Once debugging is completed, resume the standby status and the display is as below:
Debugging code
LED1
Display
Code
status
01~04 ON
Once the debugging for the complete unit is finished, please set relevant functions for the unit
according to the actual functional requirements of the project. Refer to relative technical materials for
the detailed operation method. If there is no special requirement, skip this step directly.
When delivery it to the user for operation, explain the precautions to the user.
4.4 Parameter Judgment Reference Value for Unit Normal Operation
Debugging Parameter Reference Value for GMV Heat Recovery DC Inverter VRF Unit
No. Debugging item
1
2
3
Outdoor
4
System
unit's
parameter
parameter
5
6
Progress code
LED2
Display
Code
status
OF ON
Parameter name
Outdoor ambient
temperature
Discharge pipe
temperature of inverter
compressor 1
Shell top tube
temperature of inverter
compressor 1
Discharge pipe
temperature of inverter
compressor 2
Shell top tube
temperature of inverter
compressor 2
Temperature of
defrosting temperature
sensor
GMV Heat Recovery DC Inverter VRF
Status code
LED3
Code Display status
OF ON
Unit Reference value
℃
℃
● When the compressor starts running, the
normal discharge pipe of cooling or shell
℃
top temperature is 70~95℃, above 10℃
higher than the saturation temperature of
system high pressure; the normal heating
temperature is 65~90 ℃, above 10℃
℃
higher than the saturation temperature of
system high pressure.
℃
● When the system is running in cooling
mode, the temperature of defrosting
temperature sensor is 5~11℃ lower than
system high pressure;
℃
● When the system is running in heating
mode, the temperature difference between
the defrosting temperature sensor and the
system low pressure is about 2℃.
66
Meaning
The complete unit has finished
the debugging and it stays at
standby status. LED1 displays
module address; LED2 and
LED3 displays "OF".
—
