PROAIM P-ZTLT-01 Assembly Manual

Z-tilt camera head (pan-tilt)

Download this manual

Z-Tilt Camera Head (Pan-Tilt) (P-ZTLT-01)

A s s e m b l y M a n u a l

What's In The Box

Please inspect the contents of your shipped package to ensure you have received everything that is listed

below.

1/4" Camera Bolt

3/8" Converter

L-Type Allen Key (3mm)

Z-Tilt Camera Head

No part of this document may be reproduced, stored in a retrieval system, or transmitted by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permitted by the applicable copyright

statutes or in writing by the Publisher.

Need help?

Do you have a question about the P-ZTLT-01 and is the answer not in the manual?

Page 1 Z-Tilt Camera Head (Pan-Tilt) (P-ZTLT-01) A s s e m b l y M a n u a l What’s In The Box Please inspect the contents of your shipped package to ensure you have received everything that is listed below.
Page 2 Z-Tilt Camera Head Setup Z-Tilt Camera Head Mounting • Remove the 3/8" converter from the bottom of the Z-Tilt camera head using a screwdriver (Not Included). • Then, mount the Z-Tilt camera head on the Tripod (Not Included). Z-Tilt Camera Head Rotation •...
Page 3 • The Camera is now securely mounted on the Z-Tilt camera head. FEATURE: Its 3/8"-16 threaded mounting hole included adapter bushing ensure compatibility with a wide range of tripods and sliders. Different Pan-Tilt Adjustments...
Page 4 YOUR PROAIM Z-TILT CAMERA HEAD ALL DRESSED UP AND READY TO GO! (SHOWN WITH OPTIONAL ACCESSORIES) Warranty: We offer a one-year warranty for our products from the date of purchase. Within this period, we will repair it without charge for labor or parts. The warranty doesn’t cover transportation costs, nor does it cover a product subjected to misuse or accidental damage.
