Installation

Single-phase, 230 VAC
L1
L2
L3
N
Thermal switch
Contactor
Noise filter
Regeneration
resistor *1
Reverse
pulse
Forward
pulse
12 to 24 VDC
RUN Command
Input
Alarm Reset
Input
Deviation Counter
Reset Input
Gain Switch
Input
Electronic Gear
Switch Input
Reverse Drive
Prohibit Input
Forward Drive
Prohibit Input
*1. An External Regeneration Resistor can be connected. Connect this resistor if the regenerative energy exceeds regeneration absorption capacity in the Servo Drive.
Note:1.
The dynamic brake operates when the main circuit power supply or the control circuit power supply is turned OFF.
2.
When turning OFF the main circuit power supply, turn OFF the RUN Command Input (RUN) signal at the same time.
94
L1
L3
SMARTSTEP2
Servo drive
CNA
(100-400 W)
P
B1
CN1
22
+CW
4.7 kΩ
220 Ω
−CW 23
24
+CCW
220 Ω
−CCW 25
4.7 kΩ .
24VIN 1
2
RUN
4.7 kΩ
RESET 3
4.7 kΩ
ECRST 4
4.7 kΩ
GSEL 5
4.7 kΩ
GESEL 6
4.7 kΩ
NOT 7
4.7 kΩ
POT 8
Servo motor
U
V
CNB
W
Optical encoder
CN2
9 /ALM
Alarm Output
10 INP
Positioning
Completed
Output
11 BKIR
Brake Interlock
12 WARN
Warning Output
13
OGND
21 Z
Z-phase Output
(open collector output)
14
GND
15
+A
Encoder A-phase
−A
Output
16
18
+B
Encoder B-phase
−B Output
17
19
+Z
Encoder Z-phase
−Z
20
Output
Shell, 26 FG
Frame ground
Maximum operating
voltage: 30 VDC
Maximum Output
Current: 50 mA DC
Line driver output
Conforms to
EIA RS-422A
(Load resistance:
220 Ω min.)
AC servo systems
