Installation

Single-phase, 230 VAC
L1
L2
L3
N
Thermal switch
Contactor
Noise filter
Regeneration
resistor *1
Reverse
pulse
Forward
pulse
12 to 24 VDC
RUN Command
Input
Alarm Reset
Input
Deviation Counter
Reset Input
Gain Switch
Input
Electronic Gear
Switch Input
Reverse Drive
Prohibit Input
Forward Drive
Prohibit Input
*1. An External Regeneration Resistor can be connected. Connect this resistor if the regenerative energy exceeds regeneration absorption capacity in the Servo Drive.
Note: 1.The dynamic brake operates when the main circuit power supply or the control circuit power supply is turned OFF.
Note: 2.When turning OFF the main circuit power supply, turn OFF the RUN Command Input (RUN) signal at the same time.
14
L1
L3
SMARTSTEP2
Servo drive
CNA
(100-400 W)
P
B1
22
+CW
4.7 kΩ
220 Ω
23
−CW
24
+CCW
220 Ω
−CCW 25
4.7 kΩ .
24VIN 1
2
RUN
4.7 kΩ
RESET 3
4.7 kΩ
ECRST 4
4.7 kΩ
GSEL 5
4.7 kΩ
GESEL 6
4.7 kΩ
NOT 7
4.7 kΩ
POT 8
U
V
CNB
W
CN2
CN1
9 /ALM
10 INP
11 BKIR
12 WARN
13
OGND
21
14
GND
15
+A
−A
16
18
+B
−B
17
19
+Z
−Z
20
Shell, 26 FG
Servo motor
Optical encoder
Alarm Output
Positioning
Completed
Output
Maximum operating
voltage: 30 VDC
Brake Interlock
Maximum Output
Current: 50 mA DC
Warning Output
Z
Z-phase Output
(open collector output)
Encoder A-phase
Output
Line driver output
Conforms to
Encoder B-phase
EIA RS-422A
Output
(Load resistance:
220 Ω min.)
Encoder Z-phase
Output
Frame ground
AC servo systems
