SmartStep2 Servo Drive (750 W model)
Main-circuit power terminals
Control-circuit power terminals
External regeneration resistor
Servomotor connection terminals
Protective ground terminals
92
Analog monitor outputs
connection terminals
Display area
AC SERVO DRIVER
UNIT No.
Settings area
DATA
RS-485
Communications connector
(CN3A)
RS-232
Communications connector/
Parameter unit connector
(CN3B)
Control I/O connector
(CN1)
Encoder connector (CN2)
AC servo systems
