ED UPS
Assembly Instruction
Original document
060675 45532/17224 - 07/2023
EN

Advertisement

loading
Need help?

Need help?

Do you have a question about the ED and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dormakaba ED

Summary of Contents for Dormakaba ED

  • Page 1 ED UPS Assembly Instruction Original document 060675 45532/17224 - 07/2023...

  • Page 2: Information About This Document

    Information about this document Assembly Instruction 1 Information about this document 1.1 Contents and purpose This document describes the mounting, connection and commissioning of the ED UPS. 1.2 Target group The product may only be mounted and commissioned by a qualified electrician.
  • Page 3 Application tips, useful information Cross references point to the number of the chapter in which additional information is located. Example [ 2.2 ] Action steps Requirement ü Step 1 ð Intermediate result 2. Step 2 ð Result 060675 45532/17224 - 07/2023 ED UPS...

  • Page 4: Personnel Qualification

    2.2 Intended use • The ED UPS is used to keep the ED 100/250 in operation in the event of mains failure. • The ED UPS can be mounted either during the initial mounting or retrofitted on the ED 100/250.

  • Page 5: Product Description

    29280062 ED charging electronics for UPS passive door leaf The core components of the ED UPS are an ED-AMP board, a connection cable, the battery casing and an ED RBI board for double-leaf doors. The battery is not included. This must be ordered separately.

  • Page 6: Led Display

    (I_ED < tween ED and 65 mA again. 65 mA) ED-AMP. Self-test or hard- 5 x short, Restart None ware error 1 x long In case of permanent errors, contact dormakaba. ED UPS 060675 45532/17224 - 07/2023...
  • Page 7 Screw-on points of the ED UPS mounting plate The mounting plate for the ED UPS must always be aligned in such a way that the screw-on point of the connecting lug points in the direction of ED 100/250. Screw-on points of outer Vario bracket...
  • Page 8 Mounting ED UPS Assembly Instruction Procedure The ED UPS must always be placed on the side where the program switch is located. Switch off the ED 100/250 at the power switch (1). 2. Dismantle the ED 100/250 up to the base plate. The description can be found in the ED 100, ED 250 mounting and commissioning instructions.
  • Page 9 Assembly Instruction Mounting ED UPS 10. Mount the ED UPS mounting plate on the ED 100/250 mounting plate. 11. Attach the mounting plate to the wall. ð The ED UPS mounting plate is firmly connected to the ED 100/250 mounting plate. 12. Re-mount the ED 100/250. Do not mount the casing cover.

  • Page 10: Electrical Connection

    3. Remove the green 3-pin power plug from the ED 100/250 control board. 4. Unscrew the red and black cable from the connector. 5. Some ED 100/250 have another blue cable in the connector next to the red (+) and black (ground) cable.
  • Page 11 Secure the range of motion of the door leaves. 12. Plug in the ED ribbon cable. 13. Mount the end cap of the ED 100/250 on the outer end of the ED UPS. 14. Attach the casing cover (8) to the casing.

  • Page 12: Cable Routing

    Assembly Instruction 5.3 Cable routing Lay the connection cables as follows: Illustrated without ribbon cable Connection cable: Battery - ED-AMP board Connection cable: Board - program switch Illustrated with ribbon cable 6 Commissioning No further steps are required for commissioning.
  • Page 13 9. Connect the plug for A01 battery to the ED-AMP board. DANGER Danger of death due to door leaves The ED UPS supplies the ED 100/250 with voltage regardless of the power switch setting. As a result, the ED 100/250 can no longer be switched off. •...

  • Page 14: Disassembly And Disposal

    9.1 Disposing of batteries Do not dispose of batteries as domestic waste! Used batteries must be returned to a disposal system in accordance with state and local regulations. The batteries must be fully discharged prior to disposal. ED UPS 060675 45532/17224 - 07/2023...
  • Page 15 Assembly Instruction Notes 060675 45532/17224 - 07/2023 ED UPS...
  • Page 16 060675 45532/17224 - 07/2023 Copyright © dormakaba 2023 dormakaba Deutschland GmbH DORMA Platz 1 58256 Ennepetal Germany +49 2333 793-0 www.dormakaba.com www.dormakaba.com...
