (3) ASCII code corresponding to the text data (when the data format is 9 bits and there is no parity bit, ASCII code corresponds to lower 8 bits of data on the left side). (4) Counter: Calculates the total number of frames and the percentage of ERR (parity error and stop bit error) frames.
  • Page 267 ⚫ Bus configuration Left swipe to open the bus configuration menu, and the following need to be set according to measured signal: Source — Select the signal source of decode. Idle Level - high and low. Select whether to display high active or low active after the signal start bit of measured equipment.
  • Page 268 Chapter 11 Serial Bus Trigger and Decode (Optional) Figure 11-10 LIN Bus Configuration Menu ⚫ Trigger mode Open the trigger configuration menu and select the appropriate trigger type. When the LIN bus trigger is selected, the trigger mode includes: synchronous rising edge, frame ID, frame ID and data. See Figure 11-11:...
  • Page 269 Figure 11-11 LIN Trigger Mode Configuration Menu Synchronous rising edge – When the “Sync Interval” of LIN bus ends, the rising edge triggers. Frame ID — Triggered when a frame with an ID equal to the set value is detected. Select “Frame ID”, click data on the touch screen, and use the pop-up virtual keyboard to modify it.
  • Page 270 Chapter 11 Serial Bus Trigger and Decode (Optional) (1) Tap S1 to open the decode channel, and click again to open the bus configuration menu; (2) Select the bus type as “LIN”, click “Ch1”, “Idle High”, “19.20kb/s”, and then close the menu; (3) Open the trigger mode configuration menu and click “Synchronous Rising Edge”;...
  • Page 271 Figure 11-12 LIN Graphic Interface LIN decode data packet description: (1) Decode data packet displays real-time data about the bus activities. (2) Decode data displays as hexadecimal system.
  • Page 272 Chapter 11 Serial Bus Trigger and Decode (Optional) (3) “Frame ID” displays in yellow, “Data” displays in white, and “Parity sum” displays in green. If the parity sum has error, it is displayed in red “E”. (4) When “?” appears, the time base needs to be adjusted to view decode results. Figure 11-13 LIN Text Interface...
  • Page 273 LIN text interface description, as shown in Figure 11-13: “Ch”: bus channel. “Time”: Time intervals between the last frames to current frames. “ID”: Frame ID value. “Data”: Frame data. “Parity sum”: Frame parity sum, the sum of parity error displays in red. “Trigger”: “Yes”...

  • Page 274: Can(Fd) Bus Trigger And Decode

    Chapter 11 Serial Bus Trigger and Decode (Optional) 11.3 CAN(FD) Bus Trigger and Decode For correctly decoding CAN and CAN FD(optional) bus data and making trigger stable, the bus configuration, trigger mode set and trigger level need to be adjusted. ⚫...
  • Page 275 Figure 11-14 CAN(FD) Bus Configuration Menu ⚫ Trigger mode Open the trigger configuration menu and select the appropriate trigger type; when S1 CAN bus trigger is selected, as shown in Figure 11-15:...
  • Page 276 Chapter 11 Serial Bus Trigger and Decode (Optional) Figure 11-15 CAN Trigger Mode Configuration Menu Trigger mode selection menu description: Frame start — trigger at the start of the frame; Remote frame ID — setting the ID matches the remote frame trigger. After selecting the “Remote Frame ID”, and then set the ID value at the bottom of the trigger data area Operation description: Press the numbers on the touch screen and use the virtual keyboard to set;...
  • Page 277 Remote frame/data frame ID — trigger on remote frame or data frame that matches set ID. Remote frame/data frame ID configuration is the same as the remote data frame ID configuration; Data frame ID and data ID — trigger on data frame that matches set ID and data. The configuration method is the same as the remote frame ID configuration;...
  • Page 278 Chapter 11 Serial Bus Trigger and Decode (Optional) (2) Select the bus type as “CAN”, and then click “Ch1”, “Idle High” and “1Mb/s”. After setting, click the blank area to close the menu; (3) Open the trigger mode configuration menu and click “Frame Start”; (4) Adjust the threshold level according to the signal amplitude;...
  • Page 279 CAN decode data packet description: (1) Decode data packet displays real-time data about the bus activities. (2) Decode data displays as hexadecimal system. (3) “Frame ID” displays in yellow, “Data” displays in white, and “DLC” and “CRC” codes display in green. If there is frame error, it is displayed in red “E”.
  • Page 280 Chapter 11 Serial Bus Trigger and Decode (Optional) Figure 11-17 CAN Text Interface CAN text interface description, as shown in Figure 11-17: “Ch”: bus channel. “Time”: Time intervals between the last frames to current frames. “ID”: CAN frame ID value displayed in hexadecimal, maximum 29 bits.

  • Page 281: Spi Bus Trigger And Decode

    “Type”: Frame type, “SFF” standard data frame, “SRF” standard remote frame, “EFF” extended data frame, “ERF” extended remote frame. “DLC”: Number of data bytes sent by this frame. This value can be ignored for remote frames. “Data”: Frame data. “CRC”: Frame CRC check code. “Error”: Response error, bit stuffing error, format error, CRC error.
  • Page 282 Chapter 11 Serial Bus Trigger and Decode (Optional) ⚫ Bus configuration Left swipe to open the bus configuration menu, the following need to be set: Clock source, data source, chip select signal, and data word length, as shown in Figure 11-18: Figure 11-18 SPI Bus Configuration Menu...
  • Page 283 ⚫ Trigger mode Open the trigger configuration menu and select the appropriate trigger type; when selecting the SPI bus trigger, as shown in Figure 11-19: Figure 11-19 SPI Trigger Mode Configuration Menu The operation method is the same as CAN frame ID to be matched in the configuration, and will not be repeated here.
  • Page 284 Chapter 11 Serial Bus Trigger and Decode (Optional) The measured signal channel Ch1 is connected to CLK, Ch2 channel is connected to DATA, the bus idle state is high, the clock rising edge is sampled; the data word length is 4 bits; the CS chip select is off; the trigger mode matches the “Data”...
  • Page 285 Figure 11-20 SPI Graphic Interface SPI decode data packet description: (1) Decode data packet displays real-time data about the bus activities. (2) Decode data displays as hexadecimal system. (3) Data displays in white.
  • Page 286 Chapter 11 Serial Bus Trigger and Decode (Optional) (4) When “?” appears, the time base needs to be adjusted to view decode results. Figure 11-21 SPI Text Interface...
  • Page 287 SPI text interface description, as shown in Figure 11-21: “Ch”: bus channel. “Time”: Time intervals between the last frames to current frames. “Data”: According to the data word length setting, the decode data is displayed. For example, if the data word length is 8bit, only one byte displays in the data column;...

  • Page 288: I2C Bus Trigger And Decode

    Chapter 11 Serial Bus Trigger and Decode (Optional) 11.5 I2C Bus Trigger and Decode For correctly decoding I2C bus data and making trigger stable, the bus configuration, trigger mode set and trigger level need to be adjusted. ⚫ Bus configuration Left swipe to open the bus configuration menu, Bus configuration includes the serial clock (SCL) and the serial data (SDA) corresponding to the channel settings.
  • Page 289 Figure 11-22 I2C Bus Configuration Menu Notes: When SCL or SDA channel is set, the system will automatically set other channels.
  • Page 290 Chapter 11 Serial Bus Trigger and Decode (Optional) ⚫ Trigger mode Open the trigger configuration menu and select the appropriate trigger type. When the I2C bus trigger is selected, click the trigger type and relationship on the screen, as shown in Figure 11-23: Figure 11-23 I2C Trigger Mode Configuration Menu Trigger mode menu description: Start condition —...
  • Page 291 Restart — triggered when a new start condition occurs before the stop condition. Address no ack — trigger when the ack bit in the set address field is invalid (ignoring W/R bit), select “Address” in the trigger data, and use the pop-up virtual soft keyboard to modify it. Frame Type 1 - Start + Address 7 + Read/Write + Acknowledge + Data;...
  • Page 292 Chapter 11 Serial Bus Trigger and Decode (Optional) the set data match the set relationship condition, trigger on the clock edge of Ack bit after the data byte. After selecting “EEPROM Data Read”, click the relationship by “=” “ >” “<” “ ≠”, and the setting method is the same as the address field.
  • Page 293 Figure 11-24 I2C Graphic Interface I2C decode data packet description: (1) Decode data packet displays real-time data about the bus activities. (2) Decode data displays as hexadecimal system.
  • Page 294 Chapter 11 Serial Bus Trigger and Decode (Optional) (3) Address content display: Read address displays in green, write address displays in yellow, and data displays in white. “W” denotes write operation, “R” denotes read operation, “D” denotes decode data, and “~A” denotes no Ack bit.
  • Page 295 I2C text interface description, as shown in Figure 11-25: “Ch”: bus channel. “Time”: intervals between the last read/write operations to current read/write operations “Address”: in address bar, “R” means the read operation, and “W” means write operation “Data”: data sent by one read and write operation is in the data bar. “Ack”: in Ack bar, “X”...

  • Page 296: Arinc429 Bus Trigger And Decode

    Chapter 11 Serial Bus Trigger and Decode (Optional) 11.6 ARINC429 Bus Trigger and Decode For correctly decoding ARINC429 bus data and making trigger stable, the bus configuration, trigger mode set and trigger level need to be adjusted. ⚫ Bus configuration Left swipe to open the bus configuration menu, the following needs to be set: Data Source —...
  • Page 297 Figure 11-26 ARINC429 Bus Configuration Menu ⚫ Trigger mode Open the trigger configuration menu and select the appropriate trigger type; when the ARINC429 bus trigger is selected, click the trigger type and relationship on the screen, as shown in Figure 11-27:...
  • Page 298 Chapter 11 Serial Bus Trigger and Decode (Optional) Figure 11-27 ARINC429 Trigger Mode Configuration Menu If LABEL, SDI (source identifier), DATA or SSM (symbol/status mark) trigger are used, after selecting trigger mode, use the pop-up virtual keyboard to modify it, enter the value, and click “Enter” on the virtual soft keyboard to complete the setting.
  • Page 299 LABEL: Label, triggered when the specified tag value occurs. SDI: Source identifier, triggered on the specified source terminal. DATA: Trigger on the specified data. SSM: Symbol/status mark, triggered on the specified symbol status matrix. LABEL+SDI: Trigger on the specified label and the specified source terminal. LABEL+DATA: Trigger on the specified label and the specified data.
  • Page 300 Chapter 11 Serial Bus Trigger and Decode (Optional) All 1 bit -: Triggered when any bit with the value of 1 appears. ⚫ ARINC 429 serial decode The measured signal source is CH1, the decode format is LABEL+DATA, the display is in hexadecimal, the baud rate is 12.5kb/s, and the trigger mode is LABEL, operate as follows: (1) Tap S1 to open the decode channel, and click S1 again to open the bus configuration menu;...
  • Page 301 Figure 11-28 ARINC429 Graphic Interface ARINC429 decode data packet description: (1) Data packet, a total of 32bits, the data format is 8~1 (label bit, high bit first) +9~10(SD) +11~29 (data bit, low bit first) +30~31 (symbol status bit) +32 (parity bit)
  • Page 302 Chapter 11 Serial Bus Trigger and Decode (Optional) (2) Label (8bits) - Displayed in octal: yellow (3) SDI (2bits) - Displayed in binary: blue (4) Data (19bits) - Displayed in selected numeration system: white, or red if there is parity error (5) SSM (2bits) - Displayed in binary: green Figure 11-29 ARINC429 Text Interface...
  • Page 303 ARINC429 text interface description, as shown in Figure 11-29: “Ch”: bus channel. “Time”: intervals between the last read/write operations to current read/write operations “LABLE”: label, information identifier, displayed in octal. “SDI”: source/target identifier, displayed in binary (displays XX if not identified separately). “Data”: content of the transmitted information, displayed in the selected numeration system.

  • Page 304: 1553B Bus Trigger And Decode

    Chapter 11 Serial Bus Trigger and Decode (Optional) 11.7 1553B Bus Trigger and Decode For correctly decoding 1553B bus data and making trigger stable, the bus configuration, trigger mode set and trigger level need to be adjusted. ⚫ Bus configuration Left swipe to open the bus configuration menu, the data source and display hexadecimal need to be set, as shown in Figure 11-30:...
  • Page 305 Figure 11-30 1553B Bus Configuration Menu ⚫ Trigger mode Open the trigger configuration menu and select the appropriate trigger type. When the trigger type is 1553B bus trigger, click the trigger type on the screen, as shown in Figure 11-31:...
  • Page 306 Chapter 11 Serial Bus Trigger and Decode (Optional) Figure 11-31 1553B Trigger Mode Configuration Menu Trigger configuration menu description: Command/status word sync header: Triggered at the beginning of the command/status word (at the end of valid C/S sync pulse). Data word sync header: Triggered at the beginning of data word (at the end of valid data sync pulse). Command/status word: Triggered when the specified command/status word is detected.
  • Page 307 If you select this option, RTA softkey will be available, allowing you to select the hexadecimal remote terminal address value to be triggered on it. If you select 0xXX (irrelevant), oscilloscope will trigger on any RTA. Manchester coding error: Triggered when a Manchester coding error is detected. Data word: Triggered when the specified data word is detected.
  • Page 308 Chapter 11 Serial Bus Trigger and Decode (Optional) (3) Open the trigger setting menu, select the trigger type as bus trigger, 1553B, and trigger mode as “command/status word sync header”. Channel threshold level is adjusted according to signal amplitude. 1553B trigger graphic interface is shown in Figure 11-32: Figure 11-32 1553B Graphic Interface...
  • Page 309 1553B decode data packet description: (1) Remote terminal address (5-bit data): blue (2) The value of remaining 11 bits of the command/status word: yellow (3) Decoded data: white (4) If the command/status or data word has a parity error, its decoded text is displayed in red instead of green or white.
  • Page 310 Chapter 11 Serial Bus Trigger and Decode (Optional) Figure 11-33 1553B Text Interface 1553B text interface description, as shown in Figure 11-33: “Ch”: bus channel. “Time”: intervals between the last read/write operations to current read/write operations.
  • Page 311 “Type”: frame type (data frame DATA, command/status frame C/S, others N/A). “RAdr”: remote terminal address, displayed in the selected numeration system (N/A for no content display). “Data”: content of the transmitted information, displayed in the selected numeration system. “Trigger”: “Yes” means reach trigger condition. “Error”: displays the frame error type (parity error Par, Manchester coding error M-ch).

  • Page 312: Chapter 12 Homepage Functions

    Chapter 12 Homepage Functions Chapter 12 Homepage Functions This chapter contains the functions of the oscilloscope homepage and describes the functions of all icons on the homepage and settings. You are recommended to read this chapter carefully to understand the homepage functions of the Smart series oscilloscope.
  • Page 313 The following figure shows the contents of the oscilloscope home page. Slide left or right to display the remaining applications. See Figure 12-1. Figure 12-1 Homepage Interface...

  • Page 314: Oscilloscope (See Chapters 2~11)

    Chapter 12 Homepage Functions 12.1 Oscilloscope (see Chapters 2~11) 12.2 App Store Tap the app store icon on the homepage to go to the app store interface, as shown in Figure 12-2. App store content includes Network, Local, U-disk, and About. Figure 12-2 App Store...
  • Page 315 Network Tap “Network” to open the application list. Tap app icon to view details such as version number of the current app and app description, and tap the green open option below to open or install the current app. Tap the green option on the right of the app list to open and install the app. Local Apps that have been downloaded and installed are displayed locally.
  • Page 316 Chapter 12 Homepage Functions After USB disk has been plugged, if there are no apk files in the USB device for installation, the interface displays “There is no available apk file in the U disk directory”. About In “About” interface, the equipment model, bandwidth, serial number, version information, shipment date and information about installed options can be viewed.
  • Page 317 Figure 12-3 About Interface The options that can be installed include: UART, LIN, SPI, CAN, I2C, 1553B, 429 and other serial decode (refer to Chapter 11 Serial Bus Trigger and Decode).

  • Page 318: Settings

    Chapter 12 Homepage Functions 12.3 Settings Tap settings on Homepage to enter the System Settings interface. Settings on the settings interface include Network & internet, display, sound, storage, system and About Oscilloscope, as shown in Figure 12-4. Figure 12-4 System Setting Interface...
  • Page 319 WLAN connection Tap WIFI icon to enter the WLAN settings interface, as shown in Figure 12-5. Figure 12-5 WLAN Connection Setting...
  • Page 320 Chapter 12 Homepage Functions Tap on/off bar to turn the WLAN function on. Oscilloscope can automatically scan the surrounding wireless networks and display their names by list. Tap the wireless network to be connected and the password input box will pop up. After entering password using the virtual keyboard, tap Enter to connect oscilloscope to the wireless network.
  • Page 321 Figure 12-6 Portable WLAN Hotspot Setting Display Tap display icons to set the oscilloscope Brightness level, Wallpaper, and Auto standby. Brightness level: The progress bar can be dragged to set the brightness of the screen display.
  • Page 322 Chapter 12 Homepage Functions Wallpaper: Set the screen wallpaper. Auto standby: Set auto standby time. Sound Tap the “sound” icon and drag the progress bar in the sound section to change the media volume, alarm volume and notification volume. After clicking the default notification ring tone, drag up and down to select the ring tone, then click OK.
  • Page 323 If USB device is plugged, it will display the total storage capacity and available memory size, and can also uninstall and format SD card. Language and input method Tap System →language & input icons to set your system language and input method. Language: add a language and drag it to the first position of language list to make it as system language.
  • Page 324 Chapter 12 Homepage Functions Tap System →Date & time icons to set your system date and time Use network-provided time: When turned on, the time provided by the network will be used as the system time. Date and time cannot be set manually after turning this on. Set date: Set the system date manually.

  • Page 325: File Manager

    12.4 File Manager File manager app can enable quick access to and management of various files stored on the equipment. Tap the Files app icon on the homepage screen to enter the file manager interface. Recent: shows files that have been opened recently Classification: views files by types, including images, videos, Audio, Documents, Downloads, STO etc.

  • Page 326: Browser

    Chapter 12 Homepage Functions Calculator can perform simple addition, subtraction, multiplication and division calculations as well as scientific calculations. 12.6 Browser Tap the browser icon on homepage interface to enter the browser interface, and then it can access to the internet if the network condition is good, as shown in Figure 12-7.

  • Page 327: Gallery

    Figure 12-7 Browser Interface 12.7 Gallery Tap gallery application on the homepage interface to enter the picture viewing interface, as shown in Figure 12-8.
  • Page 328 Chapter 12 Homepage Functions Figure 12-8 Picture Viewing Interface Gallery provides locally stored photos/videos with the functions of picture/video viewing and photo editing. In the picture view interface, pictures and videos can be classified into different categories according to the method in the upper left corner, and tap them to view pictures or videos.
  • Page 329 When viewing pictures, click to display them in full screen. When viewing videos, swipe left and right to select the video you want to play. Click the triangle play button, and the video will play automatically. Tap the screen to pause play.

  • Page 330: Calendar

    Chapter 12 Homepage Functions When viewing pictures and videos, tap the option at the top right of the screen and click to select items. The pictures and videos can be selected. Click the recycle bin icon in the upper right corner of the screen to delete pictures or videos.

  • Page 331: Clock

    Figure 12-10 Electronic Calculation Tool Function 12.10 Clock Tap time icon on the homepage or tap clock app icon to enter the clock settings screen, as shown in Figure 12-11.
  • Page 332 Chapter 12 Homepage Functions Alarm clock Add an alarm: Click “+” button below to add an alarm clock and create settings. Alarm time: Drag pink dot in the dial to set the hour, and drag again to set the minute. Repeat: Monday to Sunday available and click calendar icon on the right to enter the calendar for custom selection.
  • Page 333 Delete timer: Click “DELETE” to delete the timer. Pause: Click the double rectangle button to pause timer. Stopwatch Start: Click “Triangle” to start timing. Pause: Click “Double Rectangle” below to pause the stopwatch. Mark: Click the LAP to mark it.
  • Page 334 Chapter 12 Homepage Functions Figure 12-11 Time Setting...

  • Page 335: Power Off

    12.11 Power Off Long press power button to enter the power off interface, as shown in Figure 12-12. Power off contains 4 options: Shutdown, Reboot, Standby, Lock Screen. Figure 12-12 Power Off Interface...

  • Page 336: File Explorer

    Chapter 12 Homepage Functions Shutdown: Click the button to turn off the oscilloscope. Reboot: Click the button to restart the oscilloscope. Standby: Click the button to standby the oscilloscope, press power button to wake. Lock Screen: Click the button to lock the oscilloscope screen, repeat the step to unlock. 12.12 ES File Explorer Use the ES file browser to realize wireless transfer of oscilloscope files to computers and smartphones.
  • Page 337 Figure 12-13 ES File Explorer On PC: Get an ftp client software, here FileZilla is used as an example. Put the computer and the oscilloscope in the same network gateway, create a new site, use the FTP file transfer protocol, enter the Host address and port number generated by the oscilloscope ES file explorer, and set the logon type to anonymous.
  • Page 338 Chapter 12 Homepage Functions Figure 12-14 FileZilla On smartphone: Get an ftp client application, take the ES file explorer app as an example. Place the smartphone and the oscilloscope on the same network gateway, open ftp and enter the URL address and Port number generated by the oscilloscope ES file explorer, and connect (no need input account &...
  • Page 339 Figure 12-15 Smartphone ftp...

  • Page 340: Chapter 13 Remote Control

    Chapter 13 Remote Control Chapter 13 Remote Control This chapter contains the application of host computer, mobile remote control and SCPI command, in order to understand remote control functions of the Smart series oscilloscope. ⚫ Host computer ⚫ Mobile remote control ⚫...

  • Page 341: Host Computer

    13.1 Host Computer To control the instrument using the host computer software, you need to install the NI driver first, then the RemoteDisplay software is downloaded and installed. This software is only suitable for Micsig Smart Series oscilloscopes. 13.1.1 Installation of Host Computer Software Note: The host computer software only supports Win7 or higher edition operating system.

  • Page 342: Connection Of Host Computer

    Chapter 13 Remote Control Figure 13-1 RemoteDisplay Software 13.1.2 Connection of Host Computer USB connection: Connect USB Device to the computer and oscilloscope through USB data cable. After the computer recognizes the USB device, open the host computer, set the connection mode to USB , and display the device information in the device information display box in the lower right corner.
  • Page 343 the lower right corner. This indicates that the oscilloscope has been found. Click to connect to the selected oscilloscope. Enter IP connection: In case of network connection (WIFI or LAN), directly type oscilloscope IP to be connected in the oscilloscope device information display box in the lower right corner, and then click the oscilloscope connection status button, the host computer will be connected to the oscilloscope corresponding to the entered IP address.

  • Page 344: Main Interface Introduction

    Chapter 13 Remote Control 13.1.3 Main Interface Introduction Figure 13-2 Host Computer Interface...
  • Page 345 Click to exit the host computer software Host computer on/off button The button has two states: Oscilloscope connection status button Green: Connect to selected oscilloscope when clicked Red: Disconnect from oscilloscope when clicked Click to take photo quickly. Pictures are stored in the local Quick camera button directory C:\Users\Public\Pictures Click to open or close video record function.

  • Page 346: Operation Interface Introduction

    Chapter 13 Remote Control Note: WIFI connection must ensure that oscilloscope and computer are in the same network 7. Host computer display area Synchronous display with oscilloscope 8. Oscilloscope information display Display oscilloscope model, connection mode, SN, IP and other information, select the oscilloscope to be connected 9.

  • Page 347: Storage And View Of Pictures And Videos

    13.1.5 Storage and View of Pictures and Videos Storage setting of pictures and videos: Open the host computer storage setting , set the storage location of pictures and videos, as shown in the figure below: Figure 13-3 Host Computer Storage Setting Pictures are stored in the local directory C:\Users\Public\Pictures by default.
  • Page 348 Chapter 13 Remote Control Figure 13-4 Change Storage Directory View pictures and videos: Open picture (video) storage directory to view pictures (videos) stored on the host computer.

  • Page 349: Mobile Remote Control

    Figure 13-5 View Pictures 13.2 Mobile Remote Control Micsig Smart series oscilloscopes support remote control on mobile phone (android & iOS). You need to download Android app from the official website of Micsig (address: http://www.micsig.com) and install it. For iOS, go to...
  • Page 350 Chapter 13 Remote Control After App is successfully connected, mobile device can be used to control the oscilloscope and display the oscilloscope interface in a real time manner. Figure 13-6 APP interface...
  • Page 351 Figure 13-7 Successful Connection of APP Android APP can be connected by two methods: Use oscilloscope portable hotspot: Mobile phone can be connected to the hotspot of oscilloscope. Enter the oscilloscope IP 192.168.45.1 in the IP box at the lower right corner of the screen to connect successfully for control;...

  • Page 352: Scpi

    Chapter 13 Remote Control The first connection method is recommended. 13.3 SCPI TO support users to use SCPI（Standard Commands for Programmable Instruments）commands a computer via USB, LAN or Wi-Fi to program and control the digital oscilloscope. For more information, refer to the programming guide for this product.

  • Page 353: Chapter 14 Update And Upgrade Functions

    Chapter 14 Update and Upgrade Functions This chapter describes the methods of software update and increasing the optional function. You are recommended to read this chapter carefully understand the upgrade functions of the Smart series oscilloscope. ⚫ Software update ⚫ Add optional functions...

  • Page 354: Software Update

    Chapter 14 Update and Upgrade Functions 14.1 Software Update Micsig often releases software updates for its products. To update your oscilloscope software, you can connect the oscilloscope to WIFI for networking, and open the SystemUpgrade application to check and install update.

  • Page 355: Add Optional Functions

    Note: Please pay attention to keep the oscilloscope power more than 50% when installing updates or connect the oscilloscope to the adapter, so as to prevent the oscilloscope from becoming abnormal due to insufficient power for update. To view the currently installed software and firmware, tap the “App Store” software in the “Home” page to display the oscilloscope software and firmware information on the “About”...
  • Page 356 Chapter 14 Update and Upgrade Functions Figure 14-2 Decode Functions Not Installed If you need the optional function service, please contact Micsig for license and enter the install option function at the license bar.
  • Page 357 Figure 14-3 Decode Functions Installed...

  • Page 358: Chapter 15 Reference

    Chapter 15 Reference Chapter 15 Reference This chapter contains the measurement category suitable for the oscilloscope and the environmental level of pollution degree supported. You are recommended to read this chapter carefully to understand the conditions of use of the Smart series oscilloscope. ⚫...

  • Page 359: Measurement Category

    15.1 Measurement Category Oscilloscope measurement category Smart oscilloscopes are primarily used for measurements in Measurement Category I. Measurement category definitions Measurement category I is for measurements performed on circuits not directly connected to MAINS. Examples are measurements on circuits not derived from MAINS, and specially protected (internal) MAINS derived circuits. In the latter case, transient stresses are variable;...

  • Page 360: Pollution Degree

    Chapter 15 Reference in the fixed installation, and equipment for industrial use and some other equipment, for example, stationary motors with permanent connection to the fixed installation. Measurement category IV is for measurements performed at the power source of the low-voltage installation. Examples are electricity meters and measurements on primary overcurrent protection devices and ripple control units.
  • Page 361 Pollution Degree Pollution degree 1: No pollution or only dry, non-conductive pollution occurs. The Categories pollution has no influence. For example: a clean room or air-conditioned office environment. Pollution degree 2: Normally only dry, non-conductive pollution occurs. Occasionally temporary conductivity caused by condensation may occur. For example: general indoor environment.

  • Page 362: Chapter 16 Troubleshooting

    Check the Power-off lock on the side of oscilloscope; ⚫ Contact Micsig if the problem persists, and we will provide service to you. If acquired waveforms do not display on the screen when the signal source is connected, please follow the steps below: ⚫...
  • Page 363 ⚫ Check whether the trigger type is correctly selected; ⚫ Check whether trigger conditions are set correctly ⚫ Check whether signal source is working properly; ⚫ Check whether the channel is turned on; ⚫ Check whether the vertical scale factor is set correctly; ⚫...
  • Page 364 Chapter 16 Troubleshooting ⚫ Check the trigger source on the trigger type menu to ensure that it is consistent with the actually used signal channel; ⚫ Check the trigger type: edge trigger is adopted for general signal, and video trigger mode for video signal. Only the correct trigger mode is used, the waveform can be displayed stably;...
  • Page 365 If the display becomes slower after setting average times of sampling: ⚫ If the average times are above 32, it is normal for the general speed to become slow. ⚫ You can reduce the average times. Staircase waveform is displayed: ⚫...
  • Page 366 Chapter 16 Troubleshooting 10. During measurement, the measured value is displayed as -----: ⚫ This phenomenon is normal. When the channel waveform displays beyond the waveform display area, the measured value is displayed as -----. If the channel vertical sensitivity or vertical position is adjusted, the measured value can be displayed correctly;...
  • Page 367 13. Oscilloscope backlight has low brightness: ⚫ Check whether the backlight settings are correct. 14. A waveform being moved changes abruptly: ⚫ Check whether the picture is displayed in full screen. 15. Turn off the channel at Auto state: ⚫ This phenomenon is normal. At Auto state, the channel with an amplitude less than 10mV will be turned off. 16.

  • Page 368: Chapter 17 Services And Support

    Micsig commit as follows: Repair Commitments : Micsig commits to use the original factory parts for products returned by the user for repair (under warranty or not) and the commissioning and testing standards are identical with new products. Micsig the obligation to inform the customer, but without any other obligations for non-product defects or products with decreased performance not for objective reasons.
  • Page 369 Service Time Commitments : Micsig will give a reply of the time and cost for repair within 2 working days after receiving the product returned by the user for repair. After the reply is confirmed, the repair period for a general fault is 5 working days and shall not exceed 10 working days for any special fault.

  • Page 370: Annex

    Annex Annex Annex A:Maintenance and Care of Oscilloscope General maintenance Do not put or leave the instrument in a place where the LCD display will be exposed to direct sunlight for long period. Caution: To avoid damage to the oscilloscope or probes, do not expose them to sprays, liquids, or solvents. Clean oscilloscope Examine the oscilloscope and probes as often as operating conditions require.
  • Page 371 ⚫ Use a soft cloth dampened with water to clean the oscilloscope while doing this please keep the power off. Wipe with a mild detergent and water. Do not use any corrosive chemical cleaning agent, in order to avoid damaging the oscilloscope or probe.

  • Page 372: Annex B: Accessories

    Annex Battery charge Upon delivery, the lithium battery may not be charged. It takes 6 hours to be fully charged (the oscilloscope is recommended to turn off to save the charging time). When running on battery power, the battery level indicator in the lower right corner of the screen will indicate the battery usage.
  • Page 373 Smart packing list Optional accessories Oscilloscope suitcase/handbag Battery High voltage probe Differential probe Current probe...
  • Page 374 The company will assume no responsibility for accident or hazard caused by the improper operation of the user. The copyright of this manual shall belong to Micsig. Any organization or individual may not duplicate, copy or excerpt the contents without Micsig’s authorization. Micsig reserves the right to claim against such...

This manual is also suitable for:

To3004To2004To2002To1004

Table of Contents
