Omron SMARTSTEP 2 SERVO DRIVE System Configuration Manual page 7

L1
L2
L3
N
Thermal switch
Contactor
Noise filter
Single-Phase
200 to 230 VAC
Reverse pulse
500 kpps max.
Forward pulse
Position reference
Reverse pulse
2 Mpps max.
Forward pulse
12 to 24 VDC
Servo ON
Vibration filter
switching
Gain switching
Electronic gear
switching
Deviation counter reset
Alarm reset
Control mode
switching
Pulse prohibition
Reverse run
prohibited
Forward run
prohibited
*1 B3-B2 are short-circuited. If the internal regenerative resistor is insufficient, remove the wire between B2 and B3 and connect an external regen-
erative resistor between B1 and B2.
*2 Use only when an absolute encoder. If a backup battery is connected, an encoder cable with a battery is not required.
*3 The default values are ZSP (zero-speed detection) for OUTM1 and T-LIMIT (at torque limit) for OUTM2.
SmartStep 2 servo drive
*1
B1 B3
SMARTSTEP2
Servo drive
L1
(750W)
L3
CNA
L1C
L2C
2.2 kΩ
+24 VCW 1 CN1
+CW 3
220 Ω
-CW 4
+24 VCCW 2 2.2 kΩ
+CCW 5
220 Ω
-CCW 6
+CWLD 44 3 kΩ
43 kΩ
110 Ω
-CWLD 45
43 kΩ
3k Ω
3k Ω
+CCWLD 46
43 kΩ
110 Ω
-CCWLD
47
43 kΩ
3 kΩ
4.7 kΩ
+24 VIN 7
RUN 29
4.7 kΩ
DFSEL
26
4.7 kΩ
GSEL
27
4.7 kΩ
GESEL 28
4.7 kΩ
ECRST 30
4.7 kΩ
RESET 31
4.7 kΩ
TVSEL 32
4.7 kΩ
IPG 33
4.7 kΩ
NOT 8
4.7 kΩ
POT 9
Shell
B2
U
CNB V
W
Optical encoder
CN2
11 BKIR
Brake release signal output
10 BKIRCOM
35 READY
Servo ready output
34 READYCOM
37 /ALM
Alarm output
36 ALMCOM
39 INP
Positioning completed output
38 INPCOM
12
OUTM1
General-purpose output 1
40
OUTM2
General-purpose output 2
41
COM-
19 Z
Phase-Z output
(output collector output)
25 ZCOM
21 +A
Encoder phase-A output
22 -A
49 +B
Encoder phase-B output
48 -B
23 +Z
Encoder phase-Z output
24 -Z
100Ω
20 SEN
Sensor ON
4.7 kΩ
1 µF
13 SENGND
42
BAT
43
BATGND
50
Servo motor
External power supply 12 to 24 VDC
Maximum
service voltage: 30 VDC
Maximum
output current: 50 mADC
*3
*3
Line-driver output corresponding
with the EIA RS-422A communications
method (load resistance 120 W min.)
*2
Backup battery
(3.6 V)
95
