Buyers 1501155 Installation Instructions

1501155 Window Screen for Ladder Rack (1501150)
1. Window Screen must be installed with the flanges
facing the cab of the truck as shown in Figure A.
2. The Window Screen will work with the hardware
already installed on the Ladder Rack but the bolts
must be oriented as shown in Figure B. This orien-
tation is necessary to ensure that the bolts can be
installed without interfering with the truck cab.
Installation Instructions
3. Install Window Screen and hardware in the position
shown in Figure C.
NOTE: If the ladder rack was previously installed it
may need to be repositioned when mounting the win-
dow screen. The hardware may need to be loosened
and the rack re-centered.
This window screen is designed to be used with
Buyers Products Ladder Rack part number 1501150
ONLY
1
www.buyersproducts.com
Phone (440) 974-8888
Fax 800-841-8003
WARNING
—continued
